Robustel R5020L-A-5G-A25GL Dual-Band WiFi High Speed Smart 5G Router
2x Ethernet - 1x RS232 / RS485
Robustel R5020L-A-5G-A25GL Dual-Band WiFi High Speed Smart 5G Router
2x Ethernet - 1x RS232 / RS485
- Brand: Robustel
- MPN: R5020L-A-5G-A25GL
- Part #: NETRTL1024
- UPC:
- Brand: Robustel
- MPN: R5020L-A-5G-A25GL
- Part #: NETRTL1024
- UPC:
What PB Tech customers are saying about this product...
See More Reviews
"Great product worked with 2 degrees SIM card straight off the bat and the features are great. download speeds were also great over 5g.
However, RCMS is fantastic but did allow m ...view more"
Features
The R5020 Lite is Robustel's new 5G capable router supporting global 5G, 4G and 3G bands. The R5020 Lite leverages the tried and tested high performance CPU platform and RobustOS 5 - an Operating System developed in-house by Robustel that has passed extensive 3rd party penetration testing.
- Low cost industrial 5G Router
- Global 5G/4G/3G cellular connections
- Cutting-edge 5G 3GPP Release 16 cellular interface
- Supports Ethernet, Wi-Fi and 5G/4G internet with auto-failover
- 1 x RS232/RS485 (software configurable) ports for connection to industrial/legacy devices
- Fully programmable Operating System with well documented SDK
- Multiple VPN options are available, including DMVPN, IPsec, L2TP + more…
- Free cloud management platform - RCMS
- Robust metal enclosure with small footprint - DIN-rail + wall mount options
R5020 Lite is compatible with 3GPP Release 16 and targeted at the following applications:
Broadband Failover
R5020 Lite can be configured to use Ethernet or Wi-Fi as primary internet and failover to 5G/4G in the event of an outage. This can help provide resilience to shops and small offices at a reasonable cost and provide sufficient bandwidth for many users. IPsec, DMVPN, GRE+ many more protocols can be used for connections into core networks.
Primary Broadband
Cellular network operators can now provide unlimited 5G tariffs at very reasonable prices. For many, a chance to cut the cables and use a wireless internet connection can be technically or commercially favorable.
SD-WAN
Whilst many appliances have cellular options built-in, the R5020 Lite can offer a very low-cost way to add a 5G backup route & by virtue of being able to located externally to the appliance, is more likely to get a good 5G signal!
Application Example
R5020-Lite Use Cases
In-Vehicle Connectivity
Provide secure 5G backhaul for emergency services and fleets with in-vehicle computers, cameras, and location reporting via GNSS; manage updates and diagnostics centrally with RCMS.
SD-WAN 5G Backup
Add a cost-effective 5G backup path to SD-WAN appliances; external mounting improves signal; central monitoring and updates reduce the risk and cost of truck rolls.
High-Speed Industrial IoT
Add high-bandwidth 5G backhaul for robotics, video, telemetry, and data-heavy workflows at plants and yards. Reduce rollout time versus fibre; manage security and updates at scale.
Specifications
Reviews
Delivery & Pick-up
Delivery Estimates
The estimated time to ship for each product we sell is detailed on the individual product page just underneath the price. From when your items ship, products typically arrive within 1-2 working days for North Island deliveries and 2-3 working days for South Island deliveries. Rural deliveries may take an extra working day. Bulk & hazard deliveries may take an extra 2-7 working days and tracking links for these deliveries can take a few days to generate.
Next Day Delivery
Need your order in a hurry? PB Tech offers next day delivery for local Auckland addresses. Simple place your order before 4pm (provided your items are in stock) and select our next day delivery option in the checkout. T&C's apply. Learn more about Next Day Delivery.
Same Day Delivery
Need your order in a hurry? PB Tech offers same day delivery for Auckland, Hamilton, Wellington and Christchurch. Simple place your order before 1pm (provided your items are in stock) and select one of our same day delivery options 'Evening Delivery' or 'Urgent 3-hour Delivery' in the checkout. T&C's apply. Learn more about Same Day Delivery.
Shipping Costs
Shipping costs vary based on your location and the items being shipped and in some cases shipping may even be FREE.
