Dynamix LKV379P-DVB-TV2 HDMI to RF Digital Modulator with HDMI Loop Out Port. Supports Full HD 1080p30Hz. LCD Display, Menu Navigation Keys, 12V DC Power Adapter (Included).

PB Tech price: PB Tech price:
$309 20  +GST $355 58  inc GST
$309.20  +GST
$355.58  inc GST

Dynamix LKV379P-DVB-TV2 HDMI to RF Digital Modulator with HDMI Loop Out Port. Supports Full HD 1080p30Hz. LCD Display, Menu Navigation Keys, 12V DC Power Adapter (Included).

Part #: KVMDNX0379
2
PB Tech price: PB Tech price:
$309 20 $355 58
 +GST  inc GST


Click & Collect: Select your store to check availability
Delivery: Order now and it ships on 24/08/2022 When will I receive it?
$309.20  +GST
$355.58  inc GST

Six easy payments of $61.04 per week*

Laybuy lets you spread the cost of your purchase over 6, interest-free, weekly payments.

Click the button below or select Laybuy as your payment method during the checkout process.

If you do not have a Laybuy account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.
Learn more about Laybuy

Five easy payments of $73.68 per fortnight*

humm lets you spread the cost of your purchase over 5 or 10 interest free fortnightly payments.

Click the button below or select humm as your payment method during the checkout process.

If you do not have a humm account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.
Learn more about humm

Finance from $3.78 per week*

Get what you want at a price you can afford. Choose a finance term below to see the weekly repayment amount and apply online during checkout or in-store.

Choose a Finance Term

*Weekly payments are indicative only and based on a retail price of over a loan term of months at an interest rate of % p.a. and include a monthly service fee and a establishment fee (excludes optional Payment Protection Insurance).The total amount payable over the term of the loan is . Details of finance (including weekly payments, the total amount repayable over the term of the loan, interest rate and any applicable fees) can be confirmed with a detailed quote. Full disclosure of all of the terms of your finance will also be provided to you in the Finance Now disclosure statement for your consideration prior to confirmation of your purchase. All finance is subject to Finance Now terms and conditions and approval criteria.

Learn more about Finance Now

No payments or interest for 12 months available*

Q Card / Mastercard is your perfect shopping partner, combining the benefits of a credit card with the added ability to access a range of interest-free deals and payment holidays.

Learn more about Q Mastercard, apply online for one now, or email [email protected] to chat with our team.

*An Establishment fee of $55 applies to your first LTF transaction, a $35 Advance Fee applies to all subsequent LTF transactions. Standard Interest Rate, currently 25.99% p.a. applies to any outstanding balance at end of the interest free period. Lending criteria, $50 annual account fee, fees, terms and conditions apply.
Learn more about Q Card

  • Brand: Dynamix
  • MPN: LKV379P-DVB-TV2
  • Part #: KVMDNX0379
  • UPC:

What PB Tech customers are saying about this product...

See More Reviews

"We had an awkward setup at the back of our television, to monitor Freeview programs to the rest of the house tv's (bedrooms and kitchen). We had to keep replacing different compone ...view more"

J
By: JacquiP62 12/04/22
Verified Owner

"This is the second unit I have installed. One for my home and recently for my in-laws. Takes the SKY HDMI output and modulates it into a digital RF signal that sends HDMI quality s ...view more"

G
By: Guest 05/11/21

Features

DYNAMIX HDMI to RF Digital Modulator with HDMI Loop Out Port. Supports Full HD 1080p @ 30Hz, LCD Display, Menu Navigation Keys, 12V DC Power Adapter (Included).
This is an HDMI to DVB-T converter, the perfect solution to distribute HDMI signal to DVB-T1 standard digital cable television via coaxial cables. Output can be set as any channel number and distributed to all the TV's in the system directly via CATV splitter, Co-existing with all your current existing channels.

Features

- Distributes 1x HDMI signal to DVB-T1 standard digital cable television via coaxial cables
- Supports source to multiple displays via CATV splitter
- Supports DVB-T1 digital HD RF signal output
- Supports resolution up to FHD 1080p @ 60Hz
- Wall-mountable
- Easy installation

Specifications

HDMI Signal

HDMI1.3, fully compatible HDCP

HDMI Loop Out Port

Yes

HDMI DDC Signal

5Vp-p (TTL)

HDMI TMDS Signal

0.5 ~ 1.5Vp-p (TMDS)

Input HDMI Resolution Supported

480 [email protected] 60Hz, 480p @ 60Hz, 576i @ 50Hz, 576p @ 50Hz, 720p @ 50/60Hz, 1080i @ 50/60Hz, 1080p @ 50/60Hz

HDMI Graphics Resolution

1280x720 @ 60Hz, 1920x1080 @ 60Hz

Video Encoding

H.264

Audio Encoding

MPEG2

Coaxial Output Standard

DVB-T1

Coaxial Cable Required

RG6, RG7, RG11

Frequency

177.5 ~ 866MHz

Effective Bit Ratio

Max: 24M bits

Insert Loss

+2dBm

RF output Wattage (TX)

-10dBm ~ -13dBm

Delay Time

200-300ms (Depends on the decoding ability of receivers)

Audio Format

Stereo PMC (44.1kbps, 48kbps)

Power

DC 12V/1A

Product Consumption

<5W

Working Temperature

0°C~50°C

Stock Temperature

-10°C~70°C

Relative Humidity

0%~90%

Product Dimensions

158 x 115 x 33mm

Weight

520g

Colour

Nero

Manufacturer Part No:
LKV379P-DVB-TV2
Brand:
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
0.8 kg
PB Part No:
KVMDNX0379
Product Model:
LKV379P-DVB-TV2
Warranty: 24 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
