Ubiquiti NanoStation Loco5AC Outdoor airMAX ac CPE - 5 Pack
Ubiquiti NanoStation Loco5AC Outdoor airMAX ac CPE - 5 Pack
- Brand: Ubiquiti
- MPN: Loco5AC-5
- Part #: NAPUBI140920
- UPC: 817882027267
- Brand: Ubiquiti
- MPN: Loco5AC-5
- Part #: NAPUBI140920
- UPC: 817882027267
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Related Promotions
Popular CPE





Ubiquiti NanoStation Loco5AC Outdoor airMAX ac CPE - 5 Pack
- Brand: Ubiquiti
- MPN: Loco5AC-5
- Part #: NAPUBI140920
- UPC:817882027267

Product URL: https://www.pbtech.co.nz/product/NAPUBI140920/Ubiquiti-NanoStation-Loco5AC-Outdoor-airMAX-ac-CPE
Branch | New Stock | On Display |
---|---|---|
Albany | 0 | |
Glenfield | 0 | |
Queen Street | 0 | |
Auckland Uni | 0 | |
Newmarket | 0 | |
Westgate | 0 | |
Penrose | 0 | |
Henderson (Express) | 0 | |
St Lukes | 0 | |
Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Head Office | 0 | |
Hornby | 0 | |
Christchurch Central | 0 |
Features
NanoStation AC 5 GHz airMAX® ac CPE
The indoor/outdoor NanoStation® AC and NanoStation AC loco are compact, high-performance CPEs featuring airMAX® AC technology and a dedicated Wi-Fi radio for management.
Sleek Industrial Design
The NanoStation AC and NanoStation AC loco represent the next evolution of the iconic CPE design that revolutionized the Wireless ISP industry.
Dual Ethernet Connectivity
The NanoStation AC provides a secondary Ethernet port with software-enabled PoE. Use this port to conveniently power an external device, such as a PoE security camera, for seamless IP video integration.
Management Wi-Fi Radio
Each NanoStation AC model integrates a separate Wi-Fi radio for fast and easy setup using your mobile device.
Improved Surge Protection
The NanoStation AC and NanoStation AC loco feature enhanced protection against ESD events.
Now with airOS®8
airOS®8 provides powerful features, including airMAX® ac protocol support, real-time RF analytics, and an all-new design for enhanced usability.
Specifications
General
Dimensions
179 x 77.5 x 59.1 mm (7.05 x 3.05 x 2.33")
Weight
180 g (6.35 oz)
Power Supply
24V, 0.3A Gigabit PoE Supply*
Max. Power Consumption
7W
Power Method
Passive PoE 2-Pair (Pairs 4, 5+; 7, 8 Return)
Gain
13 dBi
Networking Interface
10/100/1000 Mbps Ethernet Port
Channel Bandwidths
10/20/30/40/50/60/80 MHz
Processor Specs
Atheros MIPS 74Kc, 560 MHz
Memory
64 MB DDR2
Cross-pol Isolation
20 dB Minimum
Max. VSWR
1.8:1
Beamwidth
45° (H-pol) / 45° (V-pol) / 45° (Elevation)
Polarization
Dual Linear
Enclosure
Outdoor UV Stabilized Plastic
LEDs
(1) Power
Mounting
Pole-Mount (Kit Included)
Operating Temperature
-40 to 70° C (-40 to 158° F)
Operating Humidity
5 to 95% Noncondensing
RoHS Compliance
Yes
ESD/EMP Protection
±24kV Contact/Air
Shock & Vibration
ETSI300-019-1.4
Certifications
CE, FCC, IC
Operating Frequency (MHz)
Worldwide
5150 - 5875
USA
U-NII-1: 5150 - 5250
U-NII-2A: 5250 - 5350 MHz
U-NII-2C: 5470 - 5725 MHz
U-NII-3: 5725 - 5850
Management Radio (MHz)
Worldwide
2412 - 2472
USA
2412 - 2462
