CTS MCT-3002BTFCSM10 Compact Gigabit Media Converter 10/100/1000Base-TX RJ45 to 1000Base-LX Single-Mode Fibre 10KM

CTS MCT-3002BTFCSM10 Compact Gigabit Media Converter 10/100/1000Base-TX RJ45 to 1000Base-LX Single...

  • Brand: CTS
  • MPN: MCT-3002BTFCSM10
  • Part #: NETCTS0039
  • UPC:
PB Tech price: PB Tech price:
$146 09 $168 00
 +GST  inc GST

Click & Collect: Select your store to check availability
Delivery: Order now and it ships on 29/01/2021 When will I receive it?
Shop in-store: Check store stock levels

Five easy payments of $34.61 per fortnight*

humm lets you spread the cost of your purchase over 5 or 10 interest free payments.

Click the button below or select humm as your payment method during the checkout process.

If you do not have a humm account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.
Learn more about humm

Six easy payments of $28.84 per week*

Laybuy lets you spread the cost of your purchase over 6, interest-free, weekly payments.

Click the button below or select Laybuy as your payment method during the checkout process.

If you do not have a Laybuy account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.
Learn more about Laybuy

Features

CTS Compact Gigabit Media Converter 10/100/1000Base-TX RJ45 to 1000Base-LX Single-Mode Fibre 10km

Features:

  • The Worldwide Effortless and Reliable Media Converter
    The almost "set-it-and-forget-it" media converter is for minimising network implementation and maintenance efforts
  • 9K Bytes Jumbo Frame Size
    Support jumbo frame size 9K bytes to ease the network traffic loading and facilitate IPTV service
  • Link Alarm
    When UTP or fibre port is down during operation, the other port will be automatically turned off to alert the user
  • Fully Compatible with MCT-RACK-18 Series
    Space-saving and budget limited solution for MCTRACK-18 series to mix installation with MCT series converter

Specifications

Interface
TP Port
10/100/1000Base-T RJ-45 x 1
F/O Port
100/1000Base-X x 1

Standards

IEEE 802.3 10Base-T
IEEE 802.3u 100Base-TX/FX
IEEE 802.3ab 1000Base-T
IEEE 802.3z 1000Base-X

H/W Specication

Store and Forward Switching
Mechanism
Auto-Crossover for MDI/MDI-X in TP
Port
Auto-Negotiation in TP Port
Full/Half Duplex Mode Operation
Mac Address Table : 2K
Memory Buer (Bytes) : 128K
Jumbo Frame (9K Bytes)
Slide-In Converter Center

LED

Power, FDX, Status, Speed, F/O, TP

Ethernet Features
Support 9K Bytes Jumbo Frame
Store and Forward Switching
Mechanism
Other Features
Rear Panel DIP Switch
Support Link Alarm
Support Slide-In Converter Center

Power Requirement

Power Adaptor
- AC Input: 100VAC~240VAC
- Frequency Range: 50~60Hz
- DC Output: 3.3V
Power Consumption: 2.3W

Environmental Condition

Operation: 0? ~ 50?
Storage Temperature: -20? ~ 60?
Humidity: 5% ~ 90%,
Non-Condensing

Dimension & Weight

Size: 51 x 74 x 20 mm (WxDxH)
Weight: 0.1Kg

EMC/Safety

FCC Class A, CE
Manufacturer Part No: MCT-3002BTFCSM10 Brand: CTS Product Type: -
UPC - Product Family: - Shipping Weight: 0.487 kg
PB Part No: NETCTS0039 Product Model: MCT-3002BTFCSM10

Warranty: 24 months local warranty *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
