Grandstream DP755 DECT Base Station - Carrier Grade - PTT,extendedrange - 20 concurrent calls
Grandstream DP755 DECT Base Station - Carrier Grade - PTT,extendedrange - 20 concurrent calls
- Brand: Grandstream
- MPN: DP755
- Part #: IPHGSM1079
- UPC:
- Brand: Grandstream
- MPN: DP755
- Part #: IPHGSM1079
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Business Phone Accessories





Grandstream DP755 DECT Base Station - Carrier Grade - PTT,extendedrange - 20 concurrent calls
- Brand: Grandstream
- MPN: DP755
- Part #: IPHGSM1079

Product URL: https://www.pbtech.co.nz/product/IPHGSM1079/Grandstream-DP755-DECT-Base-Station---Carrier-Grad
Branch | New Stock | On Display |
---|---|---|
Auckland - Albany | 0 | |
Auckland - Glenfield | 0 | |
Auckland - Queen Street | 0 | |
Auckland - Auckland Uni | 0 | |
Auckland - Newmarket | 0 | |
Auckland - Westgate | 0 | |
Auckland - Penrose | 0 | |
Auckland - Henderson (Express) | 0 | |
Auckland - St Lukes | 0 | |
Auckland - Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Auckland - Head Office | 0 | |
Auckland - East Tamaki Warehouse | 0 | |
Christchurch - Hornby | 0 | |
Christchurch - Christchurch Central | 0 | |
Dunedin | 0 |
Features
Grandstream DP755 Carrier Grade HD DECT Base Station, PTT, extended range, 20 concurrent calls.
The DP755 is a powerful DECT VoIP phone base station that pairs with up to 10 of Grandstream's DP series DECT handsets to offer mobility to business and residential users. It supports an outdoor range of up to 400 meters with the DP730 or up to 350 meters with DP722/DP720 as well as an indoor range of up to 50 meters to give users the freedom to move around their work or home.
This DECT VoIP phone base station supports up to 10 handsets and 20 SIP accounts while also offering 3-way voice conferencing, full HD audio, and integrated PoE. A shared SIP account on all handsets will add seamless unified features that give users the ability to answer all calls regardless of location in real-time. The DP755 supports a variety of auto-provisioning methods and TLS/SRTP/HTTPS encryption security. When paired with Grandstream's DP720, DP722, or DP730 handsets, the DP755 offers a powerful cordless DECT solution for any business or residential user.
Specifications
Manufacturer's Product Code
DP755
Air Interface
1880 - 1900 MHz
Number of Channels
10
Outdoor Range
up to 400 meters (DP730) or up to 350 meters (DP722/DP720)
Indoor Range
up to 50 meters
Ethernet
1 x 10/100 Mbps auto-sensing Ethernet port with integrated PoE
LED's
3 LED indicators: Power, Network, DECT pairing/Paging button
Protocol/Standards
SIP RFC3261, TCP/IP/UDP, RTP/RTCP, HTTP/HTTPS, ARP/RARP, ICMP, DNS (A record, SRV, NAPTR), DHCP, PPPoE, SSH, TFTP, NTP, STUN, SIMPLE, LLDP-MED, LDAP, TR-069, 802.1x, TLS, SRTP, IPv6
Voice Codecs
G.711µ/a-law, G.723.1, G.729A/B, G.726-32, iLBC, G.722, OPUS, G.722.2/AMR-WB (special order), in-band and out-of-band DTMF (in audio, RFC2833, SIP INFO), VAD, CNG, PLC, AJB
Telephony Features
Hold, transfer, forward, 3-way conference, downloadable phonebook (XML, LDAP, up to 3000 entries), call waiting, call log (up to 1500 records), auto answer, flexible dial plan, server redundancy and fail-over
QoS
Layer 2 QoS (802.1Q, 802.1P) and Layer 3 QoS (ToS, DiffServ, MPLS)
Security
User and administrator level access control, MD5 and MD5-sess based authentication, 256-bit AES encrypted configuration file, TLS, SRTP, HTTPS, 802.1x media access control, DECT authentication & encryption
Multi-language
English, Czech, German, Spanish, French, Hebrew, Italian, Dutch, Polish, Portuguese, Russian, Turkish, Arabic, Chinese Simple, Chinese Tradition, Japanese, Korean, Slovakian, Serbian
Upgrade/ Provisioning
Firmware upgrade via TFTP/HTTP/HTTPS and local uploading, mass provisioning using TR-069 or AES encrypted XML configuration file
Multiple SIP Accounts
Up to twenty (20) distinct SIP accounts per system; Each handset may map to up to 20 SIP account(s); Each SIP account may map to any handset(s)
Ring Group
Flexible options when multiple handsets share the same SIP account: Parallel Mode: all phones ring concurrently and after one phone answers, the remaining available phones can make new calls HS Mode: multiple handsets can call out on the same account, but all incoming calls are directed to a single handset
Power & Green Energy Efficiency
Universal Power Supply: Input AC 100-240V 50/60Hz; Output 5VDC 1A; Micro-USB connection; PoE: IEEE802.3af Class 1, 0.44W-3.84W
Dimensions (H x W x D)
140.31 x 64.98 x 105mm
Weight
Base unit: 140g; Universal power supply: 50g; Package: 370g
Temperature and Humidity
Operation: -10 to 45ºC (14 to 113ºF); Storage: -20º to 60ºC (-4 to 140ºF) Humidity: 10% to 90% non-condensing
Compliance
FCC: FCC Part 15B; FCC Part 15D; MPE; FCC ID CE: EN 55032; EN 55035; EN 61000-3-2; EN 61000-3-3; EN 60950-1; EN 301 489-1/-6; EN 301 406; EN 50385; RED NB Cert RCM: AS/NZS 32; AS/NZS 60950.1 ANATEL: ANATEL, EAC, UL (adapter)
