TP-Link Omada ES205G 5-Port Gigabit Easy Managed Switch - 1GbE x5
TP-Link Omada ES205G 5-Port Gigabit Easy Managed Switch - 1GbE x5
- Brand: TP-Link
- MPN: ES205G
- Part #: NETTPL2058
- UPC:
- Brand: TP-Link
- MPN: ES205G
- Part #: NETTPL2058
- UPC:
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Switches





TP-Link Omada ES205G 5-Port Gigabit Easy Managed Switch - 1GbE x5
- Brand: TP-Link
- MPN: ES205G
- Part #: NETTPL2058

Product URL: https://www.pbtech.co.nz/product/NETTPL2058/TP-Link-Omada-ES205G-5-Port-Gigabit-Easy-Managed-S
Branch | New Stock | On Display |
---|---|---|
Auckland - Albany | 0 | |
Auckland - Glenfield | 0 | |
Auckland - Queen Street | 0 | |
Auckland - Auckland Uni | 0 | |
Auckland - Newmarket | 0 | |
Auckland - Westgate | 0 | |
Auckland - Penrose | 0 | |
Auckland - Henderson (Express) | 0 | |
Auckland - St Lukes | 0 | |
Auckland - Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Auckland - Head Office | 1 | |
Auckland - East Tamaki Warehouse | 0 | |
Christchurch - Hornby | 0 | |
Christchurch - Christchurch Central | 0 | |
Dunedin | 0 |
Features
Omada 5-Port Gigabit Easy Managed Switch
- 5× 10/100/1000Mbps RJ45 ports
- -Easy to Use: Supports plug-and-play for instant connectivity and simple configuration for additional features
- Centralised Cloud Management via the web or the Omada app†
- Automatic Loop Prevention, VLAN, and IGMP Snooping
- Fanless design for silent operation
- Durable metal casing and desktop/wall mounting design
Software Defined Networking (SDN) with Cloud Access
Remotely manage your access points, switches, and gateways across multiple sites all from a single interface.
Compact and Durable Metal Casing, Featuring Desktop/Wall Mounting and a Fanless Design
Specifications
HARDWARE FEATURES
Interface
- 5× 10/100/1000 Mbps RJ45 Ports
- AUTO Negotiation/AUTO MDI/MDIX
Fan Quantity
Fanless
Installation
- Desktop
- Wall Mount
Physical Security Lock
Yes
Power Supply
External DC Power Adapter (Output: 5 VDC/ 0.6 A)
Dimensions ( W x D x H )
3.9 × 3.9 × 1.0 in (100 × 98 × 25 mm)
PERFORMANCE
Switching Capacity
10 Gbps
Packet Forwarding Rate
7.4 Mpps
MAC Address Table
8 K
Packet Buffer Memory
4 Mbits
Jumbo Frame
15 KB
SOFTWARE FEATURES
Quality of Service
- Port-based/802.1p/DSCP QoS
- 8 Priority Queues
- Priority Schedule Mode
- WRR (Weighted Round Robin)
- Queue Weight Config
- Bandwidth Control
- Port-Based Rating Limit
- Storm Control
- Multiple Control Modes (kbps/pps)
- Broadcast/Multicast/Unknown-Unicast Control?
L2 Features
- Static Link Aggregation
- Loop Prevention / Loopback Detection
- Flow Control
- 802.3x Flow Control
- Mirroring
- Port Mirroring
- One-to-One
- Many-to-One
- Ingress/Egress/Both
- Port Statistics
- Port Mirror Status
- Traffic Statistics
- 802.1ab LLDP
L2 Multicast
- IGMP Snooping
- IGMP v1/v2/v3 Snooping
- Fast Leave
VLAN
- MTU VLAN
- Port-Based VLAN
- 802.1Q Tag VLAN
- Max 32 VLAN Groups
- 4K VID
Transmission Method
Store-And-Forward
MANAGEMENT
Omada App
Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Centralized Management
- Omada Cloud-Based Controller
- Omada Hardware Controller
- Omada Software Controller
Cloud Access
Yes. Requires the use of Omada Hardware Controller, Omada Cloud-Based Controller, or Omada Software Controller.
Zero-Touch Provisioning
Yes. Requires the use of Omada Cloud-Based Controller
Management Features
- Web-based GUI
- DHCP Client
- Cable Diagnostics
- Automatic Device Discovery†
- Batch Configuration†
- Batch Firmware Upgrading†
- Unified Configuration†
OTHERS
Certification
FCC, CE, RoHS
Package Contents
- ES205G
- Power Adapter
- Installation Guide
- Rubber Feet
Environment
- Operating Temperature: 0?~40? (32?~104?)
- Storage Temperature: -40?~70? (-40?~158?)
- Operating Humidity: 10%~90% non-condensing
- Storage Humidity: 5%~90% non-condensing
