Grandstream GWN7603 (AC1750) Dual-Band 4-Stream Wi-Fi 5 Access Point with 1GbE x4 (PoE+ 12W)

PB Tech price
PB Tech price
$ 99 .34
 +GST
$ 114 .24
 inc GST
$99.34  +GST
$114.24

Grandstream GWN7603 (AC1750) Dual-Band 4-Stream Wi-Fi 5 Access Point with 1GbE x4 (PoE+ 12W)

PB Tech price
$ 99 .34 $ 114 .24
 +GST  inc GST


Click & Collect: Select your store to check availability
Delivery: Order now and it ships on 14 Oct When will I receive it?
$99.34  +GST
$114.24

Ethernet Ports

4

USB Ports

None

WiFi Bands

Dual

Wireless Technology

WiFi 5 (802.11ac)

Wireless Transmission Speed

1000Mbps

Pack Size

1-Pack

Similar in-stock products available at PB Tech right now

Features

The GWN7603 is a compact Wi-Fi access point designed for small businesses, hotels, and home offices. It offers versatility through four Gigabit Ethernet ports, including one uplink port that can receive PoE/PoE+ to power the access point, and two ports with PSE capability to provide both PoE power and network connections to other devices.

This access point features dual-band 2x2:2 MU-MIMO technology and a sophisticated antenna design that supports 100+ concurrent clients and offers a 100-meter coverage range. It can be easily installed and managed using GWN.Cloud (now integrated with GDMS) and GWN Manager, Grandstream's cloud and on-premise network management platforms.

With support for advanced QoS, low-latency real-time applications, mesh networking, captive portals, 1.27Gbps wireless throughput, and four Gigabit network ports, the GWN7603 is an excellent choice for small-to-medium-sized deployments that demand both flexibility and reliable performance.

- 1.27Gbps aggregate wireless throughput, 1x Gigabit and 3x Gigabit wireline speed
- Up to 100 meters coverage range
- Self power adaptation upon auto detection of PoE/PoE+ and PSE
- Anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate/random default password per device
- Support up to 100+ Wi-Fi client devices
- Advanced QoS to ensure real-time performance of low-latency applications

Specifications

Brand

Grandstream

Manufacturer Part Number

GWN7603

Wi-Fi Standards

IEEE 802.11a/b/g/n/ac (Wave-2)

Antennas

2 dual band internal antennas.
Antenna 1 - 2.4GHz: gain 3.0dBi, 5GHz: gain 3.5dBi
Antenna 2 - 2.4GHz: gain 3.5dBi, 5GHz: gain 3.0dBi

Wi-Fi Data Rates

IEEE 802.11ac: 6.5 Mbps to 867Mbps
IEEE 802.11a: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
IEEE 802.11n: 6.5Mbps to 300Mbps; 400Mbps with 256-QAM on 2.4GHz
IEEE 802.11b: 1, 2, 5.5, 11Mbps
IEEE 802.11g: 6, 9, 12, 18, 24, 36, 48, 54 Mbps
*Actual throughput may vary depending on many factors including environmental conditions, distance
between devices, radio interference in the operating environment and mix of devices in the network

Frequency Bands

2.4 GHz Radio: 2412 - 2484 MHz
5 GHz Radio: 5150-5250 MHz, 5250-5350 MHz, 5470-5725 MHz, 5725-5850 MHz
*Not all frequency bands can be used in all regions. The band 5150-5350 MHz is restricted to indoor use only in all EU states.

Channel Bandwidth

2.4G: 20 and 40MHz
5G: 20, 40, 80MHz

System Security

WEP, WPA/WPA2-PSK, WPA/WPA2 Enterprise (TKIP/AES); WPA3, anti-hacking secure boot and critical data/control lockdown via digital signatures, unique security certificate and random default password per device

MU-MIMO

2×2:2 2.4GHz, 2×2:2 5GHz

Coverage Range

Up to 100 meters
*Coverage range can vary based on environment

Maximum TX Power

5G: 22dBm
2.4G: 24dBm
*Maximum power varies by country, frequency band, and MCS rate

Receiver Sensitivity

2.4G:
802.11b: -96dBm @ 1Mbps, -88dBm @ 11Mbps; 802.11g: -93dBm @ 6Mbps, -75dBm @ 54Mbps;
802.11n 20MHz: -73dBm @ MCS7; 802.11n 40MHz:-70dBm @ MCS7
5G:
802.11a: -92dBm @ 6Mbps, -74dBm @ 54Mbps; 802.11ac 20MHz: -67dBm @ MCS8; 802.11ac: HT40:-63dBm @ MCS9; 802.11ac 80MHz: -59dBm @ MCS9

SSIDs

16 SSIDs total, 8 per radio (2.4ghz and 5 ghz)

Concurrent Clients

100+

Network Interfaces

1 x 10/100/1000M uplink Ethernet port with POE/POE+
2 x 10/100/1000M Ethernet port with PSE
1 x 10/100/1000M Ethernet port

Auxiliary Ports

1x Reset Pinhole, 1x Kensington lock

Mounting

Indoor wall mount, kits included

LEDs

1x tri-color LEDs for device tracking and status indication

Network Protocols

IPv4/IPv6, 802.1Q, 802.1p, 802.1x, 802.11e/WMM

QoS

802.11e/WMM, VLAN, TOS

Network Management

Embedded controller can manage up to 50 local GWN APs
GWN.Cloud offers a free cloud management platform for unlimited GWN APs
GWN.Manager offers premise-based software controller for up to 3,000 GWN APs

Power and Green Energy Efficiency

PoE 802.3af/ 802.3at
PSE max output: Total 12W power budget for LAN2/LAN3
Maximum Power Consumption: 6.5W (Excluding PoE Output)

Environmental

Operation: 0°C to 45°C
Storage: -10°C to 60°C
Humidity: 10% to 90% Non-condensing

Dimensions

135 x 115 x 30mm

Weight

215g

Compliance

FCC, CE, RCM, IC

Manufacturer Part No:
GWN7603
Brand:
Product Type:
-
UPC
-
Product Family:
-
Shipping Weight:
0.36 kg
PB Part No:
NETGSM26088
Product Model:
GWN7603
Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
