TP-Link TL-WA1201 Wi-Fi Access Point MU-MIMO - Dual-Band AC1200 (450+867Mbps) Captive Portal - Multiple Modes - Access Point - Range Extender - Client modes

PB Tech price
PB Tech price
$ 86 .08
 +GST
$ 98 .99
 inc GST
$86.08  +GST
$98.99  inc GST

TP-Link TL-WA1201 Wi-Fi Access Point MU-MIMO - Dual-Band AC1200 (450+867Mbps) Captive Portal - Multiple Modes - Access Point - Range Extender - Client modes

Expand your WiFi's reach. Full strength WiFi for your entire home made simple!
  • Brand: TP-Link
  • MPN: TL-WA1201
  • Part #: NAPTPL1201
  • UPC:
20

Six easy payments of $16.99 per week*

Laybuy lets you spread the cost of your purchase over 6, interest-free, weekly payments.

Click the button below or select Laybuy as your payment method during the checkout process.

If you do not have a Laybuy account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.

Learn more about Laybuy

Four payments of $25.37 per fortnight*

Klarna lets you spread the cost of your purchase over 4 interest free fortnightly payments.

Click the button below or select Klarna as your payment method during the checkout process.

If you do not have a Klarna account you will be able to create one at checkout.

*Repayments shown above are indicative only and may vary. Ts and Cs and lending criteria apply.

Learn more about Klarna

  • Brand: TP-Link
  • MPN: TL-WA1201
  • Part #: NAPTPL1201
  • UPC:

Ethernet Ports

1

Wireless Transmission Speed

900Mbps

Wi-Fi Bands

Dual

USB Ports

None

Looking for a bargain? Shop Ex-demo stock for this item

What PB Tech customers are saying about this product...

See More Reviews

"Excellent unit. Easy to setup and works well. Great that you can power it by POE."

DD
By: DavidD5 11/04/24

"We live in a tiny house connected to the main broadband via 100m cable to the main house router. This setup is precisely what we required. After a simple plug-in and basic setup, w ...view more"

OH
By: OllieH91 11/04/24

"So easy to set up and just worked perfectly from the outset. Is performing excellently."

MM
By: MarkM7546 12/02/24
Verified Owner

COMBO DEALS: Buy Together and SAVE!

Save even more by creating your own combo deal with any of the items below and the TP-Link TL-WA1201 Wi-Fi Access Point MU-MIMO - Dual-Band AC1200 (450...
TP-Link TL-WA1201 Wi-Fi Access Point MU-MIMO - Dual-Band AC1200 (450+867Mbps) Captive Portal - Multiple Modes - Access Point - Range Extender - Client modes
Total:
$ 230 .70
 +GST
$ 265 .30
 inc GST
Buy together and save $5.62 $6.46
Samsung 870 EVO 500GB 2.5" Internal SSD V-NAND - SATA3 6GB/s - Up to 560MB/s Read - Up to 530MB/s Write - 7mm - 5 Years Warranty
Samsung 870 EVO 500GB 2.5" Internal SSD V-NAND - SATA3 6GB/s - Up to 560MB/s Read - Up to 530MB/s Write - 7mm - 5 Years Warranty
$79.00 $90.85

$77.00  +GST

$88.55  inc GST

TP-Link TL-SG1005D 5-Port Gigabit Unmanaged Switch
TP-Link TL-SG1005D 5-Port Gigabit Unmanaged Switch

TP-Link TL-SG1005D 5-Port Gigabit Unmanaged Switch

Collect from 11 stores by 9:56am today
Ships tomorrow
$27.82 $31.99

$25.21  +GST

$28.99  inc GST

You save 9% You save 9%
Panasonic LR03T/24V AAA 24pcs Alkaline 1.5V Bulk Value Pack Alkaline-Zinc - Longer Lasting protects power for upto 10 years
Panasonic LR03T/24V AAA 24pcs Alkaline 1.5V Bulk Value Pack Alkaline-Zinc - Longer Lasting protects power for upto 10 years

