Features
The EKI-9502G EN50155 train-to-ground Wi-Fi/cellular router is designed for rolling stock applications. It provides secure Internet connectivity while offering superior application flexibility. EKI-9502G provides automatic wireless failover between WLAN and WAN connectivit and supports up to 4 WWAN(LTE) modules with dual SIM cards installation and up to 2 WIFI modules for 802.11a/b/g/n/ac with 2.4Ghz/5Ghz selective. With load balance, VPN tunneling, and configuration backup, it provides stable and reliable wireless connectivity that is ideal for transportation applications.
- Cellular connectivity with dual SIM cards designed for each cellular module
- Supports up to 4 WWAN connectivity
- Supports wide temperature range: -40 ~ 70°C
- Designed with 24Vdc to 110Vdc isolated power input
- Flexible design with serial interface for Modbus RTU and serial communication protocol
- Supports IPSec, OpenVPN secured tunnel
- Firewall with SPI and IPS function prevents cyber attacks and enhances network efficiency
- Complies with EN50155
- Supports multi-WAN load balance
For more information: https://advdownload.advantech.com/productfile/PIS/EKI-9502G/file/EKI-9502G-Series_DS(071223)20230712133655.pdf

Specifications
MPN
EKI-9502G-CXRW-A
Certification
EMC
EN 55032, EN 55024, EN 50121-3-2, EN 50121-4
EMI
FCC Part 15 Subpart B (Class B)
EMS
EN 61000-6-1,
EN 61000-6-3,
EN 61000-4-2,
EN 61000-4-3,
EN 61000-4-4,
EN 61000-4-5,
EN 61000-4-6,
EN 61000-4-8,
EN 61000-4-11
Environment
Relative Humidity
10~95% RH
Operating Temperature
-40 ~ 70°C (-40 ~ 158°F)
Storage Temperature
-40 ~ 80°C (-40 ~ 176°F)
Ethernet Communication
RJ-45 Port Connector Type
M12
RJ-45 Port Number
2
RJ-45 Transmission Distance
NA
RJ-45 Transmission Speed
10/100/1000 Mbps
Mechanism
Dimensions (W x H x D)
280 x 160 x 85 mm (11 x 6.3 x 33.5 in.)
Enclosure (Metal)
Metal shell with solid mounting kits
LED Indicator
System: Power, Status
WLAN: Quality
LAN: Link/Active
Mounting (Wall)
Yes
Weight
1.5 kg
Power
Power Connector Type
M12 (5 pin A-coded)
Power Consumption
21W
Power Input (DC)
24 ~ 110 VDC
Software
Configuration
Web browser
Protocols
ARP, ICMP, IPv4, TCP, UDP, DHCP Client/Server, DNS proxy, HTTP, SNTP, Telnet, SSH, VPN
Reboot Trigger
N/A
Wireless Communication
Wi-Fi 2.4 GHz
Yes
Wi-Fi 5 GHz
Yes
Wi-Fi Antenna Connector Type
Reverse SMA
Wi-Fi Operation Mode
Access Point/ Client mode
Wi-Fi RF Capability
3T3R
Wireless Security
Open System , Shared Key, Lagacy 802.1X
Wi-Fi Standard
IEEE 802.11 a/b/g/n/ac
