Cisco 1000BASE-SX SFP transceiver module for MMF, 850-nm wavelength extended operating temperature range and DOM support, dual LC/PC connector
Cisco 1000BASE-SX SFP transceiver module for MMF, 850-nm wavelength extended operating temperature range and DOM support, dual LC/PC connector
- Brand: Cisco
- MPN: GLC-SX-MMD=
- Part #: NETCIS1856535
- UPC: 882658340895
- Brand: Cisco
- MPN: GLC-SX-MMD=
- Part #: NETCIS1856535
- UPC: 882658340895
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Transceivers
Cisco 1000BASE-SX SFP transceiver module for MMF, 850-nm wavelength extended operating temperature range and DOM support, dual LC/PC connector
- Brand: Cisco
- MPN: GLC-SX-MMD=
- Part #: NETCIS1856535
- UPC:882658340895
Product URL: https://www.pbtech.co.nz/product/NETCIS1856535/Cisco-1000BASE-SX-SFP-transceiver-module-for-MMF-8
Branch | New Stock | On Display |
---|---|---|
Albany | 0 | |
Glenfield | 0 | |
Queen Street | 0 | |
Auckland Uni | 0 | |
Newmarket | 0 | |
Westgate | 0 | |
Penrose | 0 | |
Henderson (Express) | 0 | |
St Lukes | 0 | |
Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Head Office | 3 | |
Hornby | 0 | |
Christchurch Central | 0 |
Features
1000BASE-SX SFP for Multimode Fiber Only
The 1000BASE-SX SFP, compatible with the IEEE 802.3z 1000BASE-SX standard, operates on legacy 50 µm multimode fiber links up to 550 m and on 62.5 µm Fiber Distributed Data Interface (FDDI)-grade multimode fibers up to 220 m. It can support up to 1km over laser-optimized 50 µm multimode fiber cable.
Cisco's industry-standard SFP is a hot-swappable input/output device that plugs into a Gigabit Ethernet port/slot, linking the port with the fiber-optic network. SFPs can be used and interchanged on a wide variety of Cisco products and can be intermixed in combinations of IEEE 802.3z- compliant 1000BaseSX, 1000BaseLX/LH, or 1000BaseZX interfaces on a port-by-port basis.
The Cisco GLC-SX-MM operates on ordinary multi-mode fiber optic link spans of up to 550 m in length.
Specifications
Wavelength (nm)
850
Fiber Type
MMF
Core Size (µm)
62.5
Modal Bandwidth (MHz* Km)
160 (FDDI-grade)
Operating Distance (m)
220 (722 ft)
Transmit Power Range (dBm)
-3 to -9.5
Receive Power Range (dBm)
0 to -17
Maximum Channel insertion loss in dB (by fiber type)
2.4 (FDDI-grade)
2.6 (OM1)
3.4 (400/400)
3.6 (OM2)
5 (OM3)
Transmit and Receive Wavelength Range (nm)
770 to 860
