KEF CI200QSB-THX Ultra Thin Bezel 8" Square In-Wall Subwoofer (Pair)
THX ULTRA2 & THX SELECT2 Certified - 8" LF Driver - RECOMMENDED AMPLIFIER - KASA500 CUT OUT- 238 X 238MM
KEF CI200QSB-THX Ultra Thin Bezel 8" Square In-Wall Subwoofer (Pair)
THX ULTRA2 & THX SELECT2 Certified - 8" LF Driver - RECOMMENDED AMPLIFIER - KASA500 CUT OUT- 238 X 238MM
- Brand: KEF
- MPN: CI200QSB-THX
- Part #: SPKKEF1170
- UPC: 637203212413
- Brand: KEF
- MPN: CI200QSB-THX
- Part #: SPKKEF1170
- UPC: 637203212413
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Ceiling & Wall Mounted Speakers
KEF CI200QSB-THX Ultra Thin Bezel 8" Square In-Wall Subwoofer (Pair) THX ULTRA2 & THX SELECT2 Certified - 8" LF Driver - RECOMMENDED AMPLIFIER - KASA500 CUT OUT- 238 X 238MM
- Brand: KEF
- MPN: CI200QSB-THX
- Part #: SPKKEF1170
- UPC:637203212413
Product URL: https://www.pbtech.co.nz/product/SPKKEF1170/KEF-CI200QSB-THX-Ultra-Thin-Bezel-8-Square-In-Wall
| Branch | New Stock | On Display |
|---|---|---|
| Auckland - Albany | 0 | |
| Auckland - Glenfield | 0 | |
| Auckland - Queen Street | 0 | |
| Auckland - Auckland Uni | 0 | |
| Auckland - Westgate | 0 | |
| Auckland - Penrose | 0 | |
| Auckland - Henderson (Express) | 0 | |
| Auckland - St Lukes | 0 | |
| Auckland - Manukau | 0 | |
| Hamilton | 0 | |
| Tauranga | 0 | |
| New Plymouth | 0 | |
| Palmerston North | 0 | |
| Petone | 0 | |
| Wellington | 0 | |
| Auckland - Head Office | 0 | |
| Auckland - East Tamaki Warehouse | 0 | |
| Christchurch - Hornby | 0 | |
| Christchurch - Christchurch Central | 0 | |
| Dunedin | 0 |
Features
Ci200QSb-THX
Certified to THX ULTRA2 and THX SELECT2 standards, the formidable Ci200QSb-THX in-wall subwoofer delivers deep bass and theatre thumping output capabilities, matched to the uncanny ability to deliver all the drama and emotional intensity of full theatre sound quality.
With a powerful high-output 200mm (8in.) sub-bass driver, the Ci200QSb-THX can be used in passive mode to supplement the LF output of KEF's Ci series in-wall or in-ceiling speakers. In Active mode, when 2 pair of the Ci200QSb-THX subwoofer are powered by the powerful 250Wx 2 KEF KASA500 System Amplifier the performance meets THX Select2 specification. When 4 pair of the Ci200QSb-THX are powered by 2 KEF KASA500 System Amplifiers the performance meets THX Ultra2 specification.
- THX Certified Ultra2 / Select2
- 200mm (8in.) woofer unit with extended bass response
- Paintable Ultra-Thin Bezel (UTB) and magnetic grille to blend unobtrusively with décor
- Fast, versatile installation on virtually any surface via dogleg
- Can be used in passive mode with internal crossover or active mode with KEF's KASA500 System Amplifier for THX certified performance
- Sold in Pairs
Specifications
Model
Ci200QSb -THX
Series
Q Series
Nominal Impedance
6O - Passive Mode (Crossover "ON")
N/A - Active Mode (KASA500)
Sensitivity(2.83V/1m)
85dB - Passive Mode (Crossover "ON")
N/A - Active Mode (KASA500)
Frequency response
(±6dB) 40Hz~100Hz - Passive Mode (Crossover "ON")
18Hz~140Hz - Active Mode (KASA500)
Crossover frequency
100Hz - Passive Mode (Crossover "ON")
N/A - Active Mode (KASA500)
Drive Units
LF: 200mm (8")
Recommended amplifier power
10~150W - Passive Mode (Crossover "ON")
KASA500 - Active Mode (KASA500)
Product external dimensions
Diameter: 273 x 273 x 106mm (10.75 x 10.75 x 4.17")
Cutout dimensions
H x W: 238 x 238mm (9.37 x 9.37")
Mounting depth from the surface
101.6mm (4")
Optional rough-in frame
RIF200S
Optional rear enclosure
RNC130R
Weight"
3.3kg (7.28 lbs)
