Advantech WISE-S100-A Intelligent Stack Light Monitoring Sensor

PB Tech price
PB Tech price
$ 194 .76
 +GST
$ 223 .97
 inc GST
$194.76  +GST
$223.97

Advantech WISE-S100-A Intelligent Stack Light Monitoring Sensor

  • Brand: Advantech
  • MPN: WISE-S100-A
  • Part #: IPCAVH221233
  • UPC:
PB Tech price
$ 194 .76 $ 223 .97
 +GST  inc GST

No store stock available.

Click & Collect: Select your store to check availability
Delivery: Order now and it ships on 21 Oct When will I receive it?
$194.76  +GST
$223.97

Finance from $3.02 per week*

Get what you want at a price you can afford. Choose a finance term below to see the weekly repayment amount and apply online during checkout or in-store.

Choose a Finance Term

*Weekly payments are indicative only and based on a retail price of over a loan term of months at an interest rate of % p.a. and include a monthly service fee and a establishment fee (excludes optional Payment Protection Insurance).The total amount payable over the term of the loan is . Details of finance (including weekly payments, the total amount repayable over the term of the loan, interest rate and any applicable fees) can be confirmed with a detailed quote. Full disclosure of all of the terms of your finance will also be provided to you in the Finance Now disclosure statement for your consideration prior to confirmation of your purchase. All finance is subject to Finance Now terms and conditions and approval criteria.

Learn more about Finance Now

24 months interest FREE available*

Q Card / Mastercard is your perfect shopping partner, combining the benefits of a credit card with the added ability to access a range of interest-free deals and payment holidays.

Learn more about Q Mastercard, apply online for one now, or email [email protected] to chat with our team.

*12 Months No Payments & No Interest (“Payment Holiday”) is available on Long Term Finance (LTF) for in-store & online purchases. Min Spend $200. Lending criteria, $50 annual Account Fee, fees, Ts&Cs apply. $55 Establishment Fee applies to your first LTF transaction, $35 Advance Fee applies to subsequent LTF transactions. Standard Interest Rate currently 28.95% p.a. applies at the end of LTF Interest Free Period. Rates and fees correct as at date of publication, subject to change. Other interest rates and fees may apply. See qcard.co.nz for full details. Credit provided by Columbus Financial Services Limited. Excludes vouchers, gift cards, software licenses, game activation codes, pre-orders, Customized-to-Order (CTO) Apple Mac, and backorders.

*See here for full T&C

Features

Intelligent Stack Light Monitoring Sensor

- One product for all scenarios
- Fits a variety of stack-type light towers
- 8 light sensors for fast flexible installation
- No need to stop the machinery while deployment
- Remote intelligent OEE solution by pairing with WISE-4000 series wireless I/O module
- Low power consumption for WISE-4000 LPWAN series

WISE-S100 is an easy to install intelligent stack light monitoring sensor to fit a variety of stack-type light towers. When WISE-4000 wireless modular I/O series is paired with WISE-S100 sensor, users get a remote and intelligent OEE solution that can be integrated without stopping machinery, or worrying about wiring. WISE-S100 enhances the productivity and overall equipment effectiveness. It supports WiFi 2.4G and various LPWAN wireless technologies such as LoRaWAN and proprietary LPWAN (SUB-G) which has higher penetration, lower interference, wider coverage and fits diverse production scenarios on the production line. WISE-4000 LPWAN series come with an optional battery power solution.

One for All, Fit a Variety of Stack-type Light Towers

There are 8 light sensors inside WISE-S100 tower light. The idea of the design is for quick and easy installation without needing to stop the machine. All users need to do is to simply position a sensor indicator at the stack light and adjust WISE-S100 directly to match each light and mount them together

No Need to Stop the Machinery While Installation

Directly position WISE-S100 on the stack-type light tower to quickly get light status. You do not need to stop machine/equipment so you can quickly deploy your intelligent OEE solution.

Intelligent OEE Solution by Wireless Remote Management

By pairing RS-485 I/O interface(WISE-4051 or WISE4250+WISE-S250/S251) and WISE-S100, users can enjoy wireless remote management including up to 10, 000 data samples of local data storage with time stamps. WISE-S100 sends data to SCADA system, MES etc. via Modbus TCP, RESTful, HTTP and MQTT messaging protocols. The sensors support more than 64 Modbus addresses for intelligent OEE applications. WISE-4000 series also have WiFi, LoRaWAN and proprietary LPWAN wireless solution which support Modbus, and MQTT messaging protocols for remote management. With LPWAN wireless technologies, the whole solution can be battery powered with high penetration and wide coverage for complex production line environments.

Specifications

Power

?Power Supply

3.3~30VDC

Power Consumption

15mA

Generic

?Communication Interface

RS-485 (Modbus/RTU)

Ambient Light Sensor

?Number of Sensor

8

Sensor Detection Rate

3Hz

Measuring Range

20.48~83865.6 lux

Measuring Light Status

On, Off, Slow Blink, Fast Blink

Peak Irradiance

550nm (TYP.)

?Resolution

12 bits

Accuracy*

15%
*Accuracy of measurement of fluorescent light.

Linearity

Input illuminance > 40 lux, 2% (TYP.)
Input illuminance < 40 lux, 5% (TYP.)

Temperature Drift

0.02%/°C

Mechanical

?Dimension (L x W x H)

220 x 14 x 12.8 (mm)

Material

Polycarbonate (PC)

Environmental

Operating Temperature

-25~70 °C

Storage Temperature

-40~80 °C

Operating Humidity

5~95% RH

Storage Humidity

0~95% RH

Wireless I/O Module

2.4GHz WiFi

? WISE-4051-B 2.4G WiFi IoT Wireless I/O with RS-485& 8DI

2.4/5GHz WiFi

WISE-4250-A Wi-Fi 5 2.4/5GHz Wireless I/O Module
- WISE-S250-A 6DI, 2DO & 1RS-485
- WISE-S251-A 6DI & 1RS-485

Proprietary LPWAN (SUB-G)

Proprietary LPWAN (SUB-G)

? WISE-4210-NA Proprietary LPWAN IoT Wireless Modular I/O
- WISE-S250-A 6DI, 2DO & 1RS-485
- WISE-S251-A 6DI & 1RS-485
- 1760002647-01 Bat.Cylindrical 3.6V/2500mAh AA Li/SOCl2 for
WISE-4210
- 1750008836-01 863-870MHz Dipole Antenna for WISE-4210
- 1750008837-01 902-928MHz Dipole Antenna for WISE-4210

LoRaWAN

LoRaWAN

? WISE-4610 Series LoRaWAN IoT Wireless Modular I/O
- WISE-S672-A RS-485& 6DI with M12 Connector
- WISE-S617T-A RS-485, 2AI, 2DI& 1DO with Terminal Block
- WISE-S635-A Sensor Conversion Board (No I/O)

Manufacturer Part No:
WISE-S100-A
Brand:
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
1 kg
PB Part No:
IPCAVH221233
Product Model:
WISE-S100-A
Warranty: 12 months *
