Vertiv PSA500MT3-230U PSA - 500VA MINI TOWER UPS
Out of stock
Vertiv PSA500MT3-230U PSA - 500VA MINI TOWER UPS
- Brand: Vertiv
- MPN: PSA500MT3-230U
- Part #: UPSLBT721015
- UPC: 835514007388
- Brand: Vertiv
- MPN: PSA500MT3-230U
- Part #: UPSLBT721015
- UPC: 835514007388
Product is out of stock. View similar products in-stock at PB Tech
Features
Specifications
Reviews
Delivery & Pick-up
Returns & Warranty
Popular UPS - Line Interactive





Vertiv PSA500MT3-230U PSA - 500VA MINI TOWER UPS
- Brand: Vertiv
- MPN: PSA500MT3-230U
- Part #: UPSLBT721015
- UPC:835514007388

Product URL: https://www.pbtech.co.nz/product/UPSLBT721015/Vertiv-PSA500MT3-230U-PSA---500VA-MINI-TOWER-UPS
Branch | New Stock | On Display |
---|---|---|
Auckland - Albany | 0 | |
Auckland - Glenfield | 0 | |
Auckland - Queen Street | 0 | |
Auckland - Auckland Uni | 0 | |
Auckland - Newmarket | 0 | |
Auckland - Westgate | 0 | |
Auckland - Penrose | 0 | |
Auckland - Henderson (Express) | 0 | |
Auckland - St Lukes | 0 | |
Auckland - Manukau | 0 | |
Hamilton | 0 | |
Tauranga | 0 | |
New Plymouth | 0 | |
Palmerston North | 0 | |
Petone | 0 | |
Wellington | 0 | |
Auckland - Head Office | 0 | |
Auckland - East Tamaki Warehouse | 0 | |
Christchurch - Hornby | 0 | |
Christchurch - Christchurch Central | 0 | |
Dunedin | 0 |
Features
The Liebert PSA is an economical, environmentally-friendly line-interactive UPS that offers full- featured power protection for small offi ce computers and electronic equipment. Liebert Multilink software automatically powers down your computer in the event of an extended power outage. It also has full event management and display UPS instrumentation on screen. Designed with simple controls for easy operation, the Liebert PSA provides up to fi ve minutes of back-up time at full load, more than enough time to save work in process and shut down your system. Liebert MultiLink USB shutdown software and a USB cable are also included, to allow remote alerts and automated graceful shutdown of the UPS and connected systems.
Flexibility
- Available in four sizes: 500, 650, 1000 and 1500VA; 120VAC or 230VAC
- Three to six battery-backed UPS outlets, depending on model size
- One to two surge-only outlets, differentiated by color
Reliability
- Up to five minutes of battery backup time at full load
- Full sequenced battery testing to ensure batteries are available when needed
- Advance early warning of UPS shutdown
- Lightning and surge protection (TVSS)
- RJ-45 port for data line surge protection
- USB communications / shutdown software and cable included
- User-replaceable batteries
Total Cost of Ownership
- Two-year replace or repair warranty
Environment-friendly
- Full RoHS R6 compliance
Specifications
Model Number
PSA500MT3-230U
Input Connection
IEC-320 C14
Output Connection
IEC-320 C13
Number of battery-backed outlet
3
Number of surge outlet
1
Communication Interface
USB
Dimensions: H x W x D (mm)
95 x 356 x 171
Net Weight (kg)
6
Shipping Weight (kg)
7
Form Factor
Mini tower
Software
Liebert Multilink 4, support for Windows NT / 2000 / XP / Vista
Capacity (VA / W)
500 / 300
Nominal Input Power
230VAC, single phase with ground, 50 or 60Hz auto-select
Input Voltage Window
160 to 287VAC
Input Frequency Window
50 / 60Hz ± 5%
Input Protection Type
Resettable circuit breaker
Default frequency
50Hz
Boost Mode Voltage
Input Voltage x 115%
Buck Mode Voltage
Input Voltage / 115%
Transfer Time (AC to DC)
4 to 6ms typical
Surge Protection
220J
Voltage
230VAC
Voltage Regulation
= 5%
Wave Form
Stepped Sinewave
Battery type
Sealed, non-spillage, maintenance-free, lead acid with 5 year typical lifetime
Backup Time at Full Load (minutes)
4
Typical Recharge Time
6 to 8hr to 90%
EMI Classification
IEC / EN / AS62040-2
Safety
IEC / EN/ AS62040-1-1
Transportation
ISTA procedure 1A certifi cation
WEEE and ROHS
Yes
Operation Condition
3,000 meter max. elevation, 0-90% humidity non-condensing 0 to 40°C
Noise Level
< 40dBA on line mode
