LENKENG 4K2K HDMI Extender Over Single CAT5/5e/6 Cable. Supports Res up to 4Kx2K 30Hz. One-Way IRPass-Through. One to Many Connection. Transmit up to 120m. Receiver unit only

PB Tech price
PB Tech price
$ 121 .74
 +GST
$ 140 .00
 inc GST
$121.74  +GST
$140.00

LENKENG 4K2K HDMI Extender Over Single CAT5/5e/6 Cable. Supports Res up to 4Kx2K 30Hz. One-Way IRPass-Through. One to Many Connection. Transmit up to 120m. Receiver unit only

  • Brand: LENKENG
  • MPN: LKV683-4.0-RX
  • Part #: KVMLNK1171
  • UPC:
PB Tech price
$ 121 .74 $ 140 .00
 +GST  inc GST

No store stock available.

Click & Collect: Select your store to check availability
Delivery: Order now and it ships on 02 Oct When will I receive it?
$121.74  +GST
$140.00
  • Brand: LENKENG
  • MPN: LKV683-4.0-RX
  • Part #: KVMLNK1171
  • UPC:

Features

HDMI extender, extend your HDMI video/audio with the resolution of 4K×2K@30Hz up to 120m(394 feet) via CAT6 network cable. Supports IR passback, to control media playback of the signal source device at the display location.

4kx2k @ 30Hz

Support 4kx2k@30Hz video transmission, the image can be more clear,higher saturation and showed more outstanding details.

Upgrading technology, lower latency

Adopt new upgraded transmission technology, with lower transmission dela and better compatibility with display source, signal source and transmission cable.

120m Transmission

Converting HDMI audio and video signals into standard network signals, and the longest transmission distance can reach 120 meters.

IR passback

The receiving end can return 20-60KHz infrared radio frequency signals to the transmitting end , and the remote controller of the signal source can be used to remotely switch content, switch machine and etc.

Multiple Protection

Adopted multiple protections like ESD protection, surge protection, lightning protection to make products safer and more reliable

Specifications

HDMI compliance

HDMI1.4

HDCP compliance

HDCP1.4

Video support

480i @ 60Hz,480p @ 60Hz,576i @ 50Hz,576p @ 50Hz, 720p @ 50/60Hz,1080i @ 50/60Hz,1080p @ 50/60Hz, 4K @ 24/25/30Hz

Network Cable

UTP/STP CAT5E/6

Transmission distance

Up to 120m transmission distance for 4K@30Hz, full HD over single CAT6

Input DDC signal

Supports 20~60KHz IR devices

Mechanical

Colour

Black

Dimensions (L×W×H mm)

107.3 (W) ×94 (D) × 23.7 (H) mm 2pcs

Net weight

TX: 170g
RX: 167g

Power supply

5V/2A

Power consumption

6W,4W

Operation temperature

0°C~60°C

Manufacturer Part No:
LKV683-4.0-RX
Brand:
LENKENG
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
0.5 kg
PB Part No:
KVMLNK1171
Product Model:
-
Warranty: 24 months *
