Kensington SD5700T Thunderbolt 4 Dual 4K Docking Station support 90W Power Deliver, Thunderbolt4 x4, USB3.0 x3, RJ45 x1, Support Mac/Windows, 3yr warranty

Kensington SD5700T Thunderbolt 4 Dual 4K Docking Station support 90W Power Deliver, Thunderbolt4 x4, USB3.0 x3, RJ45 x1, Support Mac/Windows, 3yr warranty
PB Tech price: PB Tech price:
$434 15  +GST $499 27  inc GST

Generating Print Page

Kensington SD5700T Thunderbolt 4 Dual 4K Docking Station support 90W Power Deliver, Thunderbolt4 x4, USB3.0 x3, RJ45 x1, Support Mac/Windows, 3yr warranty

Part #: NBDKEN5700
PB Tech price: PB Tech price:
$434 15 $499 27
 +GST  inc GST


Click & Collect: Available from 16 stores.
Select your store to check availability
Delivery: Order now and it ships on 26/10/2021 When will I receive it?

Six easy payments of $85.71 per week*

Laybuy lets you spread the cost of your purchase over 6, interest-free, weekly payments.

Click the button below or select Laybuy as your payment method during the checkout process.

If you do not have a Laybuy account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.
Learn more about Laybuy

Five easy payments of $102.85 per fortnight*

humm lets you spread the cost of your purchase over 5 or 10 interest free payments.

Click the button below or select humm as your payment method during the checkout process.

If you do not have a humm account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.
Learn more about humm

Finance from $4.98 per week*

Get what you want at a price you can afford. Choose a finance term below to see the weekly repayment amount and apply online during checkout or in-store.

Choose a Finance Term

*Repayments shown above are indicitive only and may vary. Ts and Cs and lending criteria apply.
Learn more about Finance Now

24 months interest FREE available*

Q Card / Mastercard is your perfect shopping partner, combining the benefits of a credit card with the added ability to access a range of interest-free deals and payment holidays.

Learn more about Q Mastercard, apply online for one now, or email [email protected] to chat with our finance team.

*Ts and Cs and lending criteria apply.
Learn more about Q Card

  • Brand: Kensington
  • MPN: K35175AP
  • Part #: NBDKEN5700
  • UPC: 085896351757
  • 4K Support: Yes
  • Display Ports: None
  • HDMI Ports: None
  • View more

Features

SD5700T Thunderbolt™ 4 Dual 4K Docking Station with 90W PD - Win/Mac

The first of a generation, the SD5700T Thunderbolt™ 4 Dual 4K Docking Station with 90W PD - Win/Mac offers premium Thunderbolt benefits now, and well into the future; compatible with Thunderbolt™ 4-enabled Windows 10 laptops and backward compatibility with Thunderbolt™ 3 MacBooks running macOS 11 (Big Sur) or later, supports Thunderbolt™ 3, Thunderbolt™ 4, USB-C and USB4 accessories and provides full power delivery, regardless of how many devices are connected. Features include 11-ports, Single 8K @ 30 Hz, or up to Dual 4K @ 60Hz video, 40Gbps data transfer speeds, UHS-II SD 4.0 card reader speeds, and more.

- Best For: Thunderbolt™ 4 Windows 10 laptops and Thunderbolt™ 3 MacBooks running macOS 11 (Big Sur) or later. Supports Single 8K or Dual 4K video.
- Connection Technology: Thunderbolt™ 4
- Power Delivery: Supports USB-C PD 3.0 (90W of laptop charging)
- Compatibility: Windows 10 and macOS 11 (Big Sur) or later
- # of Monitors Supported: 2
- Video Ports: Thunderbolt™ 4 ports
- Plug & Play: Yes, optional Kensington DockWorks™ software is recommended for the best connection, performance, and security from your Kensington docking station.
- System Requirements: Compatible with laptops equipped with Thunderbolt 4 ports.
- Apple M1 - While this docking station will work with the M1 MacBook, only a single video output is supported. For multi-monitor support on your M1 MacBook, see our Hybrid USB-C DisplayLink docking stations (e.g.: SD4700P, SD4750P, SD4780P or SD4900P) or USB-A DisplayLink adapters (DisplayPort K33989, HDMI K33988, DVI-I K33974).

Compatibility

Universally compatible, this Thunderbolt™ 4 desktop docking station is the first of its kind, providing the ultimate plug-and-play solution for Thunderbolt™ 4 Window 10 laptops and Thunderbolt™ 3 MacBooks running macOS 11 (Big Sur) or later, while also supporting Thunderbolt™ 3, Thunderbolt™ 4, USB-C and USB4 accessories. For Thunderbolt™ 3 based Windows 10 laptops, please see our range of Thunderbolt™ 3 docks.



