Advantech IMC-470-M1-US Standalone Media Converter, 1000Mbps, Multimode 1300nm, 2km, SC, AC adapter (also known as Giga-McBasic 856-30602)
Advantech IMC-470-M1-US Standalone Media Converter, 1000Mbps, Multimode 1300nm, 2km, SC, AC adapter (also known as Giga-McBasic 856-30602)
- Brand: Advantech
- MPN: IMC-470-M1-US
- Part #: IPCAVH220856
- UPC:
- Brand: Advantech
- MPN: IMC-470-M1-US
- Part #: IPCAVH220856
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Related Promotions
Popular Industrial PCs & IoT





Advantech IMC-470-M1-US Standalone Media Converter, 1000Mbps, Multimode 1300nm, 2km, SC, AC adapter (also known as Giga-McBasic 856-30602)
- Brand: Advantech
- MPN: IMC-470-M1-US
- Part #: IPCAVH220856

Product URL: https://www.pbtech.co.nz/product/IPCAVH220856/Advantech-IMC-470-M1-US-Standalone-Media-Converter
Branch | New Stock | On Display |
---|---|---|
Auckland - Albany | - | |
Auckland - Glenfield | - | |
Auckland - Queen Street | - | |
Auckland - Auckland Uni | - | |
Auckland - Newmarket | - | |
Auckland - Westgate | - | |
Auckland - Penrose | - | |
Auckland - Henderson (Express) | - | |
Auckland - St Lukes | - | |
Auckland - Manukau | - | |
Hamilton | - | |
Tauranga | - | |
New Plymouth | - | |
Palmerston North | - | |
Petone | - | |
Wellington | - | |
Auckland - Head Office | - | |
Auckland - East Tamaki Warehouse | - | |
Christchurch - Hornby | - | |
Christchurch - Christchurch Central | - | |
Dunedin | - |
Features
The IMC- 470 series are standalone media converters with an optional internal power security device that makes the connection between copper and fiber cables. They can be installed anywhere a network connection is required. In addition, these media converters feature automatic link restoration. They increase the scalability of a network by providing rate conversion, distance extension, and multiple types of fixed fiber connectors or open slots for small form-factor pluggable (SFP) connections.
The IMC-470 series provides two 10/100/1000Mbps copper UTP ports and one fiber port. They are available in an SFP form factor, as well as for fixed-fiber in single-mode and multi-mode. Link Fault Pass Through (LFPT) functionality allows network operators to determine a fault condition on the interface. LFPT can be enabled vis a dip switch on the front of the unit.
- Designed with internal AC power
- Supports diagnostic features including Link Loss and Fiber Alert
- Optional 10/100/1000Mbps copper ports
- Optional Link Fault Pass Through (LFPT)
- Supports range of SFP modules
- Supports multiple mounting options (desktop, DIN rail or wall-mount)
Specifications
MPN
IMC-470-M1-US
Media Converter with US power cord
Also Known As
856-30602
Ethernet Speed
10/100/1000Mbps
Optical Mode
Multi-mode
Wavelength
1300 nm
Distance
2 km
Optical Connector
SC
Ethernet Connector
2 x RJ45
Technical
IEEE 802.3ab 1000Base-T, 1000Base-LX or SX
Supports diagnostic LEDs
Supports AutoCross, Link Loss and Fiber Alert
Supports Auto Negotiation
Supports jumbo frame up to 10000 bytes
2 x RJ-45 connector
Power Input
100-240 V AC, 50/60Hz, 7 watts maximum working power
Environment
Operating Temperature
-10 to +50 °C (+14 to +122 °F)
Storage Temperature
-35 to +75 °C (-31 to +167 °F)
Operating Humidity
5 ~ 95% (non-condensing)
0 ~ 10,000 ft. altitude
MTBF
1.8 million hours
Mechanical
Dimensions (H x W x D)
2.03 x 10.16 x 10.16 cm (0.80 x 4.0 x 4.0 in)
Weight
0.3kg (0.7lb)
Certifications
CE, FCC Class A, UL/cUL, CSA
