HIKVISION DS-7732NXI-I4/16P/VPro 4K 32-Channel 1.5U 4-Bay NVR with 8TB HDD & 16-Port PoE (200W)

Support up to 4 x 20TB Storage

Brand: HIKVISION
MPN: 303623247
Part #: CCTHIK303623247
UPC:

In stock at NZ Logistics Centre

No store stock available.

Click & Collect: Select your store to check availability

Delivery: Order now and it ships on 13 Jan When will I receive it?

Add To Compare

Stock Alerts

Click or hover over image to enlarge

Brand: HIKVISION
MPN: 303623247
Part #: CCTHIK303623247
UPC:

Be the first to review this product

HDD Bays

Max Camera Resolution

32 MP

Max Cameras Supported

Video Recorder Type

NVR

View full specs

Returns & Warranty Bulk Quote Print Page

Features

I/VPro Series NVR with AcuSeek

- H.265+/H.265/H.264+/H.264 video formats
- Intelligent analytics based on Guanlan Large-Scale AI Models
- Up to 32-ch AcuSeek and AcuSearch function
- Up to 8-ch facial recognition for face picture
- Up to 32-ch IP camera inputs
- Up to 32-ch 1080p decoding capability

Powerful Multi-Channel Video Management

This Vpro Series NVR supports up to 32 channels for IP video input and simultaneous 32-channel 1080p decoding, compatible with the latest video formats including H.265+ and H.264+. Each device can be connected to up to 32 high-definition cameras, and deliver real-time monitoring and recording over high bandwidth.

Advanced AI Analytics Empowered by Guanlan Models

Integrated with large-scale Guanlan AI models, this NVR provides robust video intelligence-features include AcuSeek, AcuSearch, facial recognition, perimeter protection, ANPR (automatic number plate recognition), motion detection 2.0, people counting, and video structuralization powered by AI at both NVR and camera level.

Comprehensive Facial Recognition and Image Library Management

The system supports up to 16 face picture libraries and a total of 50,000 stored face images, facilitating efficient search, comparison, and analytics. Up to 8 channels of real-time face comparisons and 4 channels of high-definition face capture are supported, enhancing security operations in sensitive environments.

Full-Function Multi-Language Search and ANPR Coverage

With support for a wide range of languages and country-specific ANPR databases, the device ensures fast vehicle plate recognition and detailed attribute analysis (plate, brand, color, type) for global deployment in a variety of regulatory environments.

Certified Performance for Diverse Applications

Certified to major international standards (CE, CB, REACH, etc.), the NVR operates reliably from -10°C to 55°C with low power consumption. Enhanced compatibility, secure data storage, and dual-stream recording ensure consistent, high-quality video management in commercial and industrial environments.

Specifications

Intelligent Analytics

AI by NVR

Facial recognition

AI by NVR and Camera

Facial recognition, perimeter protection, video structuralization, AcuSearch, motion detection 2.0, ANPR, people counting, AcuSeek

Engine

2 engines. 1 is for face picture and AcuSearch. 1 is for AcuSeek

Facial Recognition

Face Picture Library

Up to 16 face picture libraries, with up to 50,000 face pictures in total (each picture ≤ 512 KB, total capacity ≤ 1 GB)

Face Picture Comparison

8-ch

Facial Detection and Analytics

Face picture comparison, human face capture, face picture search

Facial Detection and Analytics Performance

4-ch human face capture (HD network camera, up to 8 MP, H.264/H.265)

AcuSearch

Performance

If the cameras support Hikvision AcuSense Technology and have enabled AcuSearch function, the NVR supports AcuSearch in all channels, capable of modeling 300,000 targets/day.

AcuSeek

Performance

If the cameras support Hikvision AcuSense Technology and have enabled AcuSearch function, the NVR supports AcuSeek in all channels, capable of modeling 300,000 targets/day.