Thunderbolt™ 4 Technology

For the first time, this Thunderbolt™ 4 modern docking station can connect up to three additional Thunderbolt devices directly (up to five in total) while providing transfer speeds up to 40Gbps, up to Dual 4K video output, and audio; all through the included 0.8m Thunderbolt™ 4 cable, for a quick and powerful plug-and-play experience. Intel VT-d DMA protection blocks peripheral devices from unauthorized access to system memory.



Single 8K or Dual 4K Video Output for Thunderbolt™ 4-Enabled Devices

Single 8K or Dual 4K (@ 60 Hz) video output for Thunderbolt™ 4-enabled host devices lets you extend visual productivity with the crisp resolution, contrast, and color depth of Ultra HD (Single 8K 30Hz or Dual 4K 60Hz) via the available Thunderbolt™ 4 ports.



90W Power Delivery

90W power delivery allows you to quickly and easily charge any Thunderbolt™ 4 Windows 10 laptop or Thunderbolt™ 3-enabled MacBook running macOS 11 (Big Sur) or later, in addition to providing full support for your USB-C or USB4peripheral accessories. No need to worry about what you have connected to the dock - our solution provides the only full powered offering on the market, so you can connect anything, and be sure to receive optimal performance.



Helps Future-Proof Your Desktop Setup

With 11-Ports of connectivity, you'll have the power to get the job done today and well into the future. This dock offers four Thunderbolt™ 4 ports, all capable of data, video and audio; four USB-A ports (one 5V/1.5A charging port on the front and three Gen2 @ 10Gbps ports on the rear); one Gigabit Ethernet port; one audio combo jack; and one UHS-II SD 4.0 card reader.



UHS II SD 4.0 Card Reader

Transfer files at ultra fast speeds using the built-in UHS II SD 4.0 card reader.



Zero-Footprint Mounting Option and Security Cable Lock Slots

Maximize desktop space and reduce cable clutter by mounting your docking station out of the way. Mounting bracket sold separately (K34050WW). Lock slots allow you to protect your investment with a Kensington cable lock, sold separately (K65020WW or K64444WW).



Free Kensington DockWorks™ Software

DockWorks™ WiFi Auto-Switch guarantees the fastest, most reliable internet connection; while MAC Address ID Pass-Through and Reset, and Device Connection Monitoring give IT managers maximum network monitoring and visibility.

Specifications

Connection technology

Thunderbolt 4

Driverless

Yes

Number of Screen Outputs

2

Video ports

Thunderbolt 4

Maximum resolution

8K

Power delivery

90W

Operating system(s)

macOS, Windows

Number of USB ports

4

USB fast charging

Yes

Docking station family

The Innovator

DockWorks

Yes

Best For

Thunderbolt 4 Windows 10 laptops and Thunderbolt 3 MacBooks running macOS 11 (Big Sur) or later. Supports Single 8K or Dual 4K video.

Compatibility

Windows 10, macOS 11 or later

Card Reader

SD Card Slot (UHS-II, SD4.0)

USB-A ports

4 x (1) USB 2.0 (front) with 5V/1.5A fast-charging & (3) USB 3.2 Gen2 (back) supporting 5V/0.9A

Audio

1 x 3.5mm Combo Microphone & Headphone Port (front)

Data transfer speeds

Supports up to 40Gbps data transfer speed

Ethernet Speed (Mbps)

1000, 100, 10

Maximum resolution supported

Single 8K 30Hz or Dual 4K 60Hz

Plug & play

Plug & play installation without need for drivers or downloads

Security slot compatibility

Kensington Security Slot, Kensington Nano Security Slot

System requirements

Compatible with Windows 10 laptops equipped with Thunderbolt 4 and Thunderbolt 3 MacBooks running macOS 11 (Big Sur) or later.

Thunderbolt Ports

4 x Thunderbolt 4 Ports (1 x upstream and 3 x downstream)

USB-C Power Delivery

Supports USB-C PD 3.0 (90W of laptop charging)

Video output

Thunderbolt 4 ports

4K support

Yes

Manufacturer Part No:
K35175AP
Brand:
Product Type:
Thunderbolt 4
UPC
085896351757
Product Family:
-
Shipping Weight:
1.7 kg
PB Part No:
NBDKEN5700
Product Model:
SD5700T
Warranty: 12 months *
