LevelOne GVT-2000 10/100/1000BASE-T to 1000BASE-X to SFP Converter

PB Tech price: PB Tech price:
$99 13  +GST $114 00  inc GST
  • Overview
  • Features
  • Specifications
  • Reviews
  • Q & A

Generating Print Page

LevelOne GVT-2000 10/100/1000BASE-T to 1000BASE-X to SFP Converter

LevelOne GVT-2000 10/100/1000BASE-T to 1000BASE-X to SFP Converter

  • Brand: LevelOne
  • MPN: GVT-2000
  • Part #: NETLEL1122
  • UPC:846359031292
  • Form Factor:N/A
  • 10 Gigabit:No
  • Management Level:N/A
  • Number of Ports:0 Ports
  • PoE:No
  • PoE Ports:0 Ports
  • PoE Budget:N/A
  • Stacking:No
PB Tech price:PB Tech price:
$9913$11400
 +GST  inc GST

Store Pickup: Select your store to check availability
Delivery: Order now and it ships on 25/10/2019
When will I receive it?
Add To Compare

Four easy payments of $29.35 per fortnight*

Oxipay lets you spread the cost of your purchase over 4 fortnightly payments.

Click the button below or select Oxipay as your payment method during the checkout process.

If you do not have an Oxipay account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.
Learn more about Oxipay

Features

The GVT-2000 media converter

able to convert network signals between copper and fiber-optic based networks. The converter provides a SFP slot for 1000Base-X Gigabit optic module and a 10/100/1000Base-T RJ-45 port, supports full duplex and half duplex switch connectivity and 10Base-T, 100Base-TX and 1000Base-T auto-sensing.

The device features built-in Dip switches for easy converter configuration, which function on the Smart LFP (Link Fault Pass-through), allowing the converter to monitor both the fiber and copper ports for signal loss, as well as cut through and smart pass through mode.

The GVT-2000 is able to operate in temperatures from -10° up to 55° Celsius. The converter can be used as a standalone unit or as a slide-in module to the CHV-2000 19" converter rack, which can accommodate up to 14 units for use in a central wiring closet.

- Transfers data from 10/100/1000Base-T copper to fiber interfaces
- SFP slot supports pluggable Gigabit optic modules that enabling you to choose from a variety of transceiver
- 9K jumbo frames to increase data transfer rates
- Built-in LFP (Link Fault Pass-through) (LLCF/LLR) Technology
- IEEE 802.3x Flow Control protects against lost packets for reliable data transmission
- Dip switches for customized configuration
- Supports low-time lag transmission
- Supports the transmission of extra-long packets up to 1.6KB
- -10°C ~ 55°C operating temperature range

Specifications

General

Standards & Protocols:
IEEE 802.3 10-BASE-T, Ethernet
IEEE 802.3u 100-BASE-TX, Fast Ethernet
IEEE 802.3ab 1000BASE-T, Gigabit Ethernet
IEEE 802.3x Flow Control (full-duplex flow control)
IEEE802.3z 1000Base-SX/LX,

Connectors and Cabling:
Fiber SFP slot; RJ-45 Port CAT-5/5e Twisted Pair
cable Auto MDI/MDI-X (Max to 100m) and Auto-Negotiation

Wavelength(nm):
depend on SFP module

Indicator:
PWR,TX (FDX, 100, 1000, Link/Act), FX Link/Act

Transmission Method:
Store and forward (Default)

Power Input:
DC 5V/2A

Performance

Operating Distance:
Depend on SFP Module

Environment

Temperature (°C):
Storage: -40 ~75 °C
Operating: -10 ~ 55 °C

Humidity (Non-condensing):
5 ~ 90 %

Deployment:
Desk, chassis mounted

Physical Specifications

Dimensions (W x D x H mm):
71 x 94 x 26 mm

Weight (g):
420 g

Reliability

MTBF:
50000hrs

Approval and Compliance

EMI/EMS:
CE, RoHS, FCC

Manufacturer Part No: GVT-2000 Brand: LevelOne Product Type: -
UPC 846359031292 Product Family: - Shipping Weight: 0.3 kg
PB Part No: NETLEL1122 Product Model: -

Warranty: 24 months local warranty *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.

Reviews
