Aurora IPX-TCW3-C-W 4K Transceiver Wall Plate

Aurora IPX-TCW3-C-W 4K Transceiver Wall Plate

PB Tech price:PB Tech price:
$2,08957$2,40301
 +GST  inc GST

Store Pickup: Select your store to check availability
Delivery: Order now and it ships on 29/08/2019
When will I receive it?

Finance from $21.28 per week*

No payments or interest for 12 months available

Features

Utilizing Aurora's IPBaseT® technology, which combines various IP/AV standards to work together as one, the IPX-TCW3 Series provides one of the most advanced IP Streaming solutions on the market. It is the industry's first 4K2K IP wall plate with zero compression and latency based on BlueRiver NT™ platform. Using a transmitter (encoder) and receiver (decoder), respectively, used to be the standard - until now. The IPX-TCW3 Series can be set up as either one to make installation, inventory, and troubleshooting easier.

Another industry first is the option slot to add other IP capabilities, like ExtremeUSB® (USB 2.0 over IP) or Dante® audio, for a more complete, distributed system. Audio, video, data, and control can be sent securely to one or many IPX-TCW3 transceiver units using off-the-shelf 10G Fiber or CAT Ethernet switches.

When the IPX-TCW3 is set up to be a transmitter, the 2 HDMI inputs become a source switch and the HDMI output becomes a potential loop out. When set up as a receiver, a user can select the local HDMI inputs or an IP source. Seamless switching of the sources further enhances the presentation. Regardless of how the IPX-TCW3 is set up, the audio can be de-embedded at any location, break away, and/or be sent to or received from a Dante® enabled device. The USB 2.0 option is also flexible, working as a KVM and/or a high-speed data transfer (480Mbps) for memory sticks.

- Configure as Transmitter (Encoder) or Receiver (Decoder)
- 4K2K Over 10G Fiber (-F) or 10G CAT (-C)
- Zero Compression & Zero Latency
- Secure Content Encryption
- 128x128 Capable with HDCP, Larger for Non-Encrypted Sources
- Videowall Capability with Zero Latency
- Seamless & Break-away Switching
- SFP+ for Multi/Single Mode Fiber (-F Model)
- 1G LAN PoE
- 2 HDMI Inputs, 1 HDMI Output
- Line In/Out Stereo
- RS-232 Serial Port & IR (Bidirectional)
- User Configurable OSD
- Integrated Web Server for Custom Control Pages
- ExtremeUSB® - USB 2.0 480Mbps Option (Host or Device Configurable)
- Dante® IP Audio Option
- Programmable Front Buttons
- Auto Sense Switching
- Standard 3 Gang Outlet Box
- Low Depth for Floor & Table Boxes
- Available in White or Black

IPX control is available via our IPBaseT Manager Windows® software, or the QXP-2-IPX.

Choice is important. That's why the IPX-TCW3-F has an SFP+ port that can use single or multi-mode fiber and the unit can use Category 5e/6/6A - making it the ultimate AV IP product on the market today.

Note: The selected network switch needs to support:  10Gbps, Non-blocking IGMP.

*Patent Pending

USE THE FOLLOWING PART NUMBERS FOR ORDERING:
IPX-TCW3-F-B (White)**
IPX-TCW3-F-B (Black)**
**10G Fiber
IPX-TCW3-C-B (White)***
IPX-TCW3-C-B (Black)***
***10G Copper

Power Supply NOT included, please order separately.

Specifications

Video

Compression

Zero

Latency

Zero

HDMI Inputs

2

HDMI Outputs

1

Audio Analog

Stereo Line In/Out (3.5mm TRS)

10G Fiber Ethernet

SFP+ (Single Mode or Multi-Mode)

10G Copper Ethernet

RJ-45 330ft with CAT 6A

LAN

RJ-45 10/100/1000M PoE (PSE)

Video Bandwidth

340MHz

Video support

Up to 4K2K 4:2:0 @60Hz

Audio support

Up to 32 channels & Break-away Capable

RS-232

Up to 115k Baud (3.5mm TRS)

IR

Bi-Directional (3.5mm TRS)

USB Connector

USB 2.0 Type A (Host or Device Software Selectable)

Expansion Port

SO-DIMM for ExtermeUSB® or Dante® Options

Interface

IR or Keypad via OSD, Webserver

Connectors

Digital Video

(2) HDMI In, (1) HDMI Out, (1) Stereo Line In (3.5mm TRS), (1) Stereo Line Out (3.5mm TRS)

Data

(1) Ethernet port for network, (1) USB ports for charging & ExtremeUSB Option

Control

IR

20KHz-60KHz

Serial

Up to 115K Baud

Physical & Power

Dimensions

3 Gang 5.54" x 2.83"(4.331" with tabs) x 1.404" Note: Wall box portion depth 1.0" without option card and 2.25" with option card.

Weight

2.5lbs

Power

48V DC (2 pin Euro)

Manufacturer Part No: IPX-TCW3-C-W Brand: Aurora Product Type: -
UPC - Product Family: - Shipping Weight: 0.8 kg
PB Part No: DVAAUR1013 Product Model: -

Warranty: 12 months local warranty *
