Features
Elevate your business above the 1Gb barrier
As a leading provider of network equipment for SMBs, NETGEAR® understands the importance of providing a great choice of speed and power that can support the business's needs to keep up with the growth of network speed, virtualization, cloud-based services and applications like VoIP, video streaming and IP surveillance, whether in the hospitality, catering, education or retail domains. Also, the increase in speeds for WiFi 6 Access Points now imply the need for faster speeds in the network.
The MS510TXM and MS510TXUP 8-Port Multi-gig/10G switches with 2 SFP+ Ports join the NETGEAR Standalone Smart Managed Pro Switches family, adding multi-gigabit/10G speed, a high PoE budget for all PoE/PoE+ devices, and
Ultra60 PoE++ support (295W total PoE budget for MS510TXUP) for deploying devices with multi-gig capabilities and speed, such as WiFi 6 Access Points (eg. WAX610 from NETGEAR), multi-gig or 10G NAS.
NETGEAR Smart Managed Pro Switches offer powerful Layer 2+/Lite L3 features, great PoE functionality, and enhanced performance and usability. They are purposely designed for modern applications and support BYOD which requires companies to have more bandwidth to ensure smooth network connectivity with no congestion.
Furthermore, in 2.5G or 5G speeds, there is no requirement to upgrade your cabling from Cat5E, allowing for savings in installation costs.
To empower the Wireless and PoE applications, NETGEAR Insight Remote/ Cloud Management is added to these two new switch models as an optional management mode. By activating the NETGEAR Insight Cloud management, the
users will enable management features allowing businesses simpler configuration and deployment from anywhere using the NETGEAR Insight app from mobile devices or the Insight Cloud Portal from any device with a web browser.
Highlights
Temperature- and load-based fan-speed control combines accurate monitoring with minimized system acoustic noise, ideal for office enviornment. The MS510TXM and MS510TXUP support quiet rack mounting operation with a maximum of 25dB (MS510TXM) and 33 dBA (MS510TXUP) even at full power and 25°C (77°F) ambient.
More Powerful Switch with Multi-gigabit/10G Speed
- 4 x 1G/2.5G ports and 4 x multigig/10G ports
- 8 x Ultra60 PoE++ ports with 295W PoE budget (MS510TXUP only)
- 2 dedicated 10G SFP+ fiber uplink ports
Fast and flexible solution for SMB data, voice and video converged network
- Non-blocking switching with 140Gbps bandwidth
- Flexible rack-mounting option
Ideal companion to your NETGEAR WAX610
- Connect and power your WAX610 with MS510TXUP
- Connect your WAX610PA with MS510TXM
- Manage all devices from a single dashboard with NETGEAR Insight
Powerful Connectivity and Security
- Advanced VLAN support for better network segmentation
- L2/L3/L4 access control lists (ACLs) for granular network access control including 802.1x port authentication
- Advanced per port PoE controls for remote power management of PoE powered devices including operation scheduling
- Advanced QoS (Quality of Service) for traffic prioritization including portbased, 802.1p and L2/L3/L4 DSCPbased
- Auto "denial-of-service" (DoS) prevention
- IGMP Snooping and Querier for multicast optimization
- Egress Rate limiting and priority queuing for better bandwidth allocation
- Port mirroring for network monitoring
- Energy Efficient Ethernet (IEEE 802.3az) for maximum power savings
- IPv6 management: IPv6 QoS, IPv6 ACL, IPv6 Multicast, and static and dynamic IPv6 address assignment
- Cable test to troubleshoot connection issues
- Easy-to-use Web browser-based management GUI available in English, German and Japanese
- SNMP v1, v2c, v3 and RMON remote monitoring
Fully-integrated cloud-manageable devices
- Optional NETGEAR Insight Remote/ Cloud Management on both switch models. Easily activated through the local device GUI.