$13.01  +GST

$14.96  inc GST

You save 4% You save 4%

Features

- AC1200 Dual-Band Wi-Fi - 867 Mbps at 5 GHz and 300 Mbps at 2.4 GHz band.
- Flexible Deployment - Supports Passive PoE to carry electrical power and data simultaneously.
- Multiple Modes - Supports Access Point, Range Extender, Multi-SSID, and Client modes to meet any network needs.
- MU-MIMO Technology - Simultaneously transfers data to multiple devices for 2� faster performance.
- Boosted Coverage - Four fixed antennas equipped with Beamforming technology extend and concentrate the Wi-Fi signals.
- Captive Portal - Offers a designed portal page for heightened security and marketing.



*Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection, quality, and client condition.

?Use of MU-MIMO requires clients to also support MU-MIMO.

Specifications

HARDWARE FEATURES

Interface

1× 10/100/1000 Mbps Ethernet Port
(Supports Passive PoE)

Button

Power On/Off Button, WPS Button, Reset Button

External Power Supply

12V/1.5A

Wireless Standards

IEEE802.11b/g/n 2.4 GHz, IEEE 802.11ac/n/a 5 GHz

Dimensions ( W x D x H )

225×145.5×37 in (400×255×72 mm)

Antenna Type

4 Fixed High Performance Antennas

WIRELESS FEATURES

Frequency

2.4 GHz and 5 GHz

Signal Rate

867 Mbps at 5 GHz, 300 Mbps at 2.4 GHz

Reception Sensitivity

5 GHz:
11a 6 Mbps: -95 dBm, 11a 54 Mbps: -81 dBm
11ac VHT20(MCS0): -94 dBm, 11ac VHT20(MCS8): -71 dBm
11n HT40(MCS0): -91 dBm, 11n HT40(MCS7): -71 dBm
11ac VHT80(MCS0): -88 dBm, 11ac VHT80(MCS9): -63 dBm
2.4 GHz:
11g 54Mbps: -78 dBm
11n HT20(MCS0): -92 dBm, 11n HT20(MCS7): -74 dBm
11n HT40(MCS0): -88 dBm, 11n HT40(MCS7): -72 dBm

Transmit Power

CE: <20dBm(2.4GHz), <23dBm(5.15GHz~5.25GHz)
FCC: <30dBm(2.4GHz&5GHz)

Wireless Modes

Access Point, Range Extender, Client, Multi-SSID

Wireless Functions

Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics, Wireless Multicast Forwarding, DHCP Server, Access Control

Wireless Security

64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions

DHCP

Server, DHCP Client List

Quality of Service

WMM

Advanced Functions

Captive Portal

OTHERS

Certification

CE, FCC, RoHS

Package Contents

Wireless Access Point TL-WA1201
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
PoE Power Injector

System Requirements

Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1,
10, MAC OS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
Java-enabled browser

Environment

Operating Temperature: 0°C ~ 40°C(32°F ~ 104°F)
Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Protocol Support

IPv4, IPv6

Manufacturer Part No:
TL-WA1201
Brand:
Product Type:
Wi-Fi Access Point
UPC
-
Product Family:
-
Shipping Weight:
0.85 kg
PB Part No:
NAPTPL1201
Product Model:
TL-WA1201
Warranty: 36 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.

Reviews

4.8 out of 5 Stars Based on 20 Reviews
5 Stars
18
4 Stars
1
3 Stars
0
2 Stars
0
1 Stars
1

Do you own this product?

Write a review and go into the monthly draw Win A $100 PB Tech Gift Card!

300+Mbps throughout the whole house

I bought two of these to cover my house, but in the end I only needed one. Most of the 4-bedroom 150sqm house now has 200-300Mbps off one of these.
Only drawback is that the V3 doesn't support OpenWRT but in the end I just used the factory firmware and it's working well so why change it.

BH
By: BramfordH 04/04/23
Verified Owner
2 out of 2 users found this review helpful
Did you find it helpful?

No hassle access point

Excellent unit. Easy to setup and works well. Great that you can power it by POE.

