Cambium Networks XV2-2T1 Outdoor Dual radio WiFi 6 AP Sector antenna 2x2, 2.5GbE, 48Vout,BLE. RW
Cambium Networks XV2-2T1 Outdoor Dual radio WiFi 6 AP Sector antenna 2x2, 2.5GbE, 48Vout,BLE. RW
- Brand: Cambium Networks
- MPN: XV2-2T1
- Part #: NETCBN010184
- UPC:
- Brand: Cambium Networks
- MPN: XV2-2T1
- Part #: NETCBN010184
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Outdoor Access Points
Cambium Networks XV2-2T1 Outdoor Dual radio WiFi 6 AP Sector antenna 2x2, 2.5GbE, 48Vout,BLE. RW
- Brand: Cambium Networks
- MPN: XV2-2T1
- Part #: NETCBN010184
Product URL: https://www.pbtech.co.nz/product/NETCBN010184/Cambium-Networks-XV2-2T1-Outdoor-Dual-radio-WiFi-6
| Branch | New Stock | On Display |
|---|---|---|
| Auckland - Albany | 0 | |
| Auckland - Glenfield | 0 | |
| Auckland - Queen Street | 0 | |
| Auckland - Auckland Uni | 0 | |
| Auckland - Westgate | 0 | |
| Auckland - Penrose | 0 | |
| Auckland - Henderson (Express) | 0 | |
| Auckland - St Lukes | 0 | |
| Auckland - Manukau | 0 | |
| Hamilton | 0 | |
| Tauranga | 0 | |
| New Plymouth | 0 | |
| Palmerston North | 0 | |
| Petone | 0 | |
| Wellington | 0 | |
| Auckland - Head Office | 0 | |
| Auckland - East Tamaki Warehouse | 0 | |
| Christchurch - Hornby | 0 | |
| Christchurch - Christchurch Central | 0 | |
| Dunedin | 0 |
Features
Cambium XV2-2T1 Outdoor Dual Radio 2x2 Wi-Fi 6 Access Point with 120° Integrated Sector Antenna and PoE Out port.
The XV2-2T1 is a dual radio WiFi6 access point (AP) designed for outdoor deployments in Wi-Fi hotspots, outdoor enterprise networks, hospitality, and education markets. Surge suppression up to 4kV and an LTE co-existence filter are featured.
The XV2-2T1 delivers Cambium 30VDC power out, or 48VDC for PoE devices connected to the second gigabit Ethernet port. Ideal for connecting the XV2-2T1 to a Cambium subscriber module (SM), Terragraph CN (connection node), or any IP and Ethernet device such as a security IP camera, or another Wi-Fi access point.
The new IEEE 802.11ax standard delivers higher network speeds and enables more connected devices at higher packet quality. In outdoor deployments, the IEEE 802.11ax standard delivers greater range by boosting the RF frame preamble by 3dB and improved signal quality with increased guard interval vs previous Wi-Fi technology. The XV2-2T1 is fully backward compatible with existing Wi-Fi technology and prepares a network for higher growth and greater density of Wi-Fi connected devices.
- Compatible with Cambium Networks XMS or cnMaestro management system
- Dual radios 802.11ax (WiFi 6)
- 2.5 GbE uplink port
- 1 GbE with power out
- Outdoor IP67 rated, -40ºC to 65ºC
- HE 120º Sector Antenna
- Application policy control (requires XMS Cloud or Enterprise)
- EasyPass with Microsoft Azure and Google G Suite integration (requires XMS Cloud or Enterprise)
Specifications
Radios
2.4 GHz 802.11 b/g/n/ax, 2x2; 5 GHz 802.11 a/n/ac Wave 2/ax, 2x2
Wi-Fi
802.11 a/b/g/n/ac Wave 2/ax
SSID Security
WPA3, WPA2 (CCMP, AES, 802.11i), WPA2 Enterprise (802.1x/EAP), WPA PSK (TKIP), WEP, Open
Max PHY Rate
2.4 GHz radio 573.5 Mbps; 5 GHz radio 1,201 Mbps
Ports
1 x IEEE 10/100/1000/2500 Mbps Auto sensing MDIX, 1 x IEEE 10/100/1000 Mbps Ethernet with SW configurable passive PoE output of 30V or 48V up to 30 Watts
Antenna
2.4 GHz 11 dBi, Sector; 5 GHz 13.5 dBi, Sector
Max EIRP
2.4 GHz 35 dBm; 5 GHz 36 dBm
LTE Filter
Band 38, 40
Power
20 W max, Up to 50W when powering an auxiliary device
Dimensions
582 mm x 200 mm x 80 mm
Weight
1,200 g
Outdoor Rating
IP67 Rated
Ambient Operating Temperature
-40ºC to 65ºC
Storage Temperature
-40ºC to 70ºC
Humidity
95% RH non-condensing
MTBF
25ºC = 674,966 hours, 65ºC = 197,106 hours
Mount Options
Pole or wall mounting. Pole diameter: MIN 30 mm / MAX 75 mm
