WD Red Plus 1TB 3.5" Internal HDD

SATA3 - 5400 RPM - 64MB Cache - 3 Years Warranty - Designed and tested for RAID environments

PB Tech price
PB Tech price
$ 132 .17
 +GST
$ 152 .00
 inc GST

Out of stock

Limited Supply - only stock on hand available, when sold out we may not be able to source this product again.

WD Red Plus 1TB 3.5" Internal HDD

SATA3 - 5400 RPM - 64MB Cache - 3 Years Warranty - Designed and tested for RAID environments

  • Brand: WD
  • MPN: WD10EFRX
  • Part #: HDDWD1922
  • UPC: 718037799650
6
PB Tech price
$ 132 .17 $ 152 .00
 +GST  inc GST

No store stock available.

Click & Collect: Collect unavailable
Delivery: Out of stock When will I receive it?
  • Brand: WD
  • MPN: WD10EFRX
  • Part #: HDDWD1922
  • UPC: 718037799650

HDD Capacity

1TB

Form Factor

3.5"

RPM

IntelliPower

Cache

64MB

Interface

SATA3

What PB Tech customers are saying about this product...

See More Reviews

"I bought the WD drive to equip the Synology Disk Station, and am very happy with it. It has been running for a couple of weeks thus far. The PB Tech service was great!"

JL
By: JeffL5 28/06/21
Verified Owner

"No problems. Does what it's supposed to. Will get another for RAID"

RL
By: RichL 04/11/19
Verified Owner

"No nonsense drive. Easy to setup and use."

G
By: Guest 28/09/19

Features

Optimized for RAID environments, keep your important data safe!

The WD Reds are part of the WD hard drive family which consists of five different colours: blue, green, purple, red and black. They all have different purposes and while they are all quite similar, they are all fine tuned to perform a particular task or be fit for a certain type of application. The WD Reds are designed for use in RAID, designed to protect your important files while still providing optimal performance. It features TLER which stands for time-limited error recovery, this is useful because most RAID controllers will drop a hard drive from the RAID array if there is no response for a couple of seconds. TLER helps prevent the RAID controller dropping the drive by aborting the recovery process if it takes more than 7 seconds which means your data transfer won't be interrupted. They also feature vibration reduction, which helps stabilize the drives when they are used together making it possible to put these in an 8 bay NAS. The speed of which these drives spin at are determined by Intellipower, which is WDs optimzed speed to power ratio for the drives, ranging from 5400 to 7200 rpm, making these drives a lot more efficient. If you are after a drive to protect your data in a small RAID environment, the WD Reds are the perfect choice.



The WD Red family just got bigger

Our formula of success has led to the growth of WD Red into the highest capacities possible. Available up to 6 TB, WD offers an even broader, more comprehensive portfolio of NAS solutions for our customers spanning from a total of 1 to 16 bays. The WD Red family just got bigger.

NASware grows to 3.0

Built off of our determination to deliver the best NAS experience, NASware 3.0 extends our promise by further optimizing WD Red for the NAS environment with added support for 6 to 8 NAS bays. WD Red now supports small NAS systems from 1 to 8 bays thanks to NASware 3.0, which further improves drive compatibility and reliability. At 48 TB of total capacity in an 8 bay system, WD Red expands your NAS experience.

Professional solutions

Designed specifically with SMB customers in mind, the WD Red family has expanded with the addition of WD Red Pro, which is available for the 8 to 16 bay medium to large-scale NAS environments. With capacities up to 4 TB, WD Red Pro carries a 5-year limited warranty and was engineered to handle the increased workloads from your business.

Experienced in NAS

WD Red is a reflection of the most extensive NAS partner compatibility- testing list that is available on the market.* That means when you buy a NAS enclosure, you can trust that WD Red will be the most compatible drive available. Our pride is in our product and our vision is shared with our customers.

NAS for Home

Take your connected home environment to the next level with a NAS system that is equipped with WD Red hard drives and enjoy streaming your media, backing up your computers, file sharing and managing your digital content faster and easier. The WD Red NASware 3.0 experience with increased compatibility makes sharing from your mobile device, computer, TV, stereo and more an instant gratification. WD Red enables you to create your own reliable Personal Cloud.

