HIKVISION 6 SERIES IP VILLA DOOR STATION -PLASTIC

This product can only be sold to limited liability companies, local councils, government departments and schools. A limited liability company name or valid council, government department or school name must be entered during the checkout process.

HIKVISION 6 SERIES IP VILLA DOOR STATION -PLASTIC

  • Brand: HIKVISION
  • MPN: 305303443
  • Part #: CCTHIK305303443
  • UPC:
NEW ARRIVAL
No store stock available.

Click & Collect: Select your store to check availability
Delivery: Order now and it ships on 20 Nov When will I receive it?
Sign in to your commercial account or apply online now to view the price and order this product

Features

POE/Wifi Villa Door Station

- 2 MP camera with IR supplement
- One-touch button calling design for easier calls
- Built-in card reader module
- Standard PoE power supply
- IP65 protection level
- Convenient Hik-Connect APP Mobile Control

Integrated 2MP Camera with Infrared for Day & Night Monitoring

This door station is equipped with a 2-megapixel HD camera and built-in infrared supplement, ensuring clear video communication and visitor identification even in low-light or nighttime conditions.

Simple One-Touch Call Button for User-Friendly Operation

A prominent single button on the panel allows visitors fast and easy call initiation, making the door entry process straightforward for users of all ages.

Built-In Card Reader Enhances Access Control

The integrated card reader module supports convenient card-based entry, adding a layer of secure, streamlined access management for authorized residents and staff.

Standard PoE Power for Effortless Installation

Compliance with standard Power over Ethernet (PoE) simplifies cable routing and power supply. This reduces installation costs while enhancing system reliability.

Durable Plastic Housing with Reliable IP65 Protection

The plastic enclosure is engineered for weather and dust resistance, rated IP65, which means the device is protected against rain and dust intrusion, suitable for varied outdoor environments.

Remote Management via Hik-Connect Mobile App

Users benefit from remote video answering, call records, and door unlocking through Hik-Connect mobile app, providing convenient and secure management from anywhere.

Specifications

System parameters

Operation system

Linux

ROM

32 MB

RAM

256 MB

Processor

Embeded high performance processor

Video parameters

Lens

1

Resolution

Main stream: 1920 × 1080p, 720p
Sub stream: 640 × 480p

FOV

Horizontal: 131° Vertical: 78°

Wide dynamic range (WDR)

Support 120 dB

Supplement light

IR light, up to 3 m

Video compression standard

H.264; H.265; MJPEG

Audio parameters

Audio input

1 built-in omnidirectional microphone

Audio compression standard

G.711 U、G.711 A、Opus、AAC-LD、AAC-LC、G.726、G.722.1

Audio output

1 built-in loudspeaker

Audio compression bitrate

64 Kbps

Audio quality

Noise suppression and echo cancellation

Volume adjustment

Adjustable

Capacity

User capacity

2000

Face capacity

/

Card capacity

10000

Network parameters

Network protocol

TCP/IP, RSTP, IPV6, ONVIF

Wi-Fi

IEEE802.11b, IEEE802.11g, IEEE802.11n

Bluetooth

Not supported.

3G/4G

/

Device interfaces

Alarm input

4

Network interface

1 RJ-45, 10/100 Mbps self-adaptive

TAMPER

1

Exit button

1

RS-485

1

USB

/

Wiegand

/

TF card

Reserved

Alarm output

/

Lock control

1 relay, Max. 30 VDC 2 A

Door contact input

1

General

Button

1 physical button

Installation

Surface mounting

Indicator

2

Net weight

0.190 kg

Protective level

IP65

Working temperature

-40 °C to 55 °C(-40 °F to 131 °F)

Working humidity

10% to 95% (no-condensing)

Dimension (W × H × D)

138 mm × 65 mm × 27 mm (5.4" × 2.6" × 1.1")

Battery

/

Application environment

Outdoor

Power consumption

< 10 W

Language

English, Arabic, European French, Russian, European Spanish, Latin American Spanish, Italian, German, Polish, Turkish, Portuguese, Brazilian Portuguese, Uzbek, Kazakh, Czech, Hungarian, Dutch, Romanian, Bulgarian, Ukrainian, Croatian, Serbian, Greek, Lithuanian, Estonian, Latvian, Norwegian, Danish, Slovenian, Slovak, Hebrew, Swedish, Finnish, Mongolian, Vietnamese, Traditional Chinese (Taiwan), Latin American Spanish

Power supply

12 VDC,Standard PoE, af

Manufacturer Part No:
305303443
Brand:
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
2 kg
PB Part No:
CCTHIK305303443
Product Model:
-
Warranty: 12 months *
