Ruckus ZoneFlex H510 Wave 2, MU-MIMO, 2X2:2, Dual-Band AC1200 Wall-Mounted Wi-Fi Access Point, Switch, 5 x GbE, 802.3af PoE 12.9W

Ruckus ZoneFlex H510 Wave 2, MU-MIMO, 2X2:2, Dual-Band AC1200 Wall-Mounted Wi-Fi Access Point, Switch, 5 x GbE, 802.3af PoE 12.9W
PB Tech price: PB Tech price:
$520 00  +GST $598 00  inc GST
  • Overview
  • Features
  • Specifications
  • Reviews
  • Q & A

Generating Print Page

Ruckus ZoneFlex H510 Wave 2, MU-MIMO, 2X2:2, Dual-Band AC1200 Wall-Mounted Wi-Fi Access Point, Switch, 5 x GbE, 802.3af PoE 12.9W

Ruckus ZoneFlex H510 Wave 2, MU-MIMO, 2X2:2, Dual-Band AC1200 Wall-Mounted Wi-Fi Access Point,...

  • Brand: Ruckus
  • MPN: 901-H510-WW00
  • Part #: NAPRKS0001
  • UPC:
  • USB Ports:1
  • Wireless Technology:802.11ac
  • Wi-Fi Bands:Dual
  • Ethernet Ports:5
  • Wireless Transmission Speed:Not Specified
PB Tech price: PB Tech price:
$520 00 $598 00
 +GST  inc GST

Click & Collect: Select your store to check availability
Delivery: Order now and it ships on 20/07/2020
When will I receive it?

Four easy payments of $153.99 per fortnight*

Oxipay lets you spread the cost of your purchase over 4 fortnightly payments.

Click the button below or select Oxipay as your payment method during the checkout process.

If you do not have an Oxipay account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.
Learn more about Oxipay

Six easy payments of $102.66 per week*

Laybuy lets you spread the cost of your purchase over 6, interest-free, weekly payments.

Click the button below or select Laybuy as your payment method during the checkout process.

If you do not have a Laybuy account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.
Learn more about Laybuy

Finance from $5.83 per week*

Get what you want at a price you can afford. Choose a finance term below to see the weekly repayment amount and apply online during checkout or in-store.

Choose a Finance Term

*Repayments shown above are indicitive only and may vary. Ts and Cs and lending criteria apply.
Learn more about Finance Now

No payments or interest for 12 months available*

Q Card / Mastercard is your perfect shopping partner, combining the benefits of a credit card with the added ability to access a range of interest-free deals and payment holidays.

Learn more about Q Mastercard, apply online for one now, or email finance@pbtech.co.nz to chat with our finance team.

*Ts and Cs and lending criteria apply.
Learn more about Q Card

Features

ZONEFLEX 802.11AC DUAL-BAND CONCURRENT 2.4 GHZ & 5 GHZ ACCESS PORTS POE IN POE OUT (ONE PORT) USB PORT. DOES NOT INCLUDE DC POWER SUPPLY.

High Performance 802.11ac Wave 2 Integrated Wired/wireless Wall Switch

The ZoneFlex H510 is the industry's first Wave 2 802.11ac wired and wireless wall switch using Ruckus' patented BeamFlex+ adaptive antenna technology to deliver high-speed 802.11ac Wi-Fi in an ultra-sleek, low-profile design that can be discretely installed over a standard electrical junction box. Ideal for offering converged services in hotel guest rooms, student residences, and multi-dwelling units, the ZoneFlex H510 provides an easy way to offer multiple connections in a single room without multiple cables.

The ZoneFlex H510 supports Multi-User MIMO (MU-MIMO) as a Wave 2 solution and can increase network throughput by transmitting to two Wave 2 clients at the same instant in time. This efficient utilization of the Wi-Fi channel boosts performance for Wave 2 clients but also frees up airtime for all clients, which means even non-Wave 2 clients see a performance benefit.

The "mobile device ready" ZoneFlex H510 with BeamFlex+ adapts in real time to client device location and physical orientation, delivering consistent Wi-Fi performance. The BeamFlex+ adaptive antenna system of the ZoneFlex H510 is optimized to deliver best-in-class Wi-Fi coverage and performance in hotel guest rooms and MDU residences.

Equipped with four Ethernet ports for in-room access, the ZoneFlex H510 can be used to connect a range of wired network devices such as IPTV set top boxes, IP telephones, or networked minibars while simultaneously providing dual band 802.11ac wireless LAN coverage. An IEEE 802.3af-compliant Power-over-Ethernet (PoE) port on the H510 allows devices such as IP telephones to be powered directly from the wall switch. The H510 itself may be powered via standard PoE or a DC power adapter.

The ZoneFlex H510 offers maximum flexibility and future-proofed utility. It is designed to securely support future add-on radio modules for wireless connectivity beyond best-in-class Wi-Fi. The cable pathways at the rear, support legacy cabling such as RG6 or CAT3/CAT5. Existing services such as video and voice over Ethernet can co-exist within the same junction box, reducing both installation time and construction costs. The H510 can be deployed as a standalone device or centrally managed by SmartZone, ZoneDirector, or FlexMaster management platforms.