To calculate what the shipping costs will be for your order, add the items you are interested in to your cart, view the Shopping Cart page, and select your 'Delivery Area' to calculate the shipping cost.
Shipping Security & Insurance
All orders shipped by PB Tech are sent via a courier with a signature required for each delivery. In some cases, and only where you have given the courier company permission to leave orders at a designated location, your order may be delivered without requiring a signature. All orders sent by PB Tech are fully insured in the unlikely event that your item(s) are damaged or go missing in transit.
1 Hour Store Pick-up / Click & Collect
You can pick-up your online order from any of our stores nationwide. You can select which store you want to pick up from at the checkout. Provided the store you select has stock and there's no hold-ups with payment we will have your order ready within 1 hour (during normal trading hours for that store) otherwise it may take up to 5 working days to transfer the stock to the store so your order can be fulfilled. Learn more about our Click & Collect process.
Overseas Shipments
PB Tech regularly ships overseas to Australia and beyond. If you are located in Australia, you can order directly from our Australian site www.pbtech.com/au. If you are from another country you can order from www.pbtech.com
Returns & Warranty
Related Promotions
Popular 4G / 5G Routers
TP-Link Archer MR6400 4G LTE CAT4 N300 WiFi 4 Router 1GbE x4 /...
TP-Link M7350 4G LTE CAT4 N300 WiFi 4 Mobile WiFi Hotspot 2100mAh...
TP-Link M7450 4G LTE CAT6 AC1200 WiFi 5 Mobile WiFi Hotspot...
Ubiquiti UniFi (UMR-Ultra) 4G LTE CAT4 N300 WiFi 4 Router 100M FE...
TP-Link M7750 4G LTE CAT12 AC1200 WiFi 5 Mobile WiFi Hotspot...
Robustel R5020L-A-5G-A25GL Dual-Band WiFi High Speed Smart 5G Router 2x Ethernet - 1x RS232 / RS485
- Brand: Robustel
- MPN: R5020L-A-5G-A25GL
- Part #: NETRTL1024
Product URL: https://www.pbtech.co.nz/product/NETRTL1024/Robustel-R5020L-A-5G-A25GL-Dual-Band-WiFi-High-Spe
| Branch | New Stock | On Display |
|---|---|---|
| Auckland - Albany | 0 | |
| Auckland - Glenfield | 0 | |
| Auckland - Queen Street | 0 | |
| Auckland - Auckland Uni | 0 | |
| Auckland - Westgate | 0 | |
| Auckland - Penrose | 0 | |
| Auckland - Henderson (Express) | 0 | |
| Auckland - St Lukes | 0 | |
| Auckland - Manukau | 0 | |
| Hamilton | 0 | |
| Tauranga | 0 | |
| New Plymouth | 0 | |
| Palmerston North | 0 | |
| Petone | 0 | |
| Wellington | 0 | |
| Nelson | 0 | |
| Auckland - Head Office | 0 | |
| Auckland - East Tamaki Warehouse | 0 | |
| Christchurch - Hornby | 0 | |
| Christchurch - Christchurch Central | 0 | |
| Dunedin | 0 |
Features
The R5020 Lite is Robustel's new 5G capable router supporting global 5G, 4G and 3G bands. The R5020 Lite leverages the tried and tested high performance CPU platform and RobustOS 5 - an Operating System developed in-house by Robustel that has passed extensive 3rd party penetration testing.
- Low cost industrial 5G Router
- Global 5G/4G/3G cellular connections
- Cutting-edge 5G 3GPP Release 16 cellular interface
- Supports Ethernet, Wi-Fi and 5G/4G internet with auto-failover
- 1 x RS232/RS485 (software configurable) ports for connection to industrial/legacy devices
- Fully programmable Operating System with well documented SDK
- Multiple VPN options are available, including DMVPN, IPsec, L2TP + more…
- Free cloud management platform - RCMS
- Robust metal enclosure with small footprint - DIN-rail + wall mount options
R5020 Lite is compatible with 3GPP Release 16 and targeted at the following applications:
Broadband Failover
R5020 Lite can be configured to use Ethernet or Wi-Fi as primary internet and failover to 5G/4G in the event of an outage. This can help provide resilience to shops and small offices at a reasonable cost and provide sufficient bandwidth for many users. IPsec, DMVPN, GRE+ many more protocols can be used for connections into core networks.
