Huawei eKitEngine AP361 (AX1800) Dual-Band 4-Stream Wi-Fi 6 Access Point (PoE 10W)

PB Tech price
PB Tech price
$ 208 .70
 +GST
$ 240 .00
 inc GST

Out of stock

Huawei eKitEngine AP361 (AX1800) Dual-Band 4-Stream Wi-Fi 6 Access Point (PoE 10W)

  • Brand: Huawei
  • MPN: 50086871
  • Part #: NAPHUA50086871
  • UPC:
PB Tech price
$ 208 .70 $ 240 .00
 +GST  inc GST

No store stock available. See in-stock alternatives

Click & Collect: Collect unavailable
Delivery: Out of stock When will I receive it?
  • Brand: Huawei
  • MPN: 50086871
  • Part #: NAPHUA50086871
  • UPC:

Ethernet Ports

1

USB Ports

None

WiFi Bands

Dual

Wireless Technology

WiFi 6 (802.11ax)

Wireless Transmission Speed

1775Mbps

Pack Size

1-Pack

Product is out of stock. View similar products in-stock at PB Tech

Features

Settled AP | 802.11ax | 1.775 Gbps device rate | Dual-radio | 80 access users recommended | Max. 128 access users | 23 dBm transmit power | Smart antenna | 20 m optimal coverage range

Wireless Network with Guaranteed Security

WPA3 with industry's strongest encryption ensuring network security.

AI-based Intelligent Signal Optimization

Adaptive channel adjustment, ensuring Internet access signal quality 20% greater coverage range and one more wall penetrated.

Seamless Roaming

Seamless roaming steering technology Eliminating service interruption for mobile terminals

Powerful Forwarding capabilities

Smooth multi-channel HD video conferencing without frame freezing, improving user experience

Specifications

Wi-Fi standard

2.4G: 802.11b/g/n/ax 5G: 802.11a/n/ac/ac Wave 2/ax

Installation Type

Wall,Ceiling (Solid Wall/Gypsum Board/Spring Tee/Flat-Edge T-Rail/Channel Rail/Beam/Threaded Rod)

Optimal Signal Distance (m)

20

Max Number of Access Users

128

Recommended Number of Access Users

80

Device Rate

1.775 Gbps

Maximum number of physical ports on the entire device

GE (RJ45) x 1, 10M/100M/1000M auto-sensing

Radio number

2

Maximum channel bandwidth [MHz]

Radio 0 (2.4 GHz): 40 MHz Radio 1 (5 GHz): 80 MHz

Maximum transmit power

2.4 GHz: 20 dBm/chain 23 dBm (combined power) 5 GHz: 20 dBm/chain 23 dBm (combined power) Note: In V200R024C10 and later versions, the combined power is increased to 23 dBm by default. In versions earlier than V200R024C10, the combined power is only 20 dBm. To increase the transmit power for the AP running an earlier version, install the corresponding patch by referring to the announcement on the official website.

MIMO spatial streams

Radio 0 (2.4 GHz): 2x2 Radio 1 (5 GHz): 2x2

Maximum power consumption [W]

9.4

Input voltage range [V]

PoE: 802.3af

Dimensions without packaging (H x W x D) [mm(in.)]

Diameter x depth: 180 mm x 35 mm (7.09 in. x 1.38 in.)

Dimensions with packaging (H x W x D) [mm(in.)]

200 mm x 231 mm x 61 mm (7.87 in. x 9.09 in. x 2.40 in.)

Weight without packaging [kg(lb)]

0.45 kg (0.99 lb)

Weight with packaging [kg(lb)]

0.75 kg (1.65 lb)

Long-term operating temperature [°C(°F)]

0°C to 40°C (32°F to 104°F) (From 1800 m to 5000 m [5905.51 ft. to 16404.20 ft.], the maximum temperature of the device decreases by 1°C [1.8°F] for every 300 m [984.25 ft.] increase in altitude.)

Long-term operating relative humidity [RH]

5% RH to 95% RH, non-condensing

Radio interface

Built-in smart antennas

Antenna gain

2.4G: 4 dBi/chain (peak) 2 dBi (combined gain) 5G: 5 dBi/chain (peak value) 3 dBi (combined gain)

Operating frequency band

2.4GHz,5GHz

Manufacturer Part No:
50086871
Brand:
Product Type:
-
UPC
-
Product Family:
eKitEngine
Shipping Weight:
1 kg
PB Part No:
NAPHUA50086871
Product Model:
AP361
Warranty: 12 months *