DD
By: DavidD5 11/04/24
0 out of 0 users found this review helpful
Did you find it helpful?

Exactly what I was after.

We live in a tiny house connected to the main broadband via 100m cable to the main house router. This setup is precisely what we required. After a simple plug-in and basic setup, we were up and running. The range is impressive, and it features smart dual-band technology, automatically connecting to the fastest band.

As rural residents, we contend with slow internet speeds, but we're pleased to report around 14mb/s within the house and a mere 11mb/s drop off at the access point, so not much of a drop-off!

OH
By: OllieH91 11/04/24
0 out of 0 users found this review helpful
Did you find it helpful?

Great price and so easy to set-up and extend our wifi.

So easy to set up and just worked perfectly from the outset. Is performing excellently.

MM
By: MarkM7546 12/02/24
Verified Owner
0 out of 0 users found this review helpful
Did you find it helpful?

Great model

Excellent product and does what it should. We now have wifi in the kitchen which we never had before, so very happy.

LB
By: LindaB69 31/12/23
Verified Owner
0 out of 0 users found this review helpful
Did you find it helpful?

it does what it says on the box

Out of the box, plug in a Cat 6 from my external router and immediate good wifi all round. Easy to get in to the web interface to set name and password, just what I wanted. Only slight negative, I haven't found where to set the wifi channels, but no problem as I can set the channel on the main router

G
By: Guest 12/06/23
0 out of 0 users found this review helpful
Did you find it helpful?

Does everything I wanted

Works great. Does what I want and what the box says.

G
By: Guest 15/02/23
0 out of 0 users found this review helpful
Did you find it helpful?

Works well, easy to set up

works well easy to set up

G
By: Guest 12/12/22
0 out of 0 users found this review helpful
Did you find it helpful?

Was Recommended by PB Tech

WiFi access point needed to extend my WiFi, took bit of sorting with passwords etc , but works a treat and full strength WiFi all thru my house

SH
By: StephenH125 14/11/22
Verified Owner
0 out of 0 users found this review helpful
Did you find it helpful?

Works great

Happy with this purchase just what we needed to extend the wifi.

G
By: Guest 16/11/21
0 out of 0 users found this review helpful
Did you find it helpful?

Works as advertised.

Stable connection, quality but not premium build. Has served me without complaint. Would recommend.

LJ
By: LeviJ85 29/07/21
Verified Owner
0 out of 0 users found this review helpful
Did you find it helpful?

Great value and performance

Brought this AP a week ago to extend the WiFi coverage in my house and it's working great. I've run a cable from my ISP supplied Router to this AP and I gave it the same SSID and password. Now I can seamlessly walk around and have my phone and other devices automatically switch over to the strongest signal. Setup was very easy too via the web page interface. Hopefully I won't need it but it's satisfying to know that this AP also comes with a 3yr warranty.
PROS: Easy to setup, great price and warranty, great WiFi range.
CONS: Not the prettiest device with it's 4 aerials sticking up but that wasn't a problem for my installation.

CM
By: CameronM985 28/04/21
Verified Owner
0 out of 0 users found this review helpful
Did you find it helpful?

Delivery & Pick-up

Potential courier delays: Please note that due to the high volumes currently within the NZ courier network there is potential for some deliveries to be delayed.

Delivery Estimates

The estimated time to ship for each product we sell is detailed on the individual product page just underneath the price. From when your items ship, products typically arrive within 1-2 working days for North Island deliveries and 2-3 working days for South Island deliveries. Rural deliveries may take an extra working day. Bulk & hazard deliveries may take an extra 2-4 working days.

Next Day Delivery

Need your order in a hurry? PB Tech offers next day delivery for local Auckland addresses. Simple place your order before 4pm (provided your items are in stock) and select our next day delivery option in the checkout. T&C's apply. Learn more about Next Day Delivery.

Same Day Delivery

Need your order in a hurry? PB Tech offers same day delivery for Auckland, Hamilton, Wellington and Christchurch. Simple place your order before 1pm (provided your items are in stock) and select one of our same day delivery options 'Evening Delivery' or 'Urgent 3-hour Delivery' in the checkout. T&C's apply. Learn more about Same Day Delivery.

