Features
The ST121SHD50 HDMI over Cat5e/Cat6 Video Extender kit lets you extend HDMI video and audio by up to 165 feet (50 Meters) over dual Cat5e cables, or 130 feet (40 Meters) over dual Cat6 cables. For added versatility the kit features Power Over Cable and only requires a single power adapter that can be connected to either the Transmitter or Receiver.
With support for High-Definition resolutions of up to 1920x1080 / 1080p and the accompanying digital audio, this cost-effective HD extender can easily be installed using new or existing Ethernet infrastructure wiring. For a convenient plug-and-play installation, the HDMI extender features built-in EDID monitor emulation, which ensures native resolution and maximum compatibility with your display or projector.
For added flexibility and convenience, HDMI cables up to 32ft (10m) can be connected to both the local and remote units, which lets you extend your HDMI signal to even further distances.
The HDMI extender kit offers a point-to-point digital signage solution right out of the box, including both local transmitter and remote receiver units, along with optional hardware that lets you mount the units as needed. Plus, with Power Over Cable, you can easily extend an HDMI signal in areas where access to power outlets is limited.
Specifications
Audio
Yes
Cabling
Cat 5 UTP or better
Daisy-Chain
No
Ports
1
Rack-Mountable
Yes
General Specifications
Maximum Distances - (1080i only)
CAT5E (stranded) - 40m (130 ft)
CAT5E (solid) - 50m (165 ft)
CAT6 (stranded or solid) - 50m (165 ft)
Max Distance
50 m / 165 ft
Maximum Digital Resolutions
1080p / 1920x1080
Supported Resolutions
1080p - with CAT6 cabling up to 40m (130ft), solid CAT5 cabling up to 20m (65 ft) and stranded CAT6 up to 16m (52 ft)
1080i - with CAT6 and solid CAT5 cabling up to 50m (165ft), and stranded CAT6 up to 40m (130 ft)
See product manual for further details
Wide Screen Supported
Yes
Local Unit Connectors
1 - HDMI (19 pin) Female
2 - RJ-45 Female
Remote Unit Connectors
1 - HDMI (19 pin) Female
2 - RJ-45 Female
LED Indicators
1 - Power
Center Tip Polarity
Positive
Input Current
0.5 A
Input Voltage
100 ~ 240 AC
Output Current
1.5 A
Output Voltage
12 DC
Plug Type
M
Power Consumption (In Watts)
18
Power Source
AC Adapter Included
Humidity
0% - 80 %
Operating Temperature
0°C to 40°C (32°F to 104°F)
Storage Temperature
-10°C to 60°C (14°F to 115°F)
Colour
Black
Enclosure Type
Aluminum
Dimensions
Height
0.8 in (21 mm)
Length
3.1 in (80 mm)
Width
2 in (51 mm)
