APC Rack ATS, 230V, 16A, C20 in, (8) C13 (1) C19 out
APC Rack ATS, 230V, 16A, C20 in, (8) C13 (1) C19 out
- Brand: APC
- MPN: AP4423A
- Part #: RACAPC4423
- UPC: 731304432449
- Brand: APC
- MPN: AP4423A
- Part #: RACAPC4423
- UPC: 731304432449
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Mounts, Rails & Plinths





APC Rack ATS, 230V, 16A, C20 in, (8) C13 (1) C19 out
- Brand: APC
- MPN: AP4423A
- Part #: RACAPC4423
- UPC:731304432449

Product URL: https://www.pbtech.co.nz/product/RACAPC4423/APC-Rack-ATS-230V-16A-C20-in-8-C13-1-C19-out
Branch | New Stock | On Display |
---|---|---|
Auckland - Albany | 0 | |
Auckland - Glenfield | 0 | |
Auckland - Queen Street | 0 | |
Auckland - Auckland Uni | 0 | |
Auckland - Newmarket | 0 | |
Auckland - Westgate | 0 | |
Auckland - Penrose | 0 | |
Auckland - Henderson (Express) | 0 | |
Auckland - St Lukes | 0 | |
Auckland - Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Auckland - Head Office | 0 | |
Auckland - East Tamaki Warehouse | 0 | |
Christchurch - Hornby | 0 | |
Christchurch - Christchurch Central | 0 | |
Dunedin | 0 |
Features
- Monitor temperature and humidity efficiently
- Dual input power cords to enhance uptime for critcal loads
- Connect and manage up to 32 Rack ATSs from one IP address
- Seamless switching with transfer time 10ms
Specifications
Main
Main Input Voltage
230 V AC 1 phase
Product or Component Type
Automatic transfer switch
Main Output Voltage
230 V AC 1 phase
Input Connection Type
IEC 60320 C20 16 A 2P+E
Number of rack unit
1U
Physical
Color
Black
Height
1.7 in (44 mm)
Width
17.008 in (432 mm)
Depth
9.3 in (236 mm)
Net Weight
8.25 lb(US) (3.74 kg)
Mounting Location
Front
Mounting preference
No preference
Mounting Mode
Rack-mounted
Mounting position
Horizontal
Input
Input Frequency
50/60 Hz
Line Rated Current
16 A
Acceptable Input Voltage
207…253 V
Max line current
20 A
Input current limits
20 A
Load Capacity
3700 VA
Output
Number of power socket outlets
8 IEC 60320 C13 10 A 2P+E
1 IEC 60320 C19 16 A 2P+E
Number of power socket outlets
9
Protection Type
Without circuit breaker
Cord Length
8.005 ft (2.44 m)
Conformance
Product Certifications
cUL Listed
CE
UL Listed
Standards
EN 55022 Class A
FCC Part 15 class A
Environmental
Ambient Air Temperature for Operation
23…113 °F (-5…45 °C)
Relative Humidity
5…95 %
Operating altitude
0...10000 ft
Ambient Air Temperature for Storage
-13…149 °F (-25…65 °C)
Storage Relative Humidity
5…95 %
Storage altitude
0…50000 ft (0…15240 m)
