Features
316L 4MP 31x Explosion-proof Network Speed Dome
- High quality imaging with 4 MP resolution
- 1/1.8" progressive scan CMOS
- Min. illumination：Color: 0.005Lux @(F1.5, AGC ON) B/W: 0.001 Lux @(F1.5, AGC ON)
- 31× optical zoom, focal length 5.9 mm to 182.9 mm
- Efficient H.265+/H.265 compression technology
- Water and dust resistant (IP68)
- 3D DNR and low bitrate technology delivers clean and sharp images
- Clear imaging against strong back light due to 120 dB true WDR technology
Explosion-Proof and Durable Stainless Steel Construction
The dome camera adopts a robust 316L stainless steel body with anti-corrosion spray treatment. Certified to ATEX & IECEx explosion-proof standards, it is designed for operation in hazardous areas and offers NEMA 4X protection for longevity in harsh environments.
4MP Ultra-Clear Imaging for Security-Critical Applications
Equipped with a high-sensitivity 1/1.8" progressive scan CMOS sensor, the camera delivers 2560 × 1440 resolution imaging, with true color down to 0.005 Lux and sharp black-and-white in near darkness.
Powerful 31x Optical Zoom for Detailed Surveillance
With a broad 31× optical zoom (5.9mm-182.9mm) and 16× digital zoom, users can capture both wide fields and remote detail with smooth, fast zoom and accurate autofocus in safety-critical and industrial zones.
Superior Video and Audio Performance
High-efficiency H.265+/H.265 compression, 3D digital noise reduction, 120dB true WDR for backlight compensation, and versatile streaming support high-quality, low-bitrate recording and live viewing. The dome features environment noise filtering and supports multiple audio codecs and two-way audio.
Comprehensive PTZ and Intelligent Detection Functions
Full 360° endless pan, up to 300 presets, eight patrols, pattern scans, and automated scheduled tasks support rapid response and precise area control. Smart events include intrusion/line crossing/object removal detection and up to 10 simultaneous face captures.
Reliable Network Integration and Multi-Tier Protection
Compatible with all major network protocols, featuring extensive alarm/input/output interfaces, local microSD storage (up to 256GB), IP68 ingress protection, lightning and surge protection, and certified suitability for explosive gas and dust atmospheres.
Specifications
Reviews
Delivery & Pick-up
Delivery Estimates
The estimated time to ship for each product we sell is detailed on the individual product page just underneath the price. From when your items ship, products typically arrive within 1-2 working days for North Island deliveries and 2-3 working days for South Island deliveries. Rural deliveries may take an extra working day. Bulk & hazard deliveries may take an extra 2-7 working days.
Next Day Delivery
Need your order in a hurry? PB Tech offers next day delivery for local Auckland addresses. Simple place your order before 4pm (provided your items are in stock) and select our next day delivery option in the checkout. T&C's apply. Learn more about Next Day Delivery.
Same Day Delivery
Need your order in a hurry? PB Tech offers same day delivery for Auckland, Hamilton, Wellington and Christchurch. Simple place your order before 1pm (provided your items are in stock) and select one of our same day delivery options 'Evening Delivery' or 'Urgent 3-hour Delivery' in the checkout. T&C's apply. Learn more about Same Day Delivery.
Shipping Costs
Shipping costs vary based on your location and the items being shipped and in some cases shipping may even be FREE.
To calculate what the shipping costs will be for your order, add the items you are interested in to your cart, view the Shopping Cart page, and select your 'Delivery Area' to calculate the shipping cost.
Shipping Security & Insurance
All orders shipped by PB Tech are sent via a courier with a signature required for each delivery. In some cases, and only where you have given the courier company permission to leave orders at a designated location, your order may be delivered without requiring a signature. All orders sent by PB Tech are fully insured in the unlikely event that your item(s) are damaged or go missing in transit.
1 Hour Store Pick-up / Click & Collect
You can pick-up your online order from any of our stores nationwide. You can select which store you want to pick up from at the checkout. Provided the store you select has stock and there's no hold-ups with payment we will have your order ready within 1 hour (during normal trading hours for that store) otherwise it may take up to 5 working days to transfer the stock to the store so your order can be fulfilled. Learn more about our Click & Collect process.
