LevelOne 8-Port Fast Ethernet Switch Unmanaged Desktop Sized
LevelOne 8-Port Fast Ethernet Switch Unmanaged Desktop Sized
- Brand: LevelOne
- MPN: FEU-0812
- Part #: SWHLEL0812
- UPC: 846359003145
- Brand: LevelOne
- MPN: FEU-0812
- Part #: SWHLEL0812
- UPC: 846359003145
Similar in-stock products available at PB Tech right now
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular Switches





LevelOne 8-Port Fast Ethernet Switch Unmanaged Desktop Sized
- Brand: LevelOne
- MPN: FEU-0812
- Part #: SWHLEL0812
- UPC:846359003145

Product URL: https://www.pbtech.co.nz/product/SWHLEL0812/LevelOne-8-Port-Fast-Ethernet-Switch-Unmanaged-Des
Branch | New Stock | On Display |
---|---|---|
Auckland - Albany | 0 | |
Auckland - Glenfield | 0 | |
Auckland - Queen Street | 0 | |
Auckland - Auckland Uni | 0 | |
Auckland - Newmarket | 0 | |
Auckland - Westgate | 0 | |
Auckland - Penrose | 0 | |
Auckland - Henderson (Express) | 0 | |
Auckland - St Lukes | 0 | |
Auckland - Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Auckland - Head Office | 0 | |
Auckland - East Tamaki Warehouse | 0 | |
Christchurch - Hornby | 0 | |
Christchurch - Christchurch Central | 0 | |
Dunedin | 0 |
Features
The LevelOne FEU-0812 is a wire-speed, non-blocking networking device that provides 8 ports 10/100 Mbps Ethernet connections. All ports support auto-negotiation and auto-MDI/MDIX sensing, eliminating the need for crossover cables or Uplink Ports. Each port can be used as general network port or as connecting port into a router, server, hub or another network switch.
- Provides flexibility of 8 x 10/100BASE-TX ports
- 10/100Mbps, full/half-duplex, auto-negotiation, auto-MDI/MDIX
- Quick and easy installation
- Supports 1K MAC address auto-learning and auto-aging
- Simple Plug and Play installation
Specifications
General
Brand
LevelOne
Manufacturer Part Number
FEU-0812
Color
Black
Dimensions
130.7 x 52 x 21 mm
Weight
0.11 kg
System specifications
Power Supply
Input : 5VDC, 0.55A (External Power Adapter)
Data Rate
100Mbps
Power Supply Included
Yes
Power Consumption
1.7 W
Standard
IEEE802.3 (10BASE-T)
IEEE802.3u (100BASE-T)
IEEE802.3az (Energy Efficient Ethernet)
IEEE802.3x
Mount
Desk mount
MAC address table
1 K
Indicators
Power
Link/Active
Packet buffer
1.19 Mpps
Backplane (Gbps)
1.6
Compliance
Compliance
CE
UKCA
RoHS
Environmental Condition
Operating Humidity
10% RH ~ 90% RH
Operating Temperature
0°C ~ 45°C
Storage Humidity
5% RH ~ 90% RH
Storage Temperature
-40°C ~ 70°C