NAS for Small Business

Increase the efficiency and productivity of your small business with WD Red hard drives for your 1 to 8 bay NAS system. WD Red comes equipped with NASware 3.0, which increases system compatibility allowing for seamless integration with your existing network infrastructure. Add value to your business by enabling your employees to quickly share their files and back up folders reliably with WD Red NAS hard drives in your NAS solution. For medium to large business environments that use up to 16 bay NAS systems, use WD Red Pro.

3D Active Balance Plus

Our enhanced dual-plane balance control technology significantly improves the overall drive performance and reliability. Hard drives that are not properly balanced may cause excessive vibration and noise in a multi-drive system, reduce the hard drive life span, and degrade the performance over time.

The Right Choice!

WD Red is designed specifically for home and small office NAS systems and PCs with RAID.

Enhanced Reliability

Since your NAS system is always on, a highly reliable drive is essential. With a 35% MTBF improvement over standard drives, the WD Red drive with NASware 3.0 is designed for the 24x7 environment.

NAS Compatibility

Advanced firmware technology built into every WD Red drive, NASware 3.0 enables seamless integration, robust data protection and optimal performance for systems operating in NAS and RAID environments.

Longer Warranty Coverage

WD Red hard drives are backed by a 3-year limited warranty for greater peace of mind and a longer warranty coverage that matches most NAS system manufacturers.

Lower Operating Temperatures

Innovative technology reduces power consumption and lowers the operating temperature, resulting in a more reliable and affordable solution for always on NAS environments.

Specifications

Interface
SATA 6 Gb/s
Rotational Speed
IntelliPower
Buffer Size
64 MB
Transfer Rates
Buffer To Host (Serial ATA) 6 Gb/s (Max)
Formatted Capacity
1,000,204 MB
Capacity
2 TB
Form Factor
3.5 Inch
User Sectors Per Drive
1,953,525,168
MTBF
1,000,000 hours
Height
26.1 mm
Depth
147 mm
Width
101.6 mm
Weight
0.45 kg
Operating Shock (Read)
65G, 2 ms
Non-operating Shock
350G, 2 ms
Idle Mode
21 dBA (average)
Seek Mode
22 dBA (average)
Operating
-0° C to 70° C
Non-operating
-40° C to 70° C
Operating Humidity
5-95% RH non-condensing
Operating Vibration
0.004 g²/Hz (10 to 300 Hz)
Non-operating Vibration
0.05 g²/Hz (10 to 300 Hz)
Current Requirements
12 VDC
Read/Write 190 mA
Idle 180 mA
Standby 7 mA
Sleep 7 mA
5 VDC
Read/Write 280 mA
Idle 215 mA
Standby 105 mA
Sleep 105 mA
Power Dissipation
Read/Write 3.70 Watts
Idle 3.20 Watts
Standby 0.60 Watts
Sleep 0.60 Watts
Compatibility
Windows/Mac/Linux

Manufacturer Part No:
WD10EFRX
Brand:
WD
Product Type:
Internal HDD
UPC
718037799650
Product Family:
Red
Shipping Weight:
0.482 kg
PB Part No:
HDDWD1922
Product Model:
Plus
Warranty: 36 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.

Reviews

5 out of 5 Stars Based on 6 reviews
5 Stars
6
4 Stars
0
3 Stars
0
2 Stars
0
1 Stars
0

Do you own this product?

Write a review and go into the monthly draw Win A $100 PB Tech Gift Card!

Great Product, Excellent Service

I bought the WD drive to equip the Synology Disk Station, and am very happy with it.
It has been running for a couple of weeks thus far.
The PB Tech service was great!

JL
By: JeffL5 28/06/21
Verified Owner
0 out of 0 users found this review helpful
Did you find it helpful?

Works just fine

No problems. Does what it's supposed to. Will get another for RAID

RL
By: RichL 04/11/19
Verified Owner
0 out of 0 users found this review helpful
Did you find it helpful?

Solid and reliable

No nonsense drive. Easy to setup and use.

G
By: Guest 28/09/19
0 out of 0 users found this review helpful
Did you find it helpful?

