MikroTik CRS125-24G-1S-2HnD-IN Cloud Router Switch 2.4Ghz 802.11

MikroTik CRS125-24G-1S-2HnD-IN Cloud Router Switch 2.4Ghz 802.11
PB Tech price: PB Tech price:
$344 35  +GST $396 00  inc GST
  • Overview
  • Features
  • Specifications
  • Reviews

Generating Print Page

MikroTik CRS125-24G-1S-2HnD-IN Cloud Router Switch 2.4Ghz 802.11

MikroTik CRS125-24G-1S-2HnD-IN Cloud Router Switch 2.4Ghz 802.11

  • Brand: MikroTik
  • MPN: CRS125-24G-1S-2HnD-IN
  • Part #: NETMKT1103
  • UPC:
  • Form Factor:1U Rackmount
  • 10 Gigabit:No
  • 10 Gigabit Ports:0 Ports
  • Management Level:Managed L3
  • Number of Ports:24 Ports
  • PoE:Yes
  • PoE Ports:Not Specified
  • PoE Budget:N/A
  • View more
PB Tech price: PB Tech price:
$344 35 $396 00
 +GST  inc GST


Click & Collect: Select your store to check availability
Delivery: Order now and it ships on 29/06/2021 When will I receive it?

Six easy payments of $67.98 per week*

Laybuy lets you spread the cost of your purchase over 6, interest-free, weekly payments.

Click the button below or select Laybuy as your payment method during the checkout process.

If you do not have a Laybuy account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.
Learn more about Laybuy

Five easy payments of $81.58 per fortnight*

humm lets you spread the cost of your purchase over 5 or 10 interest free payments.

Click the button below or select humm as your payment method during the checkout process.

If you do not have a humm account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.
Learn more about humm

Finance from $4.10 per week*

Get what you want at a price you can afford. Choose a finance term below to see the weekly repayment amount and apply online during checkout or in-store.

Choose a Finance Term

*Repayments shown above are indicitive only and may vary. Ts and Cs and lending criteria apply.
Learn more about Finance Now

No payments or interest for 12 months available*

Q Card / Mastercard is your perfect shopping partner, combining the benefits of a credit card with the added ability to access a range of interest-free deals and payment holidays.

Learn more about Q Mastercard, apply online for one now, or email finance@pbtech.co.nz to chat with our finance team.

*Ts and Cs and lending criteria apply.
Learn more about Q Card

Features

Cloud Router Switch is our new Smart Switch series. It combines the best features of a fully functional router and a Layer 3 switch, is powered by the familiar RouterOS. All the specific Switch configuration options are available in a special Switch menu, but if you want, ports can be removed from the switch configuration, and used for routing purposes.

What's more - this device has a built in 2.4GHz wireless access point, this means you can have an AP, a router with any number of ports, and a full wire speed smart switch, all in one device - ideal for medium/small businesses and offices. It has 24 Gigabit ports, one SFP cage, a microUSB port and a built in Wireless AP.

- Perfect SOHO gateway router, switch, 11n AP all in one box
- Ethernet, Fiber, or 4G (with optional USB modem) gateway connection to Internet
- RouterOS gateway/firewall/VPN router with passive cooling
- up to twenty-five gigabit switch ports (1xSFP and 24xRJ45)
- 1000mW high power 2.4GHz 11n wireless AP

Specifications

General

Product code

CRS125-24G-1S-2HnD-IN

Architecture

MIPSBE

CPU

AR9344

CPU core count

1

CPU nominal frequency

600 MHz

Dimensions

285 x 167 x 44 mm

RouterOS license

5

Operating System

RouterOS

Size of RAM

128 MB

Storage size

128 MB

Storage type

NAND

MTBF

Approximately 200'000 hours at 25C

Tested ambient temperature

-30°C to 60°C

Powering

PoE in

Passive PoE

PoE in input Voltage

8-28 V

Number of DC inputs

2 (DC jack, PoE-IN)

DC jack input Voltage

8-28 V

Max power consumption

19 W

FAN count

Passive

Wireless specifications

Wireless 2.4 GHz Max data rate

300 Mbit/s

Wireless 2.4 GHz number of chains

2

Wireless 2.4 GHz standards

802.11b/g/n

Antenna gain dBi for 2.4 GHz

4

Wireless 2.4 GHz chip model

AR9344

Wireless 2.4 GHz generation

Wi-Fi 4

Ethernet

10/100/1000 Ethernet ports

24

Fiber

SFP DDMI

Yes

SFP ports

1

Peripherals

Serial port

RJ45

Number of USB ports

1

USB Power Reset

Yes

USB slot type

microUSB type AB

Max USB current (A)

1

Other

PCB temperature monitor

Yes

Voltage Monitor

Yes

Certification & Approvals

Certification

CE, FCC, EAC, ROHS

IP

IP20

Manufacturer Part No: CRS125-24G-1S-2HnD-IN Brand: MikroTik Product Type: -
UPC - Product Family: - Shipping Weight: 1.35 kg
PB Part No: NETMKT1103 Product Model: -

Warranty: 12 months local warranty *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.

Reviews

There are currently no reviews for this product
