LENKENG LKV375N DBaseT HDMI Extender over Single Cat5e/6 cable up to 70m. Extends HDMI & IR. Includes Dual Power Adapters for Receiver & Transmitter, 1080p60Hz up to 60m, 4K2K30Hz up to 35m. HDCP1.4

LENKENG LKV375N DBaseT HDMI Extender over Single Cat5e/6 cable up to 70m. Extends HDMI & IR. Includes Dual Power Adapters for Receiver & Transmitter, 1080p60Hz up to 60m, 4K2K30Hz up to 35m. HDCP1.4
PB Tech price: PB Tech price:
$228 70  +GST $263 00  inc GST
  • Overview
  • Features
  • Specifications
  • Reviews

Generating Print Page

LENKENG LKV375N DBaseT HDMI Extender over Single Cat5e/6 cable up to 70m. Extends HDMI & IR. Includes Dual Power Adapters for Receiver & Transmitter, 1080p60Hz up to 60m, 4K2K30Hz up to 35m. HDCP1.4

LENKENG LKV375N DBaseT HDMI Extender over Single Cat5e/6 cable up to 70m. Extends HDMI & IR....

  • Brand: LENKENG
  • MPN: LKV375N
  • Part #: KVMLNK1031
  • UPC:
  • Extension Distance:100m
  • Maximum Supported Resolution:4096x2160
  • Video Interface:HDMI
  • Device Type:Transmitters & Receivers
  • Wireless Technology:N/A
PB Tech price: PB Tech price:
$228 70 $263 00
 +GST  inc GST


Click & Collect: Select your store to check availability
Delivery: Order now and it ships on 25/06/2021 When will I receive it?

Six easy payments of $45.15 per week*

Laybuy lets you spread the cost of your purchase over 6, interest-free, weekly payments.

Click the button below or select Laybuy as your payment method during the checkout process.

If you do not have a Laybuy account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.
Learn more about Laybuy

Five easy payments of $54.18 per fortnight*

humm lets you spread the cost of your purchase over 5 or 10 interest free payments.

Click the button below or select humm as your payment method during the checkout process.

If you do not have a humm account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.
Learn more about humm

Finance from $2.96 per week*

Get what you want at a price you can afford. Choose a finance term below to see the weekly repayment amount and apply online during checkout or in-store.

Choose a Finance Term

*Repayments shown above are indicitive only and may vary. Ts and Cs and lending criteria apply.
Learn more about Finance Now

No payments or interest for 12 months available*

Q Card / Mastercard is your perfect shopping partner, combining the benefits of a credit card with the added ability to access a range of interest-free deals and payment holidays.

Learn more about Q Mastercard, apply online for one now, or email finance@pbtech.co.nz to chat with our finance team.

*Ts and Cs and lending criteria apply.
Learn more about Q Card

Similar in-stock products available at PB Tech right now

Features

LENKENG HDBaseT HDMI Extender over Single Cat5e/6 cable up to 70m. Extends HDMI & IR. Includes Dual Power Adapters for Receiver & Transmitter, 1080p @ 60Hz up to 60m, 4K2K @ 30Hz up to 35m. HDCP1.4

This HDBaseT single network cable extender/transmitter kit transmits HDMI signal up to 70M over CAT6 fluently and clearly. It is lossless in signal and supports 3D, 24bits deep colour, 4K2K, CEC and HDCP.

- Apply HDBaseT extend technology
- Uncompressed HDMI video signal
- Support full HD 1080p @ 60Hz, 3D, 4K2K
- Extend 1080p signal over CAT6A up to 70M
- Supports bi-directional IR pass back
- Supports HDCP, CEC, 24 deep colour
- Supports uncompressed LPCM audio and compressed DTS-HD, Dolby True HD
- Includes dual power adapters for both transmitter and receiver



Download data sheet: https://dynamix.co.nz/content/images/PDF/lkv375n.pdf

Specifications

Transmission Length

CAT5E/CAT6

60M: Up to 1080p@60Hz 36bppp
35M: 1080p@60Hz 48bppp, 1080p@60Hz 3D, 4K2K 30Hz

CAT6A

70M: Up to 1080p@60Hz 36bppp
40M: 1080p@60Hz 48bppp, 1080p@60Hz 3D, 4K2K 30Hz

General

HDMI Signal

4K2K, Compatible with HDCP, Supports CEC and 24bits deep colour

Resolution Supported

480i/480p/576i/576p/720p/1080i/1080p/3D/4K2K

Audio

LPCM, DTS-HD, Dolby True HD

Network Cable

CAT5E, CAT6, CAT6A

Infrared Back

Supports 20kHz ~ 60kHz wide frequency
devices and Bi-directional IR Transmission

Power Supply

<8W

Product Dimension (LxWxH)

98.5 x 66.5 x 23mm

Enclosure Material

Metal

Weight

TX: 79g RX: 107g

Colour

Black

Manufacturer Part No: LKV375N Brand: LENKENG Product Type: -
UPC - Product Family: - Shipping Weight: 0.705 kg
PB Part No: KVMLNK1031 Product Model: LKV375N

Warranty: 24 months local warranty *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.

Reviews

5 out of 5 StarsBased on 1 Reviews

5 Stars
1
4 Stars
0
3 Stars
0
2 Stars
0
1 Star
0

Filter Results

Do you own this product?

Write a review while signed in and go into the draw to win great prizes each month! Learn more WRITE A REVIEW
Displaying 1 - 1 of 1 reviews

great buy

we had problems with older projector with different video senders but this one works just great ,very pleased
ordered it last night got it today (non stock item!) we are very happy

I
By: IanL518 15/03/19
Verified Owner
0 out of 0 users found this review helpful
Did you find it helpful?
