Partner POS Terminal E5 15.6 TFT LCD, PCT 1366x768, Intel i5-7300U 3.5Ghz, 4GB RAM, 128GB SSD 90W Adapter, Win10 IoT

Commercial Only
This product can only be sold to limited liability companies, local councils, government departments and schools. A limited liability company name or valid council, government department or school name must be entered during the checkout process.

Partner POS Terminal E5 15.6 TFT LCD, PCT 1366x768, Intel i5-7300U 3.5Ghz, 4GB RAM, 128GB SSD 90W Adapter, Win10 IoT

Part #: IPCPTN15607
Sign in to your commercial account or apply online now to view the price and order this product


Click & Collect: Select your store to check availability
Delivery: Order now and it ships on 29/08/2022 When will I receive it?
Commercial Only

Features

Ethan E5 Touch POS System - FLEXIBLE, POWERFUL, FUTURE-PROOF POS

The Ethan E5 is a 15.6" All in One POS solution that will perform at a high level and in adverse conditions with no difficulty. A technology-rich solution that offers industrial grade performance with a high-quality design will make a dramatic statement in your store's environment.

A Smart Investment Now

Retailers are challenged to operate as efficiently as possible, while still providing great customer experiences. The E5 touch POS terminal supports dual LAN, one network for internal ERP and secure data transfer and the other for Internet uses such as marketing and CRM.



An Investment that Lasts into the Future

Partner Tech's E5 offers you the flexibility to scale as your business needs change. This touch POS terminal support up to three individual display for retail smart applications, that include the main screen, digital signage display, and external guest facing display.



Built to Last

The E5 features a rugged design. It is fanless and ventless with IP-54 IP rating, which helps prevent damage from dust, and, with no moving parts, they are less likely to be damaged from occasional impacts or vibrations in busy retail environments. In addition some components vulnerable to damage from spills are located inside the base to help protect them.



Multi-Task

The E5 POS terminal is designed for multitasking. It can serve as both POS terminal and mini-KIOSK. The All-In-One stand with the thermal printer integrated can have all required cables well managed. Only one power adaptor is sufficient to support all operations for both E5 and the thermal printer, it is an ideal solution for business and services that require for mobility.



Display

15.6" Wide Screen All in one POS with FHD resolution and PCT

Flexible Interface

No matter what kind of interfaces your devices requires. The design of the E5 allows more flexibility

Speed

Customers want the convenience of quick, accurate service. The E5 features fast, reliable connectivity and a SATA 3.0 interface that gives you twice the data transfer speed as the previous model.

Please contact [email protected] for project.

Specifications

Item

E5

Display

15.6", Resolution 1366 x 768

Touch

15.6" Pcap Touch

CPU

Intel® Core™ i5-7300U (KABYLAKE-U Co-lay)

Memory

2 x 260 pin DDR4 SO-DIMM-2133 vertical type, Standard Spec: 4GB

Storage

HDD Standard: 500 GB; SSD Standard: 128 GB

External I/O Interface

2 x Serial ports, RS232 (RJ45), 0V/5V/12V selection by BIOS (COM1, COM2)
2 x LAN, ( IEEE 802.3 10/100/1000 Mbps Ethernet, RJ45)
1 x RJ11 port supports 2 cash drawers with 24V / 12V by jumper setting
1 x DC+12V out
4 x USB Type-A ports (USB3.0/2.0)
1 x DC +12V input power-jack
1 x Audio (1 * Line-out)
1 x HDMI port
1 x VGA

USB 2.0 at the side

USB 2.0 port at the side of POS PC for easy maintenance

RAID Function

RAID 0/1 (RAID function on Chip, 2nd SATA storage on SP-1060 stand or PS-103)

Speaker

1 * Speaker 3W

Optional Peripheral

MSR, IC Card Reader, Fingerprint, RFID, i-Button, VFD, Camera

Display Support

3 Independent Displays (Main Display + VGA + HDMI)

Expansion

Mini-PCIe interface

Optional M.2 SSD

M.2 PCIe SSD (Either one option with SATA storage)

Intel V-Pro

YES (i5 CPU only)

Operating System

Windows 10 IoT

Adaptor

AC-In 100~240V / DC-Out 12V, 90W / 180W

Mechanical

1. Front Panel IP65, whole system IP54, Fan-less Operation
2. VESA 75 x 75

Manufacturer Part No:
E5-1-K-i5-5514S
Brand:
Product Type:
-
UPC
-
Product Family:
POS Terminal
Shipping Weight:
1 kg
PB Part No:
IPCPTN15607
Product Model:
E5
Warranty: 24 months *
