LevelOne KVM-0422, 4-Port KVM Switch, USB / VGA

PB Tech price
PB Tech price
$ 116 .52
 +GST
$ 134 .00
 inc GST
$116.52  +GST
$134.00

LevelOne KVM-0422, 4-Port KVM Switch, USB / VGA

  • Brand: LevelOne
  • MPN: KVM-0422
  • Part #: KVMLEL0422
  • UPC: 878742003708
PB Tech price
$ 116 .52 $ 134 .00
 +GST  inc GST

No store stock available.

Click & Collect: Select your store to check availability
Delivery: Order now and it ships on 07 Oct When will I receive it?
$116.52  +GST
$134.00

Features

The KVM-0422 4-Port USB KVM Switch from LevelOne offers users with an easy to install KVM switch that can manage four computers from a single monitor, keyboard and mouse.

It allows users to access, control, boot and reboot four USB-enabled multimedia computers using a single USB keyboard, mouse and monitor.

Flexible Multi-Computer Management Feature
Users are now offered with flexible multi-computer management support. The KVM-0422offers users with user-programmable simultaneous or independent PC and audio switching. This enables users to work on one computer while simultaneously using the other computers for work or fun.

The KVM-0422 supports PC and Macintosh (MAC G3, G4, iMAC) platforms.

One Keyboard, Mouse and Monitor controlling Two Computers
The LevelOne KVM-0422 connects four computer systems to a single USB keyboard, USB mouse and monitor.

The KVM-0422 is a Plug-and-Play KVM switch that requires no power supply and no additional software installation. Users simply connect the KVM switch to the USB mouse and keyboard and screen ports on each by using the included cables.

Easy to Switch between Computers
The KVM-0422 switches between computers either through the pushbuttons located on the switch or by using keyboard hot keys. The KVM switch includes a Windows® and Mac based utility allowing users to select and monitor active PCs from their desktop as well as to configure the keyboard hotkeys for easy switching between computers.

The KVM-0422 further supports hot-plugging for easy maintenance of computers without shutting down the KVM switch or the computer. The LED display offers an "at-a-glance" status display for easy computer activity assessment.

- Flexible switching for an uninterrupted multi-platforms experience
- Control and manage four computers using a single USB keyboard and mouse and monitor
- Simultaneous and independent PC user-programmable switching
- High 2048 x 1536 pixels VGA resolution
- USB interface power supply
- Easy switching between computers with keyboard hotkeys push button and software selection
- At-a-glance LED display for easy monitoring of PC activity
- True Plug-and-Play operation without any software installation or power supply
- Windows-based switching software utility included

Specifications

Console Port:
Keyboard: USB x 1
Mouse: USB x 1
Video: HDB 15-pin (Female)

PC Port:
4 x HDB 15-pin Female
(VGA port with intergrated USB interface)

Monitor Supported:
VGA / SVGA / QXGA / WUXGA

LEDs:
4 LEDs

PC Selection:
Push Button / Hot Key / Auto Switching

Power:
USB Interface Power

Cables:
USB KVM Combo Cable Sets (1.8m) x 4

Max. Resolution:
2048 x 1536

Scanning Interval:
10,15,20,25,30,35,40,45,50,55,60 Seconds

Operating Temp.:
0~50°C

Storage Temp:
-20~60°C

Humidity:
0~80 % RH Non-Condensing

Enclosure:
High-impact Plastic

Weight (g):
207

Dimensions (L x W x H):
164mm x 72mm x 26mm

OS Supported:
Win & Mac
Manufacturer Part No:
KVM-0422
Brand:
Product Type:
-
UPC
878742003708
Product Family:
-
Shipping Weight:
1.323 kg
PB Part No:
KVMLEL0422
Product Model:
-
Warranty: 24 months *