Overseas Shipments
PB Tech regularly ships overseas to Australia and beyond. If you are located in Australia, you can order directly from our Australian site www.pbtech.com/au. If you are from another country you can order from www.pbtech.com
Returns & Warranty
Popular Wired IP Cameras
Ubiquiti UniFi Protect UVC-G5-Turret-Ultra 4MP/2K Turret PoE...
Reolink TrackMix PoE 8MP/4K Dual-Lens Outdoor PTZ PoE Camera with...
EZVIZ H9c 5MP/3K Dual-Lens Outdoor Wireless PT Camera with...
Ubiquiti UniFi Protect UVC-G6-Bullet 8MP/4K Bullet PoE Camera ...
Reolink Duo 2 PoE 8MP/4K Dual-Lens Outdoor PoE Camera with...
HIKVISION 327000812 HIK Explosion-Proof 4MP 31x 316SS PTZ ATEX & IECEx cw Wmount
- Brand: HIKVISION
- MPN: 327000812
- Part #: CCTHIK327000812
Product URL: https://www.pbtech.co.nz/product/CCTHIK327000812/HIKVISION-327000812-HIK-Explosion-Proof-4MP-31x-31
| Branch | New Stock | On Display |
|---|---|---|
| Auckland - Albany | 0 | |
| Auckland - Glenfield | 0 | |
| Auckland - Queen Street | 0 | |
| Auckland - Auckland Uni | 0 | |
| Auckland - Westgate | 0 | |
| Auckland - Penrose | 0 | |
| Auckland - Henderson (Express) | 0 | |
| Auckland - St Lukes | 0 | |
| Auckland - Manukau | 0 | |
| Hamilton | 0 | |
| Tauranga | 0 | |
| New Plymouth | 0 | |
| Palmerston North | 0 | |
| Petone | 0 | |
| Wellington | 0 | |
| Auckland - Head Office | 0 | |
| Auckland - East Tamaki Warehouse | 0 | |
| Christchurch - Hornby | 0 | |
| Christchurch - Christchurch Central | 0 | |
| Dunedin | 0 |
Features
316L 4MP 31x Explosion-proof Network Speed Dome
- High quality imaging with 4 MP resolution
- 1/1.8" progressive scan CMOS
- Min. illumination：Color: 0.005Lux @(F1.5, AGC ON) B/W: 0.001 Lux @(F1.5, AGC ON)
- 31× optical zoom, focal length 5.9 mm to 182.9 mm
- Efficient H.265+/H.265 compression technology
- Water and dust resistant (IP68)
- 3D DNR and low bitrate technology delivers clean and sharp images
- Clear imaging against strong back light due to 120 dB true WDR technology
Explosion-Proof and Durable Stainless Steel Construction
The dome camera adopts a robust 316L stainless steel body with anti-corrosion spray treatment. Certified to ATEX & IECEx explosion-proof standards, it is designed for operation in hazardous areas and offers NEMA 4X protection for longevity in harsh environments.
4MP Ultra-Clear Imaging for Security-Critical Applications
Equipped with a high-sensitivity 1/1.8" progressive scan CMOS sensor, the camera delivers 2560 × 1440 resolution imaging, with true color down to 0.005 Lux and sharp black-and-white in near darkness.
Powerful 31x Optical Zoom for Detailed Surveillance
With a broad 31× optical zoom (5.9mm-182.9mm) and 16× digital zoom, users can capture both wide fields and remote detail with smooth, fast zoom and accurate autofocus in safety-critical and industrial zones.
Superior Video and Audio Performance
High-efficiency H.265+/H.265 compression, 3D digital noise reduction, 120dB true WDR for backlight compensation, and versatile streaming support high-quality, low-bitrate recording and live viewing. The dome features environment noise filtering and supports multiple audio codecs and two-way audio.
