NZXT RGB and Fan Controller 3x Fan Splitter upto 9 3-Pin DC or 4-Pin PWM fans, 6x NZXT RGB Lighting Channels
Out of stock
NZXT RGB and Fan Controller 3x Fan Splitter upto 9 3-Pin DC or 4-Pin PWM fans, 6x NZXT RGB Lighting Channels
- Brand: NZXT
- MPN: AC-CRFR0-B1
- Part #: CHSNZX0017
- UPC: 810074840835
What PB Tech customers are saying about this product...
See More Reviews"Good for NZXT build sync all rgb lights together"
"Purchased on sale. Item as described. Fast shipping and easy online purchase. Was exactly what my son needed to get all his fans up and running."
"A great choice!"
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Related Promotions
Popular PC Case Accessories





NZXT RGB and Fan Controller 3x Fan Splitter upto 9 3-Pin DC or 4-Pin PWM fans, 6x NZXT RGB Lighting Channels
- Brand: NZXT
- MPN: AC-CRFR0-B1
- Part #: CHSNZX0017
- UPC:810074840835

Product URL: https://www.pbtech.co.nz/product/CHSNZX0017/NZXT-RGB-and-Fan-Controller-3x-Fan-Splitter-upto-9
Branch | New Stock | On Display |
---|---|---|
Albany | 0 | |
Glenfield | 0 | |
Queen Street | 0 | |
Auckland Uni | 0 | |
Newmarket | 0 | |
Westgate | 0 | |
Penrose | 0 | |
Henderson (Express) | 0 | |
St Lukes | 0 | |
Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Head Office | 0 | |
Hornby | 0 | |
Christchurch Central | 0 |
Features
RGB & Fan Controller
RGB Lighting & Digitally-Controlled Fan Channels
The RGB & Fan Controller combines optimal fan control, RGB lighting customization, and convenient installation-all in an intuitive and easy-to-use package.
- Control up to nine 3-pin DC or 4-pin PWM fans, allowing Zero RPM mode to optimize noise levels.
- Six NZXT RGB lighting channels, up to 40 individually addressable LEDs per channel, 120 LEDs total.
- The Fan Controller can be installed directly to the PC via SATA and an internal USB header.
Specifications
Inside the Box
RGB & Fan Controller x1
Fan Splitter Cables x3
Velcro x2
DIMENSIONS
Height
100mm
Width
70mm
Depth
16mm
OUTPUT CHANNELS
RGB Lighting Channels
6
Fan Channels
3
INPUT CONNECTOR
Lighting
5 V DC 4.5 A
Fans
12 V DC 3 A
Lighting channels support
Max 40 LED per channel and Max 120 LED combined total for All 6 channels
System Requirements
PC with available internal USB 2.0 header, Windows 11/10 operating system, and CAM software
CONNECTION CABLES
USB 2.0 Header
1
SATA Power Cable
1
Fan splitter cables (1-3 split)
3
GENERAL
Model Number
AC-CRFR0-B1
