Advantech TPC-B520L Modular TPC - Computing Box Module with Intel® Core™ i3-N305 Processor
- Modular Computing Box powered by Intel® Core™ i3-N305, octo-core processor
- Modular Front Panel modules ranging from 12.1" to 23.8" with P-CAP multi-touch in selection (12.1", 15", 15.6", 21.5" with high brightness panel option)
- Single DDR5 Memory slot supports up to 16GB
- Support expansion via three M.2 slots (PCIe, Wifi, 5G)
- LAN, POE, isolated serial port and isolated digital I/O via iDoor technology
- Support Type-C connector with USB 3.2, DP 1.4a, 15W power delivery
- Support fieldbus protocols/GPS/GPRS/Wi-Fi capabilities via iDoor technology
- Performance, fanless embedded system with chassis grounding protection
Modular Processing Power
At the heart of the Advantech TPC-B520L Modular TPC is its robust computing box, powered by the Intel® Core™ i3-N305 octo-core processor. This modern processor ensures efficient multitasking and reliable performance across industrial and commercial applications. Its octo-core design enables smoother processing of complex computations, making it suitable for demanding environments where consistent and powerful processing is essential.
Versatile and Modular Design
One of the standout features of the TPC-B520L is its highly modular front panel selection. Users can choose from front panel modules ranging from 12.1 inches to 23.8 inches, with options for P-CAP multi-touch technology. Additional high brightness panels are available in 12.1", 15", 15.6", and 21.5" sizes, supporting a wide range of usage scenarios from standard factory environments to high-visibility outdoor settings.
Memory and Expansion Capabilities
The system is designed for flexibility and future-proofing, equipped with a single DDR5 memory slot that supports up to 16GB. For even greater customization, the TPC-B520L includes three M.2 expansion slots compatible with PCIe, Wifi, and 5G modules. This allows the unit to be tailored to the specific needs of a given project, providing options for high-speed networking and cutting-edge wireless connectivity.
Comprehensive Connectivity and iDoor Technology
Connectivity is made versatile with support for LAN, Power over Ethernet (POE), isolated serial ports, and isolated digital I/O, all enabled through Advantech's innovative iDoor technology. The iDoor expansion modules also open up support for various fieldbus protocols, GPS, GPRS, and Wi-Fi capabilities, making integration with a wide range of industrial automation systems straightforward and reliable.
Advanced Interface and Rugged Reliability
The TPC-B520L is engineered with practical interfaces, including a Type-C port that supports USB 3.2, DisplayPort 1.4a, and up to 15W power delivery for additional peripherals or displays. Its fanless embedded system design, combined with chassis grounding protection, ensures consistent performance and higher reliability-especially important in harsh or sensitive environments where durability and operational continuity are key.
Specifications
Environment
Operating Temperature
-10~60 °C (14~140 °F)
Storage Temperature
-30~70 °C (-22~158 °F)
Vibration Protection
1 Grms, random
Shock Protection
10 G, half sine
Hardware
Certification
CB, UL, CE, FCC, CCC, BSMI
CPU
Intel® Core™ i3-N305 1.8GHz 8-Core
Hardware Security
TPM 2.0
I/O
2 x RS-232/422/485, 2 x USB 3.1, 2 x USB 2.0, 1 x Type C, 1 x DP, 1 x iDoor Slot
LAN
2 x 2500 Mbps
Storage
1 x M.2 B key, 1 x 2.5" SSD/HDD Bay
Expansion
1 x M.2 E Key 2230
I/O Interface
Expansion
1 x M.2 B key, 1 x M.2 E key
Displays
1 x DP
Power Connector
1 x 3-Pin Terminal Block
Expansion Function
SIM card slot
Nano SIM card
Mechanical
Mounting
Panel, Wall, Stand, VESA
Weight (Net)
2.8 kg (6.17 lb)