WD 1 TB RED

Have a few of these in our company, and they have performed very well.
They run 24/7.

G
By: Guest 08/08/18
0 out of 0 users found this review helpful
Did you find it helpful?

Well Packaged, Prompt shipping and work perfectly.

G
By: Guest 16/03/17
0 out of 0 users found this review helpful
Did you find it helpful?

Does the job

G
By: Guest 28/03/16
0 out of 0 users found this review helpful
Did you find it helpful?

Delivery & Pick-up

Potential courier delays: Please note that due to the high volumes currently within the NZ courier network there is potential for some deliveries to be delayed.

Delivery Estimates

The estimated time to ship for each product we sell is detailed on the individual product page just underneath the price. From when your items ship, products typically arrive within 1-2 working days for North Island deliveries and 2-3 working days for South Island deliveries. Rural deliveries may take an extra working day. Bulk & hazard deliveries may take an extra 2-4 working days.

Next Day Delivery

Need your order in a hurry? PB Tech offers next day delivery for local Auckland addresses. Simple place your order before 4pm (provided your items are in stock) and select our next day delivery option in the checkout. T&C's apply. Learn more about Next Day Delivery.

Same Day Delivery

Need your order in a hurry? PB Tech offers same day delivery for Auckland, Hamilton, Wellington and Christchurch. Simple place your order before 1pm (provided your items are in stock) and select one of our same day delivery options 'Evening Delivery' or 'Urgent 3-hour Delivery' in the checkout. T&C's apply. Learn more about Same Day Delivery.

Shipping Costs

Shipping costs vary based on your location and the items being shipped and in some cases shipping may even be FREE.

To calculate what the shipping costs will be for your order, add the items you are interested in to your cart, view the Shopping Cart page, and select your 'Delivery Area' to calculate the shipping cost.

Shipping Security & Insurance

All orders shipped by PB Tech are sent via a courier with a signature required for each delivery. In some cases, and only where you have given the courier company permission to leave orders at a designated location, your order may be delivered without requiring a signature. All orders sent by PB Tech are fully insured in the unlikely event that your item(s) are damaged or go missing in transit.

1 Hour Store Pick-up / Click & Collect

You can pick-up your online order from any of our stores nationwide. You can select which store you want to pick up from at the checkout. Provided the store you select has stock and there's no hold-ups with payment we will have your order ready within 1 hour (during normal trading hours for that store) otherwise it may take up to 5 working days to transfer the stock to the store so your order can be fulfilled. Learn more about our Click & Collect process.

Overseas Shipments

PB Tech regularly ships overseas to Australia and beyond. If you are located in Australia, you can order directly from our Australian site www.pbtech.com/au. If you are from another country you can order from www.pbtech.com

Returns & Warranty

7 day right of exchange

If you change your mind after making a purchase, or realise you have ordered the incorrect item, you can enjoy the peace of mind that we offer a 7 day exchange policy.

To exchange a product, goods must be sealed and unopened, with packaging in original condition, accompanied by a valid receipt dated no more than 7 calendar days from when you request an exchange. A 20% restocking fee may be applied where goods are not returned in sealed, original packaging condition.

If there is not a suitable product that can be exchanged for your returned item you will be offered a credit on your account or gift card based on the value paid at the time of purchase. Items purchased on finance cannot be exchanged for a gift card.



Hassle free warranty service

If your product develops a fault within the manufacturer warranty period, you can either contact the manufacturer directly (some manufacturers provide a high level of warranty service - including free pickup or in some cases onsite repair), or return to one of our services centres / stores. Where the product has been directly imported by PB Tech, you need to contact us directly or present the product at any one of our service centres / stores together with your proof of purchase.

If your product develops a fault outside of the manufacturer warranty or PB Tech warranty period, we offer a full repair service and are an authorised repair agent for leading brands such as Samsung, HP, Toshiba, Lenovo and more.



Returning a product / making a warranty claim

To contact the manufacturer directly to troubleshoot your product or to request a warranty repair, please view the list of manufacturer / brand warranty contacts (for products imported directly by PB Tech please return to us directly by completing our request a return form).

To return a product to PB Tech directly, please complete our request a return form.

Or view our returns policy for more information.
