Ubiquiti NanoBeam NBE-5AC-Gen2 High-Performance airMAX ac Bridge, 5GHz,450+ Mbps, 15+ km, 2 x Gigabit Ethernet Ports PtP/PtMP Bridge/ Client Mode

Ubiquiti NanoBeam NBE-5AC-Gen2 High-Performance airMAX ac Bridge, 5GHz,450+ Mbps, 15+ km, 2 x Gigabit Ethernet Ports PtP/PtMP Bridge/ Client Mode
Normally: $161.23 Normally: $185.41
$155 57  +GST $178 91  inc GST
  • Overview
  • Features
  • Specifications
  • Reviews
  • Q & A
  • Accessories

Generating Print Page

Ubiquiti NanoBeam NBE-5AC-Gen2 High-Performance airMAX ac Bridge, 5GHz,450+ Mbps, 15+ km, 2 x Gigabit Ethernet Ports PtP/PtMP Bridge/ Client Mode

Dedicated Management Wi-Fi Radio
ON SPECIAL
FREIGHT FREE

Ubiquiti NanoBeam NBE-5AC-Gen2 High-Performance airMAX ac Bridge, 5GHz,450+ Mbps, 15+ km, 2 x...

  • Brand: Ubiquiti
  • MPN: NBE-5AC-GEN2
  • Part #: NETUBI0505
  • UPC:817882023375
  • USB Ports:None
  • Wireless Technology:Not Specified
  • Wireless Transmission Speed:450Mbps
  • Ethernet Ports:1
  • Wi-Fi Bands:Single
Normally: $161.23 Normally: $185.41
$155 57 $178 91
 +GST  inc GST
Ends in --, while stocks last!

Click & Collect: Select your store to check availability
Delivery: Order now and it ships tomorrow When will I receive it?
Shop in-store: Check store stock levels

Five easy payments of $36.85 per fortnight*

humm lets you spread the cost of your purchase over 5 or 10 interest free payments.

Click the button below or select humm as your payment method during the checkout process.

If you do not have a humm account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.
Learn more about humm

Six easy payments of $30.71 per week*

Laybuy lets you spread the cost of your purchase over 6, interest-free, weekly payments.

Click the button below or select Laybuy as your payment method during the checkout process.

If you do not have a Laybuy account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.
Learn more about Laybuy

COMBO DEALS: Buy Together and SAVE!

Save even more by creating your own combo deal with any of the items below and the Ubiquiti NanoBeam NBE-5AC-Gen2 High-Performance airMAX ac Bridge, 5GHz...
Ubiquiti NanoBeam NBE-5AC-Gen2 High-Performance airMAX ac Bridge, 5GHz,450+ Mbps, 15+ km, 2 x Gigabit Ethernet Ports PtP/PtMP Bridge/ Client ModeDynamix PL-C6A-30 30m Cat6 Beige UTP Patch    Lead (T568A Specification) 250MHz Slimline Snaggles MouldingNETGEAR ProSAFE GS108 8-port Gigabit Switch 8x GbEUbiquiti UB-AM Universal Wall/Pole Mounting Kit
Total:
$27128
 +GST
$31197
 inc GST
Buy together and save $5.84$6.72
This item: Ubiquiti NanoBeam NBE-5AC-Gen2 High-Performance airMAX ac Bridge, 5GHz,450+ Mbps, 15+ km, 2 x...
$155.57 +GST$178.91 inc GST
Dynamix PL-C6A-30 30m Cat6 Beige UTP Patch    Lead (T568A Specification) 250MHz Slimline Snaggles Moulding  View Product
$32.00$36.80 $30.20 +GST$34.73 inc GST(Buy together and save $1.80$2.07)
NETGEAR ProSAFE GS108 8-port Gigabit Switch 8x GbE  View Product
$64.34$73.99 $60.67 +GST$69.77 inc GST(Buy together and save $3.67$4.22)
Ubiquiti UB-AM Universal Wall/Pole Mounting Kit  View Product
$25.21$28.99 $24.84 +GST$28.57 inc GST(Buy together and save $0.37$0.43)

Features

High-Performance airMAX® ac Bridge

Incorporating innovative industrial design with proprietary airMAX® ac technology, the NanoBeam® AC is ideal for CPE deployments requiring maximum performance from the smallest possible footprint.




Management Wi-Fi Radio

The NanoBeam® AC integrates a separate Wi-Fi radio for fast and easy setup using your mobile device.



Improved Surge Protection

The NanoBeam® AC features enhanced protection against ESD events.



Superior Processing

Ubiquiti's airMAX® engine with custom IC dramatically improves TDMA latency and network scalability. The custom silicon provides hardware acceleration capabilities to the airMAX scheduler, to support the high data rates and dense modulation used in airMAX ac technology.




Incredible Antenna "Beam" Performance

The form factor of the NanoBeam® AC features the highest gain for its size. The NanoBeam AC's excellent beam directivity provides the best performance in high-noise environments.




Advanced Software Technology

Ubiquiti's airMAX® technology is proven in millions of deployments worldwide, exhibiting outstanding performance in outdoor environments. The TDMA airMAX protocol enables unprecedented scalability, high throughput and low latency in unlicensed, multipoint networks.




Now with airOS®8


airOS®8 provides powerful features, including airMAX® ac protocol support, real-time RF analytics, and an all-new design for enhanced usability.


Specifications

Dimensions (Mount Included)
189 x 189 x 125 mm (7.44 x 7.44 x 4.92")

Weight (Mount Included)
0.530 kg (1.17 lb)

Power Supply
24V, 0.5A Gigabit PoE Adapter (Included)

Max. Power Consumption
8.5W

Gain
19 dBi

Networking Interface
2x 10/100/1000 Ethernet Port (1x Passthrough)
Wi-Fi for Management

Processor Specs
Atheros MIPS 74Kc, 720 MHz

Memory
128 MB DDR2, 8 MB Flash

LEDs
Power, Ethernet, (4) Signal Strength

Signal Strength
LEDs Software-Adjustable to Correspond to Custom RSSI Levels

Max. VSWR
1.5:1

Channel Sizes

PtP Mode
10/20/30/40/50/60/80 MHz
PtMP Mode
10/20/30/40 MHz

Polarization
Dual Linear

Enclosure
Outdoor UV Stabilized Plastic

Mounting
Pole-Mount (Kit Included), Wall-Mount

Wind Loading
45.4 N @ 200 km/h (10.2 lbf @ 125 mph)

Wind Survivability
200 km/h (125 mph)

ESD/EMP Protection
Air: ± 24 kV, Contact: ± 24 kV

Operating Temperature
-40 to 80° C (-40 to 176° F)

Operating Humidity
5 to 95% Noncondensing

Certifications
CE, FCC, IC

RoHS Compliance
Yes

Salt Fog Test
IEC 68-2-11 (ASTM B117), Equivalent: MIL-STD-810 G Method 509.5

Vibration Test
IEC 68-2-6

Temperature Shock Test
IEC 68-2-14

UV Test
IEC 68-2-5 at 40° C (104° F), Equivalent: ETS 300 019-1-4

Wind-Driven Rain Test
ETS 300 019-1-4, Equivalent: MIL-STD-810 G Method 506.5
Manufacturer Part No: NBE-5AC-GEN2 Brand: Ubiquiti Product Type: -
UPC 817882023375 Product Family: NanoBeam Shipping Weight: 1.138 kg
PB Part No: NETUBI0505 Product Model: NBE-5AC-Gen2

Warranty: 12 months local warranty *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
