Features
The ECS4150-28P is a PoE switch which can provide up to 30 Watts to Power Devices such as Wireless Access Point, VoIP Phone, Surveillance camera, IoT devices etc over Cat 5 UTP cable eliminate the need for individual power source.
The ECS4150-28P is packed with features that bring high availability, comprehensive security, robust multicast control, and advance QoS to the network edge, while maintaining simple management. The switch also supports the most advance IPv6 management, IPv6 security, and IPv6 multicast control in accordance with the growth of IPv6 deployment.
- Best price-performance Gigabit Ethernet access switch with 10G uplinks
- Low power consumption and fan speed control
- ITU-T G.8032 ERPS L2 Ring protection with <50 convergence time
- Comprehensive and field proven software features for ISP/ Carrier to provide broadband access, IPTV services
- L2+/ Lite L3 feature upgrades the L2 switch with routing functionality
- Enhanced Security,IPv6 and Multicast features
- Simple management (CLI, SNMP, Web, ecCLOUD, TIP OLS)
- Complete Private MIB to fully control and monitor the switch via customer's EMS
Interfaces

1.24 x RJ-45 10/100/1000BASE-T ports (ECS4150-28T)
2.24 x RJ-45 10/100/1000BASE-T PoE ports (ECS4150-28P)
3.4 x SFP+ 10 Gigabit uplink ports
4.RJ-45 management port
5.RJ-45 console port
6. USB management port
7.AC power input
Specifications
Product Model
ECS4150-28P
Port
RJ-45 10/100/1000BASE-T Ports
24
SFP+ 10 Gigabit Uplink Ports
4
RJ-45 Console Port
1
USB port
1
Performance
Switching Capacity
128 Gbps
Forwarding Rate
95 Mpps
NAND Flash Memory
256 MB
DRAM
1 GB
MAC Address Table
16 K
Jumbo Frames
10 KB
Auto-negotiation, Auto-MDI/MDIX
Yes
Packet Buffer
1.5 MB
MTBF
125,675 hrs
Heat Dissipation
1536 Btu/h
Acoustic Noise
50 db
Mechanical
Dimension (W x D x H) cm
44 x 28 x 4.4 cm
Weight
4.75 kg (10.47 lb)
Power Supply
AC 100-240 VAC, 50/60 Hz
Yes
Max System Power Consumption (Watts)
450 Watts
PoE
IEEE 802.3af
Yes
IEEE 802.3at
Yes
Power budget
370 W
Auto disable exceeding power budget
Yes
Dynamic power allocation
Yes
Environmental
Operating Temperature
-5 ~ 45ºC
Storage Temperature
-40 ~ 70ºC
Operating Humidity (non-condensing)
5% to 95%
Storage Humidity (non-condensing)
5% to 95%
Environmental Regulation compliance: WEEE
Yes
Environmental Regulation compliance: RoHS
Yes
Certification
FCC Class A
Yes
CE
Yes
Safety Compliance: CB (IEC/EN 62368-1)
Yes
Safety Compliance: UL (CSA 22.2 No 62368-1 & UL62368-1)
Yes