Comprehensive PTZ and Intelligent Detection Functions
Full 360° endless pan, up to 300 presets, eight patrols, pattern scans, and automated scheduled tasks support rapid response and precise area control. Smart events include intrusion/line crossing/object removal detection and up to 10 simultaneous face captures.
Reliable Network Integration and Multi-Tier Protection
Compatible with all major network protocols, featuring extensive alarm/input/output interfaces, local microSD storage (up to 256GB), IP68 ingress protection, lightning and surge protection, and certified suitability for explosive gas and dust atmospheres.
Specifications
Camera
Image Sensor
1/1.8" progressive scan CMOS
Max. Resolution
2560 × 1440
Min. Illumination
Color: 0.005 Lux @ (F1.5, AGC ON)
B/W: 0.001 Lux @ (F1.5, AGC ON)
Shutter Speed
1/1 s to 1/30,000 s
Day & Night
IR Cut Filter
Zoom
31 × optical, 16 × digital
Slow Shutter
yes
Lens
Focal Length
5.9 mm to 182.9 mm, 31 × optical zoom
FOV
Horizontal field of view: 60.2° to 2.5° (wide-tele)
Vertical field of view: 35.2° to 1.3° (wide-tele)
Diagonal field of view: 67.4° to 2.7° (wide-tele)
Focus
semi-auto, manual, auto
Aperture
F1.5
Zoom Speed
Approx. 7 s (Optical Lens, Wide-Tele)
PTZ
Movement Range (Pan)
360° endless
Movement Range (Tilt)
From 0° to 90° (Auto Flip)
Pan Speed
Pan speed: configurable from 0.1° to 100°/s, preset speed: 100°/s
Tilt Speed
Tilt speed: configurable from 0.1° to 50°/s, preset speed 50°/s
Proportional Pan
yes
Presets
300
Preset Freezing
yes
Patrol Scan
8 patrols, up to 32 presets for each patrol
Pattern Scan
4 pattern scans, record time over 10 minutes for each scan
Park Action
Preset/Pattern Scan/Patrol Scan/Auto Scan/Tilt Scan/Random Scan/Frame Scan/Panorama Scan
3D Positioning
yes
PTZ Status Display
yes
Scheduled Task
Preset, pattern scan, patrol scan, auto scan, tilt scan, random scan, frame scan, panorama scan, dome reboot, dome adjust, aux output
Power-off Memory
yes
Video
Main Stream
50 Hz: 25 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
60 Hz: 30 fps (2560 × 1440, 1920 × 1080, 1280 × 960, 1280 × 720)
Sub-Stream
50 Hz: 25 fps (704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (704 × 480, 640 × 480, 352 × 240)
Third Stream
50 Hz: 25 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 576, 640 × 480, 352 × 288)
60 Hz: 30 fps (1920 × 1080, 1280 × 960, 1280 × 720, 704 × 480, 640 × 480, 352 × 240)
Video Bit Rate
32 kbps to 16384 kbps
H.264 Type
Baseline profile, Main profile, High profile
H.265 Type
main profile
Scalable Video Coding (SVC)
yes
Region of Interest (ROI)
yes
Target Cropping
no
Audio
Audio Compression
G.711alaw/G.711ulaw/G.722.1/G.726/MP2L2/PCM
Audio Bit Rate
G.722.1: 16Kbps, G.711ulaw: 64 kbps, G.711alaw: 64 kbps, MP2L2: 32 kbps, 40 kbps, 48 kbps, 56 kbps, 64 kbps, 80 kbps, 96 kbps, 112 kbps, 128 kbps, 144 kbps, 160 kbps, 192 kbps
Audio Sampling Rate
MP2L2: 16kHz, 32kHz, 48kHz, PCM: 8kHz, 16kHz, 32kHz, 48kHz
Environment Noise Filtering
yes
Network
Protocols
IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTCP, RTP, TCP/IP, UDP, IGMP, ICMP, DHCP, PPPoE, Bonjour
Simultaneous Live View
Up to 20 channels
API
Open Network Video Interface (Profile S, Profile G, Profile T), ISAPI, SDK
User/Host
