Alphacool NexXxoS XT45 Full Copper X-Flow 360mm - Black - 45mm Thick

PB Tech price
PB Tech price
$ 164 .35
 +GST
$ 189 .00
 inc GST
$164.35  +GST
$189.00

Alphacool NexXxoS XT45 Full Copper X-Flow 360mm - Black - 45mm Thick

Equip with an internal protective ledge!
PB Tech price
$ 164 .35 $ 189 .00
 +GST  inc GST
Hurry, only 2 units left!


Click & Collect: Select your store to check availability
Delivery: Order now and it ships today When will I receive it?
$164.35  +GST
$189.00

Radiator Size

240mm 360mm

Fan Size

N/A

Colour

Black

Number of Fans

3

CPU Air Cooler Height

N/A

LED Colour

N/A

Reversed Fan Blade

N/A

Sound Level (Roughly)

N/A

COMBO DEALS: Buy Together and SAVE!

Save even more by creating your own combo deal with any of the items below and the Alphacool NexXxoS XT45 Full Copper X-Flow 360mm - Black - 45mm Thick
Alphacool NexXxoS XT45 Full Copper X-Flow 360mm - Black - 45mm Thick
Total:
$ 424 .20
 +GST
$ 487 .83
Buy together and save $8.71 $10.02
Samsung 990 Pro 1TB M.2 NVMe Internal SSD PCIe Gen 4 - Up to 7450MB/s Read - Up to 6900MB/s Write - 1200K/1550K IOPS - 5 Years Warranty or 600 TBW
Samsung 990 Pro 1TB M.2 NVMe Internal SSD PCIe Gen 4 - Up to 7450MB/s Read - Up to 6900MB/s Write - 1200K/1550K IOPS - 5 Years Warranty or 600 TBW
$189.00 $217.35

$184.20  +GST

$211.83

Cooler Master MasterFan MF120 Halo 3 in 1 Kit ARGB PWM 120mm ARGB Fan, Dual loop Addressable RGB Lighting, 3 X 120MM ARGB Fans with Controller
Cooler Master MasterFan MF120 Halo 3 in 1 Kit ARGB PWM 120mm ARGB Fan, Dual loop Addressable RGB Lighting, 3 X 120MM ARGB Fans with Controller
$60.00 $69.00

$56.52  +GST

$65.00

Save 40% with code MOVEITPB Save 40% with code MOVEITPB

Features

The new Alphacool NexXxos radiators, a name that stands for experience and quality has come to bring a fresh breeze to the radiator market.

Every user of a water cooling system needs a radiator and everyone has different requirements towards the heat exchanger. Of course the customer always demands the best in its class. The Alphacool NexXxos radiators have come to compete with and to beat the best in their class and to be the best radiator in all sizes. No more endless choices without a clear class leader, the Alphacool NexXxos is the one tool for all your needs!

Alphacool has been the company to introduce new developments and improvements in the radiator and water cooling sector generally many times over the last years.

Following this tradition, the new NexXxos radiators are the first to truly deserve the "Full copper" attribute. All main parts, not only the fins and channels, but the chambers are also made from copper. This brings an improvement in performance where other radiators are left without a chance. In structure, the Alphacool NexXxoS X-Flow Radiators differentiate materially from the standard radiators. The X.Flow Radiators are designet for high flow rates. The bevelled copper chambers on both sides have an identical structure. This Water is jetting at the same time through all avialable channels to the other chamber to whitch it then leaves the radiator.

Versatile and easy mounting is one of the main points, on which the research and development department at Alphacool focused. The chamber offers three possibilities for fitting installation on both inlet and outlet (not on the NexXos ST30). Less angled fittings are needed, improving flow rates and offering more mounting possibilities.

Here, too, Alphacool provides the popular sizes of the 120mm series. Different thicknesses, 30mm, 45mm and 60 mm underscore the broad spectrum that cover these radiators. ?Even mounting and installation of fans and radiator grills is easy and versatile with these radiators: The M3 threads are standard in the radiator sector and available in all lengths at an affordable price.

Even the dreaded insertion of a screw too far into the radiator does not result in expensive damage. Unlike other radiators, the NexXxos series is equipped with an internal protective ledge which stops the screw before it damages the fins.

Fin spacing is always an important factor in radiator design. The new series from Alphacool has a fin design which allows it to perform extremely well even with slow-spinning and medium-speed fans. This is not only pleasant thanks to the fact that it avoids unnecessary noise; it also means that the choice of fans that can be used with these radiators is not restricted.

These radiators are the result of experience and powerful performance meeting future-oriented design and well-thought through solutions.

Specifications

Dimensions (L x W x H)

413 x 124 x 30mm

Quantity of cooling channels

12

Cooling channels

Copper

Color

black

Connection

4x G1/4"

Fan thread

M3

Slats

Copper

Number of fans

3

Fan size

120mm

Housing

Steel

Pressure tested

0.8 bar

Manufacturer

Alphacool

Thickness

29 - 39mm

Fins per inch

16

Manufacturer Part No:
14235
Brand:
Product Type:
-
UPC
-
Product Family:
NexXxoS
Shipping Weight:
3 kg
PB Part No:
WTRAPH14235
Product Model:
XT45
Warranty: 60 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.
