Seagate 3.5" 10TB Enterprise Capacity (Exos) SATA 6Gb/s, 7.2K RPM, 256M, 512e

PB Tech price: PB Tech price:
$494 78  +GST $569 00  inc GST
  • Overview
  • Features
  • Specifications
  • Reviews
  • Q & A

Generating Print Page

Seagate 3.5" 10TB Enterprise Capacity (Exos) SATA 6Gb/s, 7.2K RPM, 256M, 512e

Seagate 3.5" 10TB Enterprise Capacity (Exos) SATA 6Gb/s, 7.2K RPM, 256M, 512e

  • Brand: Seagate
  • MPN: ST10000NM0016
  • Part #: HDDSE39100
  • UPC:672042225972
  • HDD Capacity:10TB HDD
  • Form Factor:3.5"
  • RPM:7200RPM
  • Cache:256MB
  • Interface:SATA3
PB Tech price:PB Tech price:
$49478$56900
 +GST  inc GST

Store Pickup: Select your store to check availability
Delivery: Order now and it ships on 24/09/2019
When will I receive it?
Add To Compare

18 months interest free - 36 months to pay available

No payments or interest for 12 months available

What PB Tech customers are saying about this product...See More Reviews

"had seen a lot of reviews of large capacity drives being noisy, this baby quiet as a mouse & nice'n quick for a spinner."
 Gary ~ 07-03-19

Features

Maximum Storage Capacity for Highest Rack Space Efficiency

- 10TB per drive 1 for 25% more petabytes per rack
- Industry's lowest power and weight for optimum data center TCO
- Forged, wrought-aluminum base and a helium sealed-drive design with uniform density and no porosity
- Superior material and weld-width design for a more robust, hermetically sealed-drive enclosure that protects from helium leaks
- Digital environmental sensors for measuring internal humidity, pressure and temperature, helping to ensure high reliability, performance and quality
- Latest hermetic interconnect technology supporting higher data rate heads and higher pin counts for extreme thermal conditions
- Proven enterprise-class reliability backed by 2.5M-hr MTBF


Best-Fit Applications

- Hyperscale applications/cloud data centers
- Massive scale-out data centers
- High-capacity density RAID storage
- Mainstream enterprise external storage arrays
- Distributed file systems, including Hadoop and Ceph
- Enterprise backup and restore-D2D, virtual tape
- Centralized surveillance



Minimal TCO. Maximum MTBF.

With a 5-year limited warranty and the lowest power consumption in its class, the Seagate 10 TB Enterprise Capacity 3.5 HDD (Helium) helps you shrink power and cooling costs. Dramatically reduce IOPS/watt while improving rack density thanks to lowest-in-class drive weight.



Designed for Reliability

A host of engineering innovations ensures a better hermetically sealed - and so much more dependable - drive. Premium materials, including a wrought-aluminium base, gas-impermeable enclosure, and wide-weld sealed drive design ensure maximum reliability. Humidity sensor and corrosion protection offer increased resistance to harsh environments. For industry-best data security, these drives even offer Secure Download & Diagnostics (SD&D), Seagate Secure Self-Encrypted Drive (SED) and FIPS support.

Specifications

Special Features

Multi-Step Forged Helium Sealed-Drive Design

Yes
Helium Sealed-Drive Design With Wide Weld
Yes
Digital Environmental Sensors Yes Protection Information (T10 DIF)
-
SuperParity
Yes
Low Halogen
Yes
PowerChoice™ Idle Power Technology
Yes
PowerChoice™ Power/Performance Technology
Yes
RAID Rebuild
Yes
Hot-Plug Support1
Yes
Cache, Multisegmented (MB)
256
Organic Solderability Preservative
Yes

Reliability/Data Integrity

Mean Time Between Failures (MTBF, hours)

2.5 Million
Reliability Rating @ Full 24×7 Operation (AFR)
0.35%
Nonrecoverable Read Errors per Bits Read, Max
1 sector per 10E15
Power-On Hours
8760
512e Sector Size (Bytes per Sector)
512
4Kn Sector Size (Bytes per Sector)
4096
Warranty, Limited (years)
5

Performance

Spin Speed

7200RPM
Interface Access Speed (Gb/s)
6.0, 3.0, 1.5
Max. Sustained Transfer Rate OD (MB/s, MiB/s)
249, 237
Average Latency (ms)
4.16
Interface Ports
Single
Rotational Vibration @ 1500Hz (rad/s²)
12.5

Power Consumption

Idle Average (W)

4.5W
Max Operating, Random Write 4K/16Q (W)
6.5
Max Operating, Random Read 4K/16Q (W)
8.4
Power Supply Requirements
+12V and +5V
PowerChoice™ Technology
Yes
PowerBalance™ Technology
Yes

Environmental

Temperature, Operating (°C)

5°C - 60°C
Vibration, Nonoperating: 10Hz to 500Hz (Grms)
2.27
Shock, Operating, 2ms (Read/Write) (Gs)
70/40Gs
Shock, Nonoperating, 1ms/2ms (Gs)
250Gs

Physical

Height (mm/in, max)
26.11mm/1.028in
Width (mm/in, max)
101.85mm/4.010in
Depth (mm/in, max)
147.0mm/5.787in
Weight (g/lb)
650g/1.433lb
Manufacturer Part No: ST10000NM0016 Brand: Seagate Product Type: -
UPC 672042225972 Product Family: - Shipping Weight: 0.6 kg
PB Part No: HDDSE39100 Product Model: -

Warranty: 60 months local warranty *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.

Reviews

5 out of 5 StarsBased on 1 Reviews

5 Stars
1
4 Stars
0
3 Stars
0
2 Stars
0
1 Star
0

Filter Results

Do you own this product?

Write a review and go into the draw to win great prizes each month! Learn more WRITE A REVIEW
Displaying 1 - 1 of 1 reviews
Gary

Drive is super quiet

7 March 2019
had seen a lot of reviews of large capacity drives being noisy, this baby quiet as a mouse & nice'n quick for a spinner.