Primary Broadband
Cellular network operators can now provide unlimited 5G tariffs at very reasonable prices. For many, a chance to cut the cables and use a wireless internet connection can be technically or commercially favorable.
SD-WAN
Whilst many appliances have cellular options built-in, the R5020 Lite can offer a very low-cost way to add a 5G backup route & by virtue of being able to located externally to the appliance, is more likely to get a good 5G signal!
Application Example
R5020-Lite Use Cases
In-Vehicle Connectivity
Provide secure 5G backhaul for emergency services and fleets with in-vehicle computers, cameras, and location reporting via GNSS; manage updates and diagnostics centrally with RCMS.
SD-WAN 5G Backup
Add a cost-effective 5G backup path to SD-WAN appliances; external mounting improves signal; central monitoring and updates reduce the risk and cost of truck rolls.
High-Speed Industrial IoT
Add high-bandwidth 5G backhaul for robotics, video, telemetry, and data-heavy workflows at plants and yards. Reduce rollout time versus fibre; manage security and updates at scale.
Specifications
Cellular Interface
Number of antennas
4 (ANT0 + ANT1 + ANT2 + ANT3)
Connector
SMA-K
SIM
2 x Mini SIM (2FF)
Ethernet Interface
Number of ports
2 x 10/100/1000 Mbps,
2 LAN by default, can be configured as
1 WAN + 1 LAN
Isolation protection
1 KV
WiFi Interface
Number of antennas
2 (WiFi1 + WiFi2)
Connector
RP-SMA-K
Standards
802.11b/g/n/ac 2*2 MIMO, supports AP and Client modes
Frequency bands
2.412 - 2.472 GHz (2.4 GHz ISM band)
5.15 - 5.825 GHz (5 GHz ISM band)
Security
WPA, WPA2, WEP, WPA3*
Encryption
AES, TKIP, WEP64
Data speed
5G: Up to 867Mbps
2.4G: Up to 300Mbps
Serial Interface
Number of ports
1 x RS232 or 1 x RS485 (Software configurable)
Connector
1 x 3-pin 3.5 mm female socket
ESD protection
±8 KV air discharge, ±6 KV contact discharge
Baud rate
300 bps ~ 115200 bps
Signal definition
RS232: TXD, RXD, GND
RS485: Data+ (A), Data- (B), Ground (GND)
Others
Reset button
1 x RST
LED indicators
1 x RUN, 1 x Modem, 1 x USR, 1 x RSSI, 1 x Wi-Fi 2.4G，1 x Wi-Fi 5G
Built-in
Watchdog
Software (Basic features of RobustOS)
Network protocols
PPP, PPPoE, TCP, UDP, DHCP, ICMP, NAT, HTTP, HTTPs, DNS, ARP, NTP, SMTP, Telnet, VLAN,SSH2, DDNS, etc.
VPN tunnel
IPsec, OpenVPN, GRE
Firewall
DMZ, anti-DoS, Filtering (IP/Domain name/MAC address), Port Mapping, Access Control
Management
Web, CLI, SMS
Serial port
Transparent, TCP Client/Server, UDP, Modbus RTU to TCP
Others
Data Guard, etc.
SDK
Supported programming languages
C, C++
Flash available for SDK
5MB
RAM available for SDK
128MB
Power Supply and Consumption
Connector
2-pin 3.5 mm female socket with lock
Input voltage
12 ~ 36 VDC
Power consumption
Idle: 370 mA@12 V
Data link: 1.7 A (peak) @12 V
Physical Characteristics
Ingress protection
IP30
Housing & Weight
Aluminium, 475 g
Dimension
136 x 115 x 32 mm
Installations
DIN rail mounting, desktop or wall mounting
Operating Temperature
-20 ~ +55°C (Normal temperature)
-25 ~ +70°C (Extended temperature)
Storage Temperature
-40 to +85 °C
Relative Humidity
5 to 95% RH
Regulatory and Type Approvals
Environmental
RoHS2.0