Up to 32 users. 3 levels: Administrator, Operator and User
Security
User authentication (ID and PW), Host authentication (MAC address); HTTPS encryption; IEEE 802.1x port-based network access control; IP address filtering
Network Storage
NAS (NFS, SMB/CIFS), auto network replenishment (ANR)
Client
iVMS-4200, iVMS-4500, iVMS-5200, Hik-Connect
Web Browser
IE11, Chrome 57.0+, Firefox 52.0+, Safari 11+
Image Parameters Switch
yes
Image Settings
saturation, brightness, sharpness, contrast
Day/Night Switch
auto
Wide Dynamic Range (WDR)
120 dB
SNR
>52dB
Defog
yes
Image Enhancement
HLC/BLC/3D DNR/EIS/Regional Exposure/Regional Focus
Privacy Mask
up to 24 masks
Interface
Ethernet Interface
RJ45, self-adaptive 10M/100M Ethernet port
On-board Storage
support microSD/microSDHC/microSDXC cards, up to 256 GB
Audio
1-ch audio input and 1-ch audio output
Alarm
7-ch alarm input and 2-ch alarm output
RS-485
HIKVISION, Pelco-P, Pelco-D, self-adaptive
Event
Basic Event
Motion detection, video tampering alarm, alarm input and output, exception (IP address conflict, HDD full, illegal login, HDD error, network disconnected, Abnormal Reboot)
Smart Event
intrusion detection, line crossing detection, region entrance detection, region exiting detection, unattended baggage detection, object removal detection, audio exception detection
Linkage
Alarm actions, such as Preset, Patrol Scan, Pattern Scan, Memory Card Video Record, Trigger Recording, Notify Surveillance Center, Upload to FTP/Memory Card/NAS, Send Email, etc.
Smart Linkage
manual tracking, event tracking
Deep Learning Function
Face Capture
1. Detects up to 10 faces simultaneously
2. Uploads face with background and closed-up face pictures
3. Support detecting, tracking, capturing, grading, selecting of face in motion, and output the best face picture of the face
General
Power
100 VAC to 240 VAC, Max.: 60 W
Dimension
Φ 255 mm × 405 mm（Φ 10" × 15.9")
Weight
13.2 kg (29.11 lb.)
Material
SUS316L with anti-corrosion surface spray treatment
Operating Condition
Temperature: -40°C to 60°C (-40°F to 140°F)，Humidity: ≤ 95%
Cable Length
1.95 m (6.40 ft.)
General Function
mirror, password protection, watermark, IP address filter
Demist
Demist by heating the glass
Power Consumption and Current
Max. 60 W
Approval
EMC
FCC (47 CFR Part 15, Subpart B); CE-EMC (EN 55032: 2015, EN 61000-3-2: 2014, EN 61000-3-3: 2013, EN 50130-4: 2011 +A1: 2014); RCM (AS/NZS CISPR 32: 2015); IC (ICES-003: Issue 6, 2016); KC (KN 32: 2015, KN 35: 2015)
Safety
UL (UL 62368-1); CB (IEC 60950-1:2005 + Am 1:2009 + Am 2:2013); CE-LVD (EN 62368-1:2014+A11:2017); BIS (IS 13252 (Part 1):2010+A1:2013+A2:2015); LOA (IEC/EN 60950-1)
Protection
IP68, 4000V Lightning Protection, Surge Protection and Voltage Transient Protection
Explosion-Proof Protection
ATEX: Ex II 2GD Ex db IIC T6 Gb /Ex tb IIIC T80℃ Db, IECEx: Ex db IIC T6 Gb /Ex tb IIIC T80℃ Db
For explosive gas atmospheres, the maximum surface temperature is 85°C;
For flammable dust atmospheres, the maximum surface temperature is 80°C;
IIC: for explosive gas atmospheres other than mines susceptible to firedamp;
For explosive gas mixture atmospheres: Zone 1, Zone 2, Zone 21, Zone 22.
Anti-Corrosion Protection
NEMA 4X (NEMA 250-2018)
