StarTech.com 4P6G-PCIE-SATA-CARD SATA PCIe Card - 4 Port PCIe SATA Expansion Card - 6Gbps - Low/Full Profile - Stacked SATA Connectors - ASM1164 Non-Raid - PCI Express to SATA Converter

PB Tech price
PB Tech price
$ 96 .21
 +GST
$ 110 .64
 inc GST
$96.21  +GST
$110.64

StarTech.com 4P6G-PCIE-SATA-CARD SATA PCIe Card - 4 Port PCIe SATA Expansion Card - 6Gbps - Low/Full Profile - Stacked SATA Connectors - ASM1164 Non-Raid - PCI Express to SATA Converter

  • Brand: StarTech.com
  • MPN: 4P6G-PCIE-SATA-CARD
  • Part #: IDESTT5464477
  • UPC: 065030893879
2
PB Tech price
$ 96 .21 $ 110 .64
 +GST  inc GST


Click & Collect: Available from 1 store.
Select your store to check availability
Delivery: Order now and it ships on 15 Sep When will I receive it?
Uber Delivery: Order now and get it within 3 hours. Some areas, max $1k order. How does it work?
$96.21  +GST
$110.64
  • Brand: StarTech.com
  • MPN: 4P6G-PCIE-SATA-CARD
  • Part #: IDESTT5464477
  • UPC: 065030893879

What PB Tech customers are saying about this product...

See More Reviews

"Relatively good price vs other options, but more expensive than the one it replaced from Ali that didn't work. I guess you get what you pay for lol."

BM
By: BenM797 09/09/24
Verified Owner

"Does what it says on the tin, no fuss"

DC
By: DanC5 15/06/23
Verified Owner

COMBO DEALS: Buy Together and SAVE!

Save even more by creating your own combo deal with any of the items below and the StarTech.com 4P6G-PCIE-SATA-CARD SATA PCIe Card - 4 Port PCIe SATA...
StarTech.com 4P6G-PCIE-SATA-CARD SATA PCIe Card - 4 Port PCIe SATA Expansion Card - 6Gbps - Low/Full Profile - Stacked SATA Connectors - ASM1164 Non-Raid - PCI Express to SATA Converter
Total:
$ 99 .99
 +GST
$ 114 .99
Buy together and save $0.52 $0.60
Dynamix C-SATA3 6Gbps SATA Data Cable - with Latch - 50cm - Black
Dynamix C-SATA3 6Gbps SATA Data Cable - with Latch - 50cm - Black

$3.78  +GST

$4.35

You save 12% You save 12%

Features

This 4-port SATA III (6Gbps) controller enables you to add four SATA 6Gbps Hard Drives (HDDs) or Solid State Drives (SSDs) to your computer system or server via an available PCIe x2 card slot. The card supports SATA III and PCI-Express 3.0 Specifications.

ASM1164 to Deliver 4-Port SATA 6Gbps Performance

Featuring the ASM1164 controller, this SATA card enables the connection of four high-performance SATA 6Gbps drives with a combined total throughput of up to 16Gbps. The SATA drives are connected via four individual SATA ports located on the card (SATA cables sold separately).

Wide Compatibility

The controller card is widely supported across all popular operating system platforms including Windows (7, 8, 10, 11), macOS (10.10 and above) and Linux (2.6.32 and above). The card also supports port multiplier, giving you the ability to connect multiple drives to a single SATA port (additional hardware required, sold separately).

To further improve motherboard compatibility the card does not have a built-in RAID controller, but fully supports the use of software RAID. Plus, with support for PCIe 3.0 and SATA III Specifications this card ensures backward compatibility with previous generations (SATA I/II, PCIe 1/2) at lower performance.

Hassle-Free Installation

The SATA controller card features plug-and-play installation and can be installed in a full-profile or low-profile computer systems with the full-profile bracket preinstalled, and an interchangeable low-profile (half-height) bracket included. The card also supports storage software data management systems such as Storage Spaces (Microsoft), RAID Assistant (MacOS) and mdraid/mdadm (Linux), for hassle-free setup, partitioning and software RAID array building.

Specifications

Connector(s)

Connector Type(s)

1 - PCI Express x2

Internal Ports

4 - SATA (7 pin, Data)

Environmental

Operating Temperature

0°C to 85°C (32°F to 185°F)

Storage Temperature

-25°C to 85°C (-13°F to 185°F)

Humidity

20~80% RH

Hardware

Ports

4

Interface

SATA

Bus Type

PCI Express

Card Type

Standard Profile (LP bracket incl.)

Industry Standards

Serial ATA 3.0 specification - SATA I/II/III (1.5/3/6Gbps)
PCI Express Base Specification Revision 3.0

Chipset ID

ASMedia - ASM1164

Packaging Information

Package Height

1.2 in [3.0 cm]

Package Length

6.7 in [17.0 cm]

Shipping (Package) Weight

4.1 oz [115.0 g]

Package Width

5.6 in [14.2 cm]

Performance

Maximum Data Transfer Rate

6 Gbps

TRIM Support

Yes

4Kn Support

Yes

S.M.A.R.T. Support

Yes

Type and Rate

SATA III (6 Gbps)

Port Multiplier

Yes

Bootable

Yes

Hardware Raid Supported

No

ATAPI Support

Yes

Physical Characteristics

Color

Red

Product Height

0.6 in [1.6 cm]

Product Length

2.8 in [7.0 cm]

Weight of Product

1.8 oz [50.0 g]

Product Width

2.2 in [5.6 cm]

Software

OS Compatibility

Windows® 7, 8, 8.1, 10, 11
Windows Server® 2012 R2, 2016, 2019
macOS® 10.10 to 12
Linux 2.6.32 and up

Manufacturer Part No:
4P6G-PCIE-SATA-CARD
Brand:
Product Type:
SATA PCIe Card
UPC
065030893879
Product Family:
-
Shipping Weight:
0.1 kg
PB Part No:
IDESTT5464477
Product Model:
4P6G-PCIE-SATA-CARD
