PowerShield PSG750 SafeGuard UPS 750VA 450W


The item you're looking at is currently unavailable or has limited stock, how about this one instead?

PowerShield PSG750 SafeGuard UPS 750VA 450W

  • Capacity (VA):750VA
  • Capacity (Watts):450W
  • Form Factor:Tower
  • Outlets:3
  • Recharge Time:8 Hours
  • Transfer Time:6ms
  • Run Time (Full Load):3 Minutes
  • Run Time (Half Load):6 Minutes

Product is out of stock. View similar products in-stock at PB Tech

Features

The PowerShield SafeGuard remains one of the most popular UPS choices as it provides automatic voltage
regulation, battery backup, surge protection and telephone/modem protection. This line interactive powerboard style
UPS can also be wall mounted. The SafeGuard is perfect for workstations, telephone and security applications.

Exceptional surge protection

Best surge protection in its class. 460 Joules/11000 Amps protection .

Extra surge protected sockets

The SafeGuard provides three Australian outlets, which provide a high level of surge protection as well as a UPS output supply, to keep essential systems running during utility power outages. It also provides an additional three Australian surge only protected sockets that do not require battery backup.

Hot swappable batteries

Batteries are easily hot swappable and user replaceable, extending the service life of your UPS.

Fax / LAN surge protection port

Includes ports for telephone or Lan network connections to provide extra surge protection on these lines.

Cold start function

The UPS can turn on equipment when there is no AC simply by connecting equipment and turning the UPS on. This is excellent when users need to power equipment for a short time.

Off-mode charging

The plugged in UPS will continue to charge internal batteries whether the unit is on or off.

HID Communication via USB

HID can be used for simple management with Windows, Apple, Linux and NAS devices and a large variety of industrial controllers that support HID.

HID ensures a safe and orderly shutdown in the event of a prolonged power outage.

NetGuard software communication via USB

The free, downloadable NetGuard software provides complete power monitoring. Parameters such as input/output voltage, battery remaining time and load level are easily viewed. It also ensures a safe and orderly shutdown in the event of a prolonged outage.

Automatic voltage regulation (AVR)

The AVR automatically bucks/boosts unstable fluctuating utility voltages, bringing it within 10% of nominal voltage range and thereby protecting valuable equipment.

Wallmountable / Powerboard style

This AVR powerboard style UPS has been conveniently designed to suit physically restricted areas. Additionally as an option, the UPS can also be wall mounted.

Specifications

Capacity

750VA / 450W Line interactive

Input

Voltage

240Vac (Nominal)

Voltage range

177 to 290Vac

Frequency

50Hz or 60Hz (Auto sensing)

Output

Output Voltage

240Vac ±10%

Frequency range (Batt. Mode)

50Hz or 60Hz ±-1Hz

Transfer time

6 msec (Typical)

Wave Form (Batt. Mode)

Simulated Sine Wave

Australian Outlets

3 (UPS and Surge Protection)

Australian Outlets

3 (Full Time Surge Protection)

Battery

Capacity

12V*9AH

Backup Time

25 min (1 PC load at 100W)

Typical Recharge Time

8 hours recover to 90% capacity

Protection

Full protection

Overcharge, discharge, short circuit and thermal protection

Surge protection

468Joules /11000Amps - Best in its class

Data protection

Tel/LAN, RJ45 connector

Communication & management

Interface

USB interface

Software

PowerShield® NetGuard® supports Windows, Linux, Unix & Mac

HID

Supports Windows, Apple, Linux, NAS and various industrial controllers

LED Alarm

AC Mode, Battery Mode, Low Battery (Batt. Mode), Fault

Audible Alarm

Battery Mode, Low Battery (Batt. Mode), Fault

Physical

Dimensions L x W x H (mm)

292 x 91 x 199

Weight (kgs)

6.5

Operating enviroments

Temperature

0 - 400°C

Humidity

0-90% (RH Non-condensing)

Noise level

<5dB (No Fan)

Compliance

Safety

EN62040 - 1 - 1 2003, IEC60950 - 1: 2001

EMC

EN62040 - 2 2006

RoHS

Directive 2011/65/EU

Typical run times

Small telephone with 4 handsets

60 minutes

Medium telephone with 16 hand sets

23 minutes

DVR and 4 cameras

62 minutes

DVR and 16 cameras

37 minutes

Computer with 17" LCD monitor

17 minutes

Computer with 24" LCD monitor

12 minutes

Manufacturer Part No: PSG750 Brand: PowerShield Product Type: -
UPC - Product Family: - Shipping Weight: 6.52 kg
PB Part No: UPSPSD0036 Product Model: -

Warranty: 12 months local warranty *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.

Reviews

There are currently no reviews for this product