Search Language

English, French, Italian, German, Polish, Portuguese, Thai, Russian, Arabic, Turkish, Spanish, Dutch, Romanian, Czech, Swedish, Croatian, Latvian, Ukrainian, Hungarian, Danish, Japanese, Korean, Vietnamese, Indonesian, Brazilian Portuguese, Traditional Chinese

ANPR

By Camera

All channels

Support Countries & Regions

1. Myanmar, Philippines, Indonesia, Vietnam, Pakistan, New Zealand, Australia, Sri Lanka, Singapore, Malaysia

2. Turkey, Croatia, Slovakia, Czech Republic, Bulgaria, Macedonia, Hungary, Greece, Poland, France, Netherlands, Switzerland, Spain, The United Kingdom, Ireland, Germany, Italy, Austria, Palestine, Latvia, Lithuania, Estonia, Belgium, Luxembourg, Ukraine, Uzbekistan, Kazakhstan, Mongolia, Moldova, Kyrgyzstan, Azerbaijan, Georgia, Armenia, Albania, Kosovo, Belarus, Cyprus, Denmark, Finland, Malta, Portugal, Romania, Slovenia, Sweden, Israel, Bosnia and Herzegovina, Turkmenistan, Montenegro, Serbia, Tajikistan, Iceland, Liechtenstein

3. Argentina, Brazil, Chile, Colombia, Peru, Ecuador, Paraguay, Uruguay, Salvador, Bolivia, Canada, Algeria, Mexico, Panama, Costa Rica, Nigeria, Kenya, Mauritius, Tanzania, Cote d'Ivoire, South Africa, Tunisia, Sierra Leone, Zambia, Ghana, Zimbabwe, Uganda, Angola, Ethiopia, Republic of Trinidad and Tobago, Dominica, Guatemala, Senegal, Algeria, Cameroon

4. Qatar, Kuwait, Oman, Jordan, Lebanon, Iraq, United Arab Emirates, Saudi Arabia, Bahrain, Egypt, Libya

Vehicle Attributes

Plate number, license plate color, license plate type

Plate Attributes

Vehicle brand, vehicle color, vehicle type

Video and Audio

IP Video Input

Incoming Bandwidth

384 Mbps

Outgoing Bandwidth

256 Mbps

HDMI Output

HDMI1: 4K (3840 × 2160) / 30 Hz, 2K (2560 × 1440) / 60 Hz, 1920 × 1080 / 60 Hz, 1280 × 720 / 60 Hz

HDMI2: 1920 × 1080 / 60 Hz, 1280 × 720 / 60 Hz

VGA Output

1920 × 1080/60Hz, 1280 × 720/60Hz

Video Output Mode

HDMI/VGA independent output

CVBS Output

Audio Output

1-ch, RCA (Linear, 1 KΩ)

Two-Way Audio

1-ch, RCA (2.0 Vp-p, 1 KΩ)

Decoding

Decoding Format

H.265, H.265+, H.264, H.264+, MPEG4

Recording Resolution

32MP/24MP/12MP/8MP/7MP/6MP/5MP/4MP/3MP/1080p/UXGA/720p/VGA/4CIF/DCIF/2CIF/CIF/QCIF

Synchronous playback

16-ch

Dual-Stream Recording

Support

Live View Window Division

1/4/6/8/9/16/25/36

Aux Port Window Division

1/4/6/8/9/16/25/36

Stream Type

Video, Video & Audio

Decoding Capability

Enable AI by NVR: 20-ch@1080p (30 fps)

Disable AI by NVR: 32-ch@1080p (30 fps)

Audio Compression

G.711ulaw, G.711alaw, G.722, G.726, MP2L2

Network

Network Interface

1, RJ-45 10/100/1000 Mbps self-adaptive Ethernet interface

PoE

Interface

16, RJ-45 10/100 Mbps self-adaptive Ethernet interface

Power

≤ 200W

Standard

IEEE 802.3 af/at

Auxiliary Interface

SATA

4 SATA interfaces

Capacity

Up to 20 TB capacity for each disk

Serial Interface

2 RS-485 (half-duplex), 1 RS-232

Alarm In/Out

16/9

USB Interface

Front panel: 2 × USB 2.0; Rear panel: 1 × USB 3.0

General

Power Supply

≤ 360 W

Consumption

≤ 50W

Working Temperature

-10℃～＋55℃

Working Humidity

10％～90％

Chassis

1.5U

Dimension (W × D × H)

440 x 391 x 72 mm（17.32" x 15.39" x 2.81"）

Weight

≤5 kg (without HDD, 11.02 lb.)

Certification

Obtained Certification

CE, CB, REACH, WEEE, UKCA, RCM,IC,LOA,KC

EN 55032:2015, EN 61000-3-2, EN 61000-3-3, EN 50130-4

Manufacturer Part No:

303623247

Brand:

HIKVISION

Product Type:

UPC

Product Family:

Shipping Weight:

1 kg

PB Part No:

CCTHIK303623247

Product Model:

DS-7732NXI-I4/16P/VPro
