Ubiquiti EdgeSwitch ES-48-500W 48-Port Gigabit Managed PoE+ Switch with 48 x PoE/PoE+ (Max 500W) and 2 x SFP, 2 x SFP+, Passive 24V & 802.3af/at,

Ubiquiti EdgeSwitch ES-48-500W 48-Port Gigabit Managed PoE+ Switch with 48 x PoE/PoE+ (Max 500W) and 2 x SFP, 2 x SFP+, Passive 24V & 802.3af/at,
PB Tech price: PB Tech price:
$1,206 90  +GST $1,387 94  inc GST

Generating Print Page
Home Networking Switches Ubiquiti EdgeSwitch ES-48-500W 48...

Ubiquiti EdgeSwitch ES-48-500W 48-Port Gigabit Managed PoE+ Switch with 48 x PoE/PoE+ (Max 500W) and 2 x SFP, 2 x SFP+, Passive 24V & 802.3af/at,

Rackmountable
Part #: NETUBI1092
FREE SHIPPING
PB Tech price: PB Tech price:
$1,206 90 $1,387 94
 +GST  inc GST
Hurry, only 5 units left!


Click & Collect: Available from 1 store.
Select your store to check availability
Delivery: Order now and it ships tomorrow When will I receive it?

Six easy payments of $238.26 per week*

Laybuy lets you spread the cost of your purchase over 6, interest-free, weekly payments.

Click the button below or select Laybuy as your payment method during the checkout process.

If you do not have a Laybuy account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.
Learn more about Laybuy

Pay only $305.91 and then 25 easy payments of $48.25 per fortnight*

humm lets you spread the cost of your purchase over 26 interest free payments.

Click the button below or select humm as your payment method during the checkout process.

If you do not have a humm account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.
Learn more about humm

Finance from $12.59 per week*

Get what you want at a price you can afford. Choose a finance term below to see the weekly repayment amount and apply online during checkout or in-store.

Choose a Finance Term

*Repayments shown above are indicitive only and may vary. Ts and Cs and lending criteria apply.
Learn more about Finance Now

24 months interest FREE available*

Q Card / Mastercard is your perfect shopping partner, combining the benefits of a credit card with the added ability to access a range of interest-free deals and payment holidays.

Learn more about Q Mastercard, apply online for one now, or email [email protected] to chat with our finance team.

*Ts and Cs and lending criteria apply.
Learn more about Q Card

  • Brand: Ubiquiti
  • MPN: ES-48-500W
  • Part #: NETUBI1092
  • UPC: 810354020674
  • Form Factor: 1U Rackmount
  • 10 Gigabit: No
  • 10 Gigabit Ports: 2 Ports
  • Management Level: Managed L3
  • Number of Ports: 48 Ports
  • PoE: Yes
  • PoE Ports: 48 Ports
  • PoE Budget: 500 Watts
  • View more

COMBO DEALS: Buy Together and SAVE!

Save even more by creating your own combo deal with any of the items below and the Ubiquiti EdgeSwitch ES-48-500W 48-Port Gigabit Managed PoE+ Switch...
Total:
$1,467 19
 inc GST
Buy together and save $2.04

This item: Ubiquiti EdgeSwitch ES-48-500W 48-Port Gigabit Managed PoE+ Switch with 48 x PoE/PoE+ (Max 500W) and...

$1,387.94 inc GST
Ubiquiti UF-MM-10G Fiber Module 10Gbps SFP+, Multi-Mode, LC, 850nm, 300m, 2-Pack

Ubiquiti UF-MM-10G Fiber Module 10Gbps SFP+, Multi-Mode, LC,...

View Product
$70.69 $81.29   $68.92 +GST $79.26 inc GST (Buy together and save $1.77) $2.04)

