StarTech.com PEX4S953LP 4-port PCI Express RS232 Serial Adapter Card - PCIe RS232 Serial Host Controller Card - PCIe to Serial DB9 - 16950 UART - Low Profile Expansion Card - Windows, macOS, Linux
StarTech.com PEX4S953LP 4-port PCI Express RS232 Serial Adapter Card - PCIe RS232 Serial Host Controller Card - PCIe to Serial DB9 - 16950 UART - Low Profile Expansion Card - Windows, macOS, Linux
- Brand: StarTech.com
- MPN: PEX4S953LP
- Part #: NETSTT4828627
- UPC:
- Brand: StarTech.com
- MPN: PEX4S953LP
- Part #: NETSTT4828627
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Related Promotions
Popular Serial Cards
StarTech.com PEX4S953LP 4-port PCI Express RS232 Serial Adapter Card - PCIe RS232 Serial Host Controller Card - PCIe to Serial DB9 - 16950 UART - Low Profile Expansion Card - Windows, macOS, Linux
- Brand: StarTech.com
- MPN: PEX4S953LP
- Part #: NETSTT4828627
Product URL: https://www.pbtech.co.nz/product/NETSTT4828627/StarTechcom-PEX4S953LP-4-port-PCI-Express-RS232-Se
| Branch | New Stock | On Display |
|---|---|---|
| Auckland - Albany | 0 | |
| Auckland - Glenfield | 0 | |
| Auckland - Queen Street | 0 | |
| Auckland - Auckland Uni | 0 | |
| Auckland - Westgate | 0 | |
| Auckland - Penrose | 0 | |
| Auckland - Henderson (Express) | 0 | |
| Auckland - St Lukes | 0 | |
| Auckland - Manukau | 0 | |
| Hamilton | 0 | |
| Tauranga | 0 | |
| New Plymouth | 0 | |
| Palmerston North | 0 | |
| Petone | 0 | |
| Wellington | 0 | |
| Auckland - Head Office | 0 | |
| Auckland - East Tamaki Warehouse | 0 | |
| Christchurch - Hornby | 0 | |
| Christchurch - Christchurch Central | 0 | |
| Dunedin | 0 |
Features
This PCI Express RS232 serial adapter card lets you add four RS232 (DB9) serial ports to your computer through a PCI Express (PCIe) slot. The 4 port PCIe serial card enables you to interact with serial devices, such as card readers, printers, PIN pads, and modems, at speeds of up to 921.6 Kbps.
Maximum Compatibility
With broad OS support, including for Windows and Linux, this PCI E serial card is easy to integrate into mixed environments. The card comes pre-configured with low-profile brackets and includes optional full-profile brackets, so installation is easy regardless of the case form factor. This card is a direct replacement for PEX4S952LP.
Experience Optimal Technology
This PCIe to serial adapter supports the following features:
Compatible with industry-standard 16950 UART
Supports max baud rate of up-to 921.6 Kbps
Provides 5/12V power output on Pin 9 when external power is connected
256-byte depth FIFO cache per transmitter and receiver
Supports 9, 8, 7, 6, 5 data bits (one per port)
Asix AX99100 chipset
PCI Express 1.1 compliant
Specifications
Details
Model
Serial Adapter Card
Type
PCI Express to Serial Port Card
External Ports
4 - DB-9 (9 pin, D-Sub) Male
Internal Ports
1 - LP4 (4 pin; Large Drive Power) Male Input
Operating Systems Supported
Windows 7, 8, 8.1, 10
Windows Server 2003, 2008 R2, 2012, 2012 R2, 2016
Linux 2.4.x to 2.6.x LTS Versions only
Specifications
HARDWARE
Bus Type: PCI Express
Card Type: Standard Profile (LP bracket incl.)
Chipset ID: Asix AX99100
Interface: Serial
Port Style: Integrated on Card
Ports: 4
PERFORMANCE
Data Bits: 5, 6, 7, 8, 9
FIFO: 256 Bytes
Flow Control: None, Xon/Xoff, RTS/CTS
Max Baud Rate: 921.6 Kbps
Parity: None, Odd, Even, Space, Mark
Serial Protocol: RS-232
Stop Bits: 1, 1.5, 2
Features
Features
PCI Express 1.1 compliant replacement to the PEX4S952LP Serial Card, ensuring wide compatibility
Add RS232 DB9 capabilities without purchasing a new server or computer
Low profile bracket comes pre-installed, a full profile is also included for case compatibility
Supports 256-byte depth FIFO cache per transmitter and receiver
High-speed data transfer rates of up to 921.6Kbps with the ASIX AX99100 Chipset
Dimensions
Dimensions 3" x 2.5" x 0.7"
Weight
0.58 lb.
Packaging
Package Contents
1 - 4-Port Low Profile Serial Card
1 - 4-Port DB9 Break-out Cable
1 - Full Profile Bracket
1 - Quick-Start Guide