Specifications

Power
POE 802.3af/802.3at
48VDC input

Physical Size
90 mm x 145 mm x 29 mm

Weight
230 g
292 g with bracket

Physical Ports

4 10/100/1000 Mbps Base-T 802.3, 802.3u, RJ-45 Ethernet access ports.
1 10/100/1000 Mpbs Base-T 802.3, 802.3u, 802.3ab, 802.3af (802.3at class 4) PoE input, RJ-45
USB 2.0

Mounting Options

Electrical wallbox; Standard US and EU single gang wall jack
Optional bracket for offset & wall mount

Environmental Conditions
Operating Temperature: 32°F (0°C) - 104°F (40°C)
Operating Humidity: 15% - 95% non-condensing

Power Draw

Idle: 6.5 W
Typical: 7.3 W
Peak, no PoE out load: 9.2W
Max load on PoE out:
4W with 802.3af for PoE
12.95W with 802.3at PoE in
Manufacturer Part No: 901-H510-WW00 Brand: Ruckus Product Type: -
UPC - Product Family: ZoneFlex Shipping Weight: 1.5 kg
PB Part No: NAPRKS0001 Product Model: -

Warranty: 12 months local warranty *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.

Reviews

There are currently no reviews for this product

Filter Results

Do you own this product?

Write a review and go into the draw to win great prizes each month! Learn more WRITE A REVIEW

Customer Questions & Answers

Want to know something about this product? Ask a question which other users may be able to answer.

Ruckus ZoneFlex H510 Wave 2, MU-MIMO, 2X2:2, Dual-Band AC1200 Wall-Mounted Wi-Fi Access Point, Switch, 5 x GbE, 802.3af PoE 12.9W

  • Brand: Ruckus
  • MPN: 901-H510-WW00
  • Part #: NAPRKS0001
  • UPC:
PB Tech price: $520.00 Excluding GSTPB Tech price:$598.00 Including GST
Date Created: 01:42, 10-07-2020
Product URL: https://www.pbtech.co.nz/product/NAPRKS0001/Ruckus-ZoneFlex-H510-Wave-2-MU-MIMO-2X22-Dual-Band
Branch
New Stock
On Display
Albany
0
North Shore
0
Auckland CBD
0
Auckland Uni
0
Penrose
0
Henderson
0
Manukau
0
Hamilton
0
Tauranga
0
New Plymouth
0
Wellington
0
Christchurch
0
Head Office (Web)
0

Features

ZONEFLEX 802.11AC DUAL-BAND CONCURRENT 2.4 GHZ & 5 GHZ ACCESS PORTS POE IN POE OUT (ONE PORT) USB PORT. DOES NOT INCLUDE DC POWER SUPPLY.

High Performance 802.11ac Wave 2 Integrated Wired/wireless Wall Switch

The ZoneFlex H510 is the industry's first Wave 2 802.11ac wired and wireless wall switch using Ruckus' patented BeamFlex+ adaptive antenna technology to deliver high-speed 802.11ac Wi-Fi in an ultra-sleek, low-profile design that can be discretely installed over a standard electrical junction box. Ideal for offering converged services in hotel guest rooms, student residences, and multi-dwelling units, the ZoneFlex H510 provides an easy way to offer multiple connections in a single room without multiple cables.

The ZoneFlex H510 supports Multi-User MIMO (MU-MIMO) as a Wave 2 solution and can increase network throughput by transmitting to two Wave 2 clients at the same instant in time. This efficient utilization of the Wi-Fi channel boosts performance for Wave 2 clients but also frees up airtime for all clients, which means even non-Wave 2 clients see a performance benefit.

The "mobile device ready" ZoneFlex H510 with BeamFlex+ adapts in real time to client device location and physical orientation, delivering consistent Wi-Fi performance. The BeamFlex+ adaptive antenna system of the ZoneFlex H510 is optimized to deliver best-in-class Wi-Fi coverage and performance in hotel guest rooms and MDU residences.

Equipped with four Ethernet ports for in-room access, the ZoneFlex H510 can be used to connect a range of wired network devices such as IPTV set top boxes, IP telephones, or networked minibars while simultaneously providing dual band 802.11ac wireless LAN coverage. An IEEE 802.3af-compliant Power-over-Ethernet (PoE) port on the H510 allows devices such as IP telephones to be powered directly from the wall switch. The H510 itself may be powered via standard PoE or a DC power adapter.

The ZoneFlex H510 offers maximum flexibility and future-proofed utility. It is designed to securely support future add-on radio modules for wireless connectivity beyond best-in-class Wi-Fi. The cable pathways at the rear, support legacy cabling such as RG6 or CAT3/CAT5. Existing services such as video and voice over Ethernet can co-exist within the same junction box, reducing both installation time and construction costs. The H510 can be deployed as a standalone device or centrally managed by SmartZone, ZoneDirector, or FlexMaster management platforms.

Specifications

Power
POE 802.3af/802.3at
48VDC input

Physical Size
90 mm x 145 mm x 29 mm

Weight
230 g
292 g with bracket

Physical Ports

4 10/100/1000 Mbps Base-T 802.3, 802.3u, RJ-45 Ethernet access ports.
1 10/100/1000 Mpbs Base-T 802.3, 802.3u, 802.3ab, 802.3af (802.3at class 4) PoE input, RJ-45
USB 2.0

Mounting Options

Electrical wallbox; Standard US and EU single gang wall jack
Optional bracket for offset & wall mount

Environmental Conditions
Operating Temperature: 32°F (0°C) - 104°F (40°C)
Operating Humidity: 15% - 95% non-condensing

Power Draw

Idle: 6.5 W
Typical: 7.3 W
Peak, no PoE out load: 9.2W
Max load on PoE out:
4W with 802.3af for PoE
12.95W with 802.3at PoE in
