LENKENG LKV401MS 4x1 HDMI Multiviewer Switch
Includes 4x HDMI Inputs & 1x HDMI Output - Displays Video from 4x HDMI Sources Simultaneously on a Single Monitor - Supports up to 1080p60Hz - Includes IR - Plug & Play
LENKENG LKV401MS 4x1 HDMI Multiviewer Switch
Includes 4x HDMI Inputs & 1x HDMI Output - Displays Video from 4x HDMI Sources Simultaneously on a Single Monitor - Supports up to 1080p60Hz - Includes IR - Plug & Play
- Brand: LENKENG
- MPN: LKV401MS
- Part #: KVMLNK1062
- UPC:
- Brand: LENKENG
- MPN: LKV401MS
- Part #: KVMLNK1062
- UPC:
What PB Tech customers are saying about this product...
See More Reviews"Just plugged it in and it works as expected, I can see all 4 screens at the same time, very great utility to have, can also be used as an HDMI switcher too, can choose to view 1 sc ...view more"
COMBO DEALS: Buy Together and SAVE!
Dynamix C-HDMIHSE-0 10Gbps High-Speed Slimline HDMI Cable - with Ethernet - 50cm Max Res 4K2K 24...
$5.49 +GST
$6.31
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular AV Switches
LENKENG LKV401MS 4x1 HDMI Multiviewer Switch Includes 4x HDMI Inputs & 1x HDMI Output - Displays Video from 4x HDMI Sources Simultaneously on a Single Monitor - Supports up to 1080p60Hz - Includes IR - Plug & Play
- Brand: LENKENG
- MPN: LKV401MS
- Part #: KVMLNK1062
Product URL: https://www.pbtech.co.nz/product/KVMLNK1062/LENKENG-LKV401MS-4x1-HDMI-Multiviewer-Switch-Inclu
| Branch | New Stock | On Display |
|---|---|---|
| Auckland - Albany | 0 | |
| Auckland - Glenfield | 0 | |
| Auckland - Queen Street | 0 | |
| Auckland - Auckland Uni | 0 | |
| Auckland - Westgate | 0 | |
| Auckland - Penrose | 0 | |
| Auckland - Henderson (Express) | 0 | |
| Auckland - St Lukes | 0 | |
| Auckland - Manukau | 0 | |
| Hamilton | 0 | |
| Tauranga | 0 | |
| New Plymouth | 0 | |
| Palmerston North | 0 | |
| Petone | 0 | |
| Wellington | 0 | |
| Auckland - Head Office | 4 | |
| Auckland - East Tamaki Warehouse | 0 | |
| Christchurch - Hornby | 0 | |
| Christchurch - Christchurch Central | 0 | |
| Dunedin | 0 |
Features
The LK-LKV401MS is a HDMI 4 x 1 Quad Multiviewer Switcher, with 4 HDMI inputs, and 1 HDMI output, displays video from four HDMI source devices simultaneously on a single monitor. Switch to and control any of the four source devices while monitoring the other three connections in real time. It supports quad mode, full screen mode and dual mode. HDMI signal resolution supported is up to 1080p @ 60Hz. It is widely used in many applications that require real-time monitoring of multiple devices, like DVD player, cameras and computers. It is the perfect solution for the applications need to monitor several sources at the same time.
- Display Modes
- Full screen mode
- Two screen mode
- Quad mode
- Support 4 HDMI inputs, 1 HDMI output
- Support quad mode, full screen mode and dual mode
- HDMI signal resolution supported is up to 1080p @ 60Hz
- Support to switch mode by remote control and button in the front of the panel
- Support seamless handover
- Plug and play
- Metal casing, stable and durable
- Wall-mountable design, convenient for installation
Specifications
Input
HDMIx1,IRx1,RS232x1
Output:
HDMIx1
Input resolution:
480i to 1080P @ 60Hz
Output resolution:
720p, 1080I and 1080P @ 60 Hz
Control:
IR
ESD protection:
+/-8KV(Airgap discharge),+/-4KV(Contact discharge)
Power supply:
DC 12V/2.0A
Operation TEMP:
0C-40C
Stock TEMP:
-20C-60C
Relative humidity:
20-90%RH
Wattage:
20w(MAX)
