LENKENG 4x4 HDMI Extender Kit Matrix Switch. Includes 1x 4-Port Transmitter & 4x Recievers.SupportsPoC, Supports Res 4K 60Hz up to 70m. Remote. Not Suitable for Cat5e Cable
LENKENG 4x4 HDMI Extender Kit Matrix Switch. Includes 1x 4-Port Transmitter & 4x Recievers.SupportsPoC, Supports Res 4K 60Hz up to 70m. Remote. Not Suitable for Cat5e Cable
- Brand: LENKENG
- MPN: LKV844
- Part #: KVMLNK1185
- UPC:
- Brand: LENKENG
- MPN: LKV844
- Part #: KVMLNK1185
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Related Promotions
Popular Wired AV Extenders





LENKENG 4x4 HDMI Extender Kit Matrix Switch. Includes 1x 4-Port Transmitter & 4x Recievers.SupportsPoC, Supports Res 4K 60Hz up to 70m. Remote. Not Suitable for Cat5e Cable
- Brand: LENKENG
- MPN: LKV844
- Part #: KVMLNK1185

Product URL: https://www.pbtech.co.nz/product/KVMLNK1185/LENKENG-4x4-HDMI-Extender-Kit-Matrix-Switch-Includ
Branch | New Stock | On Display |
---|---|---|
Auckland - Albany | 0 | |
Auckland - Glenfield | 0 | |
Auckland - Queen Street | 0 | |
Auckland - Auckland Uni | 0 | |
Auckland - Newmarket | 0 | |
Auckland - Westgate | 0 | |
Auckland - Penrose | 0 | |
Auckland - Henderson (Express) | 0 | |
Auckland - St Lukes | 0 | |
Auckland - Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Auckland - Head Office | 0 | |
Auckland - East Tamaki Warehouse | 0 | |
Christchurch - Hornby | 0 | |
Christchurch - Christchurch Central | 0 | |
Dunedin | 0 |
Features
This device is a 4x4 HDMI matrix extender designed for network cable use. It comes equipped with 4 HDMI inputs, 4 RJ45 outputs, & 4 HDMI loop-outs. The 4 HDMI outputs deliver high-definition audio & video signals to 4 UHD displays locally, while the 4 RJ45 outputs extend these signals up to 70m away to 4 additional UHD displays via 4 receivers. It offers versatile control options, including RS-232 control, Ethernet control, button control, & remote control, making input & output switching & configuration effortless. This product is an ideal choice for applications such as security, school education, exhibition centres, multimedia conferences, & more.
- Zero latency transmission
- Support resolution up to 4K @ 60Hz
- Support 4x HDMI inputs & 4x HDMI loop-out
- Support 4x HDMI outputs via CAT6/6A/7 with transmission distance up to 70 meters
- The receiver can extract the digital audio from the transmitter through the S/PDIF port
- Support IR passback (20~60kHz)
- Support PoC, only the transmitter needs to be plugged in
- Support EDID management
- Support button control, remote control, Ethernet control & RS-232 control
- Lightning protection, surge protection, ESD protection
Specifications
HDMI version
HDMI 2.0
HDCP version
HDCP 2.2, HDCP 1.4
Transmission media
Cat6/Cat6A/Cat7
Transmission distance
=70m
Video bandwidth
600MHz (18Gbps)
Resolution supported
3840×2160 @ 24/25/30/50/60Hz, 4096×2160 @ 24/25Hz, 1080i @ 50/60Hz, 1080p @ 50/60Hz, 720p @ 50/60Hz, 576i @ 50Hz, 576p @ 50Hz, 480i @ 60Hz, 480p @ 60Hz, 3440×1440, 2560×1440, 2560×1080, 2048×1080, 1920×1440, 1280×960, 1280×800, 1280×768, 1680×1050, 1360×768, 1366×768, 1600×900, 1024×768, 800×600
HDR10
Yes
HDMI loop-out
TX:Yes
IR passback
Unidirectional
S/PDIF audio separation
RX:Yes
EDID DIP switch
TX:Yes
Audio format supported
LPCM/DTS-HD/DTS-Audio/Dolby Digital 5.1CH/Dolby Atmos
Input TMDS signal
0.5~1.2Vp-p
Input DDC Signal
5Vp-p
RS-232 control
Yes
Ethernet control
Yes
Remote control
Yes
Power over cable (PoC)
TX to RX
HDMI interface
Type-A 19 Pins, Female
Case material
Iron
Dimensions
TX: 411.0(L)×147.0(W)×29.0(H) mm
RX: 105.5(L)×02.5(W)×20(H) mm
Weight
TX :1530g, RX: 243g
Color
Black
Power supply
DC12V/3A
Consumption
TX+RX=30W
Working temperature
-20~60°C
Storage temperature
-30~70°C
Humidity (no condensation)
0~90%RH (no condensation)
Protection
ESD protection
1a Contact discharge level 2 (±4KV)
1b Air discharge level 3 (±8KV)
Implementation of the standard: IEC61000-4-2
Lightning protection, Surge protection