Smart IT, not Big IT
- Easy to manage via web-based Management interface or Smart Control Center on Windows PC for multi-switch deployment
- NETGEAR Switch Discovery Tool (NSDT) to discover, register and access to the local browser interface to configure the switches
Download data sheet: https://www.netgear.com/media/MS510TXUP-MS510TXM-DS_tcm148-115417.pdf
Specifications
Technical Specifications
1G/2.5G Ethernet RJ-45 Copper ports (100M/1G/2.5G) - 1000BASE-T
4
Multi-gigabit/10G Ethernet RJ-45
Copper ports (100M/1G/2.5G/5G/10G) - 1000BASE-T
4
10 Gigabit SFP+ (fiber) ports (1G/10G) - 1000BASE-X
2 (dedicated)
Power Supply
Internal Power Supply
LEDS
Front (per device)
Power (with Cloud Mode Indicator),
Fan, PoE Max, LED Mode
Front (per port)
Speed/Link/Activity
Unified Network Management (Discovery, Setup, Monitoring, and Management) through NETGEAR Insight Cloud Management
Discovery, setup, monitoring and management
NETGEAR Insight mobile app on phone or tablet; Insight Cloud Portal from PC, Mac, or tablet web browser
Remote/Cloud management
Anywhere, anytime, from the palm of your hand using Insight mobile app or from any PC, Mac, or tablet web browser using the Insight Cloud Portal
Centralized network configuration (policies)
Centralized network configuration (policies) across Insight Managed Switches, Wireless Access Points, and Business-class ReadyNAS Storage for VLANs, ACLs, QoS, and LAGs
Device auto-join and configure (zero-touch provisioning
Additional Insight Managed devices added to the network automatically inherit the network configuration
Multi-site, multi-network single pane-of-glass view
Manage multiple sites, locations, and networks in a single view using the Insight mobile app or Insight Cloud Portal
Multi-switch, multi-port concurrent configuration for ACLs, VLANs, QoS, PoE, etc
Apply settings and policies on multiple ports across multiple switches all at the same time using the Port Config Wizard
Performance Specifications
CPU
1GHz dual core
256MB RAM
64MB SPI FLASH
Packet buffer memory (Dynamically shared across only used ports)
2 MB
Forwarding modes
Store-and-forward
Bandwidth (non-blocking, full duplex)
140 Gbps
Priority queues
8
Priority queuing
Weighted Round Robin (WRR) and Strict Priority
MAC Address database size (48-bit MAC addresses)
32K
Multicast groups
256
Number of VLANs
56
Number of DHCP snooping bindings
256
Performance Specifications Cont.
Access Control Lists (ACLs)
100 shared for MAC, IP and IPv6 ACLs (ingress)
Packet forwarding rate (64 byte packet size) (Mfps or Mpps)
14.8
2.5 G Copper standard latency (µsec) (64-byte; 1518-byte; 9216-byte frames)
64-byte: 5.903 µsec
1518-bye: 6.040 µsec
9216-byte: 6.079 µsec
10G Copper Uplink latency (µsec) (64-byte; 1518-byte; 9216-byte frames)
64-byte: 2.420 µsec
1518-bye: 2.501 µsec
9216-byte: 2.499 µsec
10G SFP+ Fiber latency (µsec) (64-byte; 1518-byte; 9216-byte frames)
64-byte: 1.257 µsec
1518-bye: 1.337 µsec
9216-byte: 1.348 µsec
Jumbo frame support
10K
Acoustic noise level @ 25° C (dBA) (ANSI-S10.12)
25 dBA
Mean Time Between Failures (MTBF) @ 25° C
1,059,519 hrs (121 yrs)
Power Consumption
Max power (worst case, all ports used, line-rate traffic) (Watts)
47.0 W
Min power (link-down standby) (Watts)
23.90 W
Heat Dissipation (min w/o PoE and max with full PoE) (BTU/hr)
Max: 160.458 BTU/hr
Min: 81.5946 BTU/hr
Energy Efficient Ethernet (EEE) IEEE 802.3az
Yes (deactivated by default)
Fan(s) (temperature- and load-based speed control)
2
Physical Specifications
Dimensions (W x D x H)
330 x 206 x 43 mm
( 13.0 x 8.12 x 1.7 in)
Weight
2.08 kg (4.25 lb)
Mounting options
Desktop, rack-mount
Environmental Specifications
Operating Temperature
0° to 50°C (32° to 122°F)
Humidity
95% maximum relative humidity (RH), non-condensing
Altitude
10,000 ft (3,000 m) maximum
Storage Temperature
-20° to 70°C (- 4° to 158°F)
Humidity (relative)
95% maximum relative humidity (RH), non-condensing
Altitude
10,000 ft (3,000 m) maximum
