JimiLab VL103D LTE GNSS Terminal LTE & GSM Network, Configurable Input/Outpu, Car Battery Protection
Out of stock
JimiLab VL103D LTE GNSS Terminal LTE & GSM Network, Configurable Input/Outpu, Car Battery Protection
- Brand: JimiLab
- MPN: VL103D
- Part #: IPCJIM0006
- UPC:
- Brand: JimiLab
- MPN: VL103D
- Part #: IPCJIM0006
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Industrial PCs & IoT
JimiLab VL103D LTE GNSS Terminal LTE & GSM Network, Configurable Input/Outpu, Car Battery Protection
- Brand: JimiLab
- MPN: VL103D
- Part #: IPCJIM0006
Product URL: https://www.pbtech.co.nz/product/IPCJIM0006/JimiLab-VL103D-LTE-GNSS-Terminal-LTE--GSM-Network
Branch | New Stock | On Display |
---|---|---|
Albany | 0 | |
Glenfield | 0 | |
Queen Street | 0 | |
Auckland Uni | 0 | |
Newmarket | 0 | |
Westgate | 0 | |
Penrose | 0 | |
Henderson (Express) | 0 | |
St Lukes | 0 | |
Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Head Office | 0 | |
Hornby | 0 | |
Christchurch Central | 0 |
Features
Compact size with great power, the VL103D is a discreetly-installed, fully-featured tracker with LTE, GNSS, RS485 interface and the IP66 waterproof rating. LTE communication with GSM (2G) fallback ensures a solid connection in almost all cases, and the wide 9-90V input voltage range is compatible with virtually any vehicle. It is a perfect tracker for a wide range of use cases - stolen vehicle recovery and the management of motorcycles, passenger cars, and light commercial vehicles.
Product is including the tracking platform of 10 years subscriptions. Contact [email protected], to register account for free softtware and APP.
Specifications
GNSS | |
Positioning system | GPS+BDS+LBS |
Positioning accuracy | <2.5m CEP |
Tracking sensitivity | -165dBm |
Acquisition sensitivity | -148dBm |
TTFF (open sky) | Avg. hot start =1sec
Avg. cold start =32sec |
Cellular | |
Communication network | LTE CAT1/GSM |
Frequency | VL103D (L) LTE-FDD: B1/B2/B3/B4/B5/B7/B8/B28 GSM: B2/B3/B5/B8 VL103D (E) |
Power | |
Battery | 270mAh/3.7V industrial-grade Li-Polymer battery |
Input voltage | 9-90VDC |
Interface | |
LED indication | GNSS (Blue), Cellular (Green), Power (Red) |
SIM | Micro-SIM |
Digital inputs | ACC |
Digital outputs | Relay |
Configurable I/O | SOS (configurable as an extra digital output) |
ADC | 0-5V ADC detection |
Physical specification | |
Dimensions | 92.0 x 40.0 x 20.0mm |
Weight | 55g |
Operating environment | |
Operating temperature | -20? to +70? |
IP rating | IP66 |
Feature | |
Sensors | Accelerometer |
Scenarios | Vehicle movement alert, Speeding alert, Geo-fence entry/exit, Vehicle battery detection |
Driving behavior analysis | Harsh acceleration, Harsh braking, Harsh cornering, Collision |
* We reserve the right of final interpretation of this page. All information is for reference only and is subject to change without further notice.