Features

Ubiquiti EdgeSwitch ES-48-500W

The enterprise class EdgeSwitch ES-48-500W 48 Port PoE Gigabit Ethernet Switch from Ubiquiti Technology is designed to be the backbone of your network. This high capacity Gigabit switch comes equipped with forty eight 10/100/1000 Mb/s Ethernet ports, two 1/10 Gb/s SFP+ Ethernet ports, and two 1 Gb/s SFP Ethernet ports. Each port includes dedicated LED indicators representing both PoE status and the speed, link, and activity of each port. This Layer 2 switch features a total non-blocking throughput of 70 Gb/s, a switching capacity of 140 Gb/s, and a forwarding rate of 104.16 Mp/s allowing for a fast uninterrupted flow of data through the switch out to end users.
Along with enhanced networking capabilities, the EdgeSwitch ES-48-500W features optical fiber backhaul made available through the two SFP+ ports. These ports support uplinks of up to 10 Gb/s to ensure a smooth, consistent flow of data. You can also power your PoE compatible devices directly from the EdgeSwitch with support for auto-sensing IEEE 802.af/at 24 V passive PoE. All of the features of the EdgeSwitch can be easily managed through the included advance user interface. Administrators can configure and monitor their network through an intuitive graphical user interface or convert to the command-line interface available through telnet and SSH.


Advanced Switching Technologies


Build and expand your network with the Ubiquiti Networks EdgeSwitch, part of the EdgeMAX line of products. The EdgeSwitch is a fully managed PoE+ Gigabit switch, delivering robust performance and intelligent switching for growing networks. The EdgeSwitch offers an extensive suite of advanced Layer-2 switching features and protocols, and also provides Layer-3 routing capability.


Switching Performance


The EdgeSwitch offers the forwarding capacity of up to 70 Gb/s to simultaneously process traffic on all ports at line rate without any packet loss.


PoE+ Flexibility


The EdgeSwitch models offers 48 PoE Gigabit Ethernet ports of auto-sensing IEEE 802.3af/at or configurable 24V Passive PoE to simplify your infrastructure. By default, the EdgeSwitch automatically detects 802.3af/at devices so they automatically receive PoE. For 24V Passive PoE devices, manually enable 24V passive PoE using the EdgeSwitch Configuration Interface.


Fiber Connectivity


The EdgeSwitch provides fiber connectivity options for growing networks. For high-capacity uplinks, the 48-port model includes two SFP and two SFP+ ports, providing up to 10 Gb/s uplinks.


Comprehensive User Interface


Designed for convenient management, the EdgeSwitch Configuration Interface allows administrators to configure and monitor switch features in a graphical user interface. For advanced users, an industry-standard command-line interface (CLI) is available through telnet and SSH.


Powerful Functionality


The EdgeSwitch uses an enhanced operating system that provides basic switching features, PoE configuration per port, and a variety of advanced features including:
MSTP/RSTP/STP
VLAN, Private VLAN, Voice VLAN
Link Aggregation
DHCP Snooping, IGMP Snooping
TACACS+, RADIUS, 802.1X, MAC Filtering, ACL
DiffServ, CoS Static Routing, Policy-Based Routing

Specifications

Total Non-Blocking Throughput
70 Gb/s

Switching Capacity
140 Gb/s

Forwarding Rate
104.16 Mp/s

Max Power Consumption
500 W

Power Method
100-240 VAC / 50-60 Hz, universal input

Power Supply
AC/DC, internal, 500 W

LED Indicators
RJ45 Data Ports: PoE, Speed/Link/Activity
SFP+/SFP Data Ports: Speed/Link/Activity

Networking Interface
48 x 10/100/1000 Mb/s RJ45 Ethernet ports
2 x 1/10 Gb/s SFP+ Ethernet ports
2 x 1 Gb/s SFP Ethernet ports

Management Interface
Ethernet in/out band

Certifications
CE, FCC, IC

Rackmount
Yes, 1U high

ESD/EMP Protection
 Air: ±24 kV, Contact: ±24 kV

Operating Temperature
23 to 104°F / -5 to 40°C

Operating Humidity
5 to 95% non-condensing

Shock and Vibration
ETSI300-019-1.4 Standard

PoE Ports
POE+ IEEE 802.3af/at (Pins 1, 2+; 3, 6-)
24 VDC Passive PoE (Pins 4, 5+; 7, 8-)

Maximum PoE Wattage Per Data Port
Max. PoE+ Wattage per Port by PSE
34.2 W
Max. Passive PoE Wattage per Port
17 W

Voltage Range
50-57 voltage range 802.3at mode
Manufacturer Part No:
ES-48-500W
Brand:
Product Type:
-
UPC
810354020674
Product Family:
EdgeSwitch
Shipping Weight:
6.2 kg
PB Part No:
NETUBI1092
Product Model:
ES-48-500W
Warranty: 12 months *
