Advantech ADAM-3112-AE Isolated AC Voltage Input Module
Advantech ADAM-3112-AE Isolated AC Voltage Input Module
- Brand: Advantech
- MPN: ADAM-3112-AE
- Part #: IPCAVH220007
- UPC:
- Brand: Advantech
- MPN: ADAM-3112-AE
- Part #: IPCAVH220007
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Related Promotions
Popular Industrial Automation & I/O





Advantech ADAM-3112-AE Isolated AC Voltage Input Module
- Brand: Advantech
- MPN: ADAM-3112-AE
- Part #: IPCAVH220007

Product URL: https://www.pbtech.co.nz/product/IPCAVH220007/Advantech-ADAM-3112-AE-Isolated-AC-Voltage-Input-M
Branch | New Stock | On Display |
---|---|---|
Auckland - Albany | - | |
Auckland - Glenfield | - | |
Auckland - Queen Street | - | |
Auckland - Auckland Uni | - | |
Auckland - Newmarket | - | |
Auckland - Westgate | - | |
Auckland - Penrose | - | |
Auckland - Henderson (Express) | - | |
Auckland - St Lukes | - | |
Auckland - Manukau | - | |
Hamilton | - | |
Tauranga | - | |
New Plymouth | - | |
Palmerston North | - | |
Petone | - | |
Wellington | - | |
Auckland - Head Office | - | |
Auckland - East Tamaki Warehouse | - | |
Christchurch - Hornby | - | |
Christchurch - Christchurch Central | - | |
Dunedin | - |
Features
- AC voltage measurement
- 1,000 VDC isolation between output and power
- 2,500 VAC isolation between output and input
- Input impendent: 2 Mohm
- Multi input modes
- Accuracy: ±0.1% FSR;Flexible Din-rail mounting
- Operates from a single +24VDC
Specifications
Voltage Output
?Output Signal
0 ~ 5 VDC
Accuracy
< ±1.0 % for full range
Output Impedance
< 10 ? @ operating frequency <60 Hz
Load
> 10 k ?
Ripple
< 120mVp-p
Temperature Coefficient
400 ppm/°C
Input Bandwidth
6 kHz
Power Consumption
?Supply Voltage
24 VDC ± 10%
Current Consumption
40 mA
General
Isolation Protection
1,000 VDC (output to power)
2,500 VRMS (input to output, input to power)
Dimensions (W x H x D)
23.2 x 101 x 93.5 mm (0.91" x 3.97" x 3.68")
Operating Temperature
0 ~ 60 °C (32 ~ 140 °F)
Storage Temperature
-20 ~ 70 °C (-4 ~ 158 °F)
Storage Humidity
5 ~ 95%
