Intel Xeon Silver 4514Y CPU
16 Core / 32 Thread - 2.0GHz - 30MB Cache - LGA 4677 - 150W TDP - 2S
Out of stock
Intel Xeon Silver 4514Y CPU
16 Core / 32 Thread - 2.0GHz - 30MB Cache - LGA 4677 - 150W TDP - 2S
- Brand: Intel
- MPN: BX807224514Y
- Part #: CPUITXBS4514Y
- UPC: 735858548397
- Brand: Intel
- MPN: BX807224514Y
- Part #: CPUITXBS4514Y
- UPC: 735858548397
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Related Promotions
Popular CPU / Processors





Intel Xeon Silver 4514Y CPU 16 Core / 32 Thread - 2.0GHz - 30MB Cache - LGA 4677 - 150W TDP - 2S
- Brand: Intel
- MPN: BX807224514Y
- Part #: CPUITXBS4514Y
- UPC:735858548397

Product URL: https://www.pbtech.co.nz/product/CPUITXBS4514Y/Intel-Xeon-Silver-4514Y-CPU-16-Core--32-Thread---2
Branch | New Stock | On Display |
---|---|---|
Auckland - Albany | 0 | |
Auckland - Glenfield | 0 | |
Auckland - Queen Street | 0 | |
Auckland - Auckland Uni | 0 | |
Auckland - Newmarket | 0 | |
Auckland - Westgate | 0 | |
Auckland - Penrose | 0 | |
Auckland - Henderson (Express) | 0 | |
Auckland - St Lukes | 0 | |
Auckland - Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Auckland - Head Office | 0 | |
Auckland - East Tamaki Warehouse | 0 | |
Christchurch - Hornby | 0 | |
Christchurch - Christchurch Central | 0 | |
Dunedin | 0 |
Features
Intel® Xeon® Silver Processor
Intel® Xeon® Silver processors deliver essential performance, improved memory speed, low latency, and power efficiency. They offer the hardware-enhanced performance required for entry-level data center compute, network, and storage.
Built-in Intel Accelerators for Performance and Security
Intel® QuickAssist Technology (Intel® QAT)
Accelerate data compression and encryption while freeing up processor cores to reduce system resource consumption and TCO.
Intel® Advanced Matrix Extensions (Intel® AMX)
Accelerate your CPU's AI capabilities with improved deep learning training and inference performance.
Intel® Trust Domain Extensions (Intel® TDX)
Increase confidentiality at the virtual machine (VM) level while enhancing privacy and control over your data.
See All Accelerator Engines
Boost performance, reduce costs, and improve power efficiency for demanding workloads with built-in Intel® Accelerator Engines.
Confidently Deploy Common and Emerging Workloads
Whether it is empowering solid foundations for AI innovation and HPC, supporting critical workloads at the edge, building a secure cloud, or helping professionals stay productive, there is an Intel Xeon processor designed to meet your organization's computing needs.
Specifications
Essentials
Product Collection
5th Generation Intel® Xeon® Scalable Processors
Code Name
Products formerly Emerald Rapids
Vertical Segment
Server
Processor Number
4514Y
Lithography
Intel 7
CPU Specifications
Total Cores
16
Total Threads
32
Max Turbo Frequency
3.4 GHz
Processor Base Frequency
2 GHz
Cache
30 MB
Intel® UPI Speed
16 GT/s
Max # of UPI Links
2
TDP
150 W
Intel® Speed Select Technology - Performance Profile (Intel® SST-PP)
Config - Active Cores - Base Frequency - TDP
4514Y (0) - 16 - 2.0 - 150
4514Y (1) - 12 - 2.1 - 135
4514Y (2) - 8 - 2.6 - 135
Supplemental Information
Embedded Options Available
Yes
Use Conditions
Server/Enterprise
Memory Specifications
Max Memory Size (dependent on memory type)
4 TB
Memory Types
Up to DDR5 4400 MT/s (1DPC & 2DPC)
Max # of Memory Channels
8
ECC Memory Supported
Yes
Expansion Options
Scalability
2S
PCI Express Revision
5.0
Max # of PCI Express Lanes
80
Package Specifications
Sockets Supported
FCLGA4677
Package Carrier
E1B
DTS Max
90 °C
TCASE
79
Package Size
77.5mm x 56.5mm
Advanced Technologies
Intel® On Demand Activation Model
Yes
Intel® Data Streaming Accelerator (DSA)
1 default devices
Intel® Advanced Matrix Extensions (AMX)
Yes
Intel® Speed Select Technology - Core Power
Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU
Yes
High Priority Cores
NA
Intel® Resource Director Technology (Intel® RDT)
Yes
Intel® Speed Shift Technology
Yes
Intel® Turbo Boost Technology
2.0
Intel® Hyper-Threading Technology
Yes
Intel® Transactional Synchronization Extensions
Yes
Intel® 64
Yes
Instruction Set Extensions
Intel® AMX, Intel® SSE4.2, Intel® AVX, Intel® AVX2, Intel® AVX-512
# of AVX-512 FMA Units
2
Intel® Volume Management Device (VMD)
Yes
Security & Reliability
Intel® Trust Domain Extensions (Intel® TDX)
Yes
Intel® Crypto Acceleration
Yes
Intel® QuickAssist Software Acceleration
Yes
Intel® Platform Firmware Resilience Support
Yes
Intel® Control-Flow Enforcement Technology
Yes
Intel® Total Memory Encryption - Multi Key
Yes
Intel® Total Memory Encryption
Yes
Intel® AES New Instructions
Yes
Intel® Software Guard Extensions (Intel® SGX)
Yes with Intel® SPS
Default Maximum Enclave Page Cache (EPC) Size for Intel® SGX
64 GB
Intel® OS Guard
Yes
Intel® Trusted Execution Technology
Yes
Execute Disable Bit
Yes
Intel® Boot Guard
Yes
Mode-based Execute Control (MBEC)
Yes
Intel® Virtualization Technology (VT-x)
Yes
Intel® Virtualization Technology for Directed I/O (VT-d)
Yes
Intel® VT-x with Extended Page Tables (EPT)
Yes