Shipping Costs

Shipping costs vary based on your location and the items being shipped and in some cases shipping may even be FREE.

To calculate what the shipping costs will be for your order, add the items you are interested in to your cart, view the Shopping Cart page, and select your 'Delivery Area' to calculate the shipping cost.

Shipping Security & Insurance

All orders shipped by PB Tech are sent via a courier with a signature required for each delivery. In some cases, and only where you have given the courier company permission to leave orders at a designated location, your order may be delivered without requiring a signature. All orders sent by PB Tech are fully insured in the unlikely event that your item(s) are damaged or go missing in transit.

1 Hour Store Pick-up / Click & Collect

You can pick-up your online order from any of our stores nationwide. You can select which store you want to pick up from at the checkout. Provided the store you select has stock and there's no hold-ups with payment we will have your order ready within 1 hour (during normal trading hours for that store) otherwise it may take up to 5 working days to transfer the stock to the store so your order can be fulfilled. Learn more about our Click & Collect process.

Overseas Shipments

PB Tech regularly ships overseas to Australia and beyond. If you are located in Australia, you can order directly from our Australian site www.pbtech.com/au. If you are from another country you can order from www.pbtech.com

Returns & Warranty

7 day right of exchange

If you change your mind after making a purchase, or realise you have ordered the incorrect item, you can enjoy the peace of mind that we offer a 7 day exchange policy.

To exchange a product, goods must be sealed / unopened, with packaging in original condition, and accompanied by a valid receipt dated no more than 7 calendar days from when you request an exchange.

If there is not a suitable product that can be exchanged for your returned item you will be offered a credit on your account or gift card based on the value paid at the time of purchase.

Please note, items purchased on finance cannot be exchanged for a gift card.



Hassle free warranty service

If your product develops a fault within the manufacturer warranty period, you can either contact the manufacturer directly (some manufacturers provide a high level of warranty service - including free pickup or in some cases onsite repair), or return to one of our services centres / stores. Where the product has been directly imported by PB Tech, you need to contact us directly or present the product at any one of our service centres / stores together with your proof of purchase.

If your product develops a fault outside of the manufacturer warranty or PB Tech warranty period, we offer a full repair service and are an authorised repair agent for leading brands such as Samsung, HP, Toshiba, Lenovo and more.



Returning a product / making a warranty claim

To contact the manufacturer directly to troubleshoot your product or to request a warranty repair, please view the list of manufacturer / brand warranty contacts (for products imported directly by PB Tech please return to us directly by completing our request a return form).

To return a product to PB Tech directly, please complete our request a return form.

Or view our returns policy for more information.

TP-Link TL-WA1201 Wi-Fi Access Point MU-MIMO - Dual-Band AC1200 (450+867Mbps) Captive Portal - Multiple Modes - Access Point - Range Extender - Client modes

Expand your WiFi's reach. Full strength WiFi for your entire home made simple!
  • Brand: TP-Link
  • MPN: TL-WA1201
  • Part #: NAPTPL1201
PB Tech price $86.08 Excluding GST PB Tech price $98.99 Including GST

Date Created: 05:56, 16-04-2024
Product URL: https://www.pbtech.co.nz/product/NAPTPL1201/TP-Link-TL-WA1201-Wi-Fi-Access-Point-MU-MIMO---Dua
Branch New Stock On Display
Albany 11
Glenfield 0
Queen Street 1
Auckland Uni 0
Newmarket 0
Westgate 0
Penrose 1
Henderson (Express) 1
St Lukes 0
Manukau 0
Hamilton 1
Tauranga 3
New Plymouth 0
Palmerston North 0
Petone 1
Wellington 3
Head Office 30+
Hornby 7
Christchurch Central 2

Features

- AC1200 Dual-Band Wi-Fi - 867 Mbps at 5 GHz and 300 Mbps at 2.4 GHz band.
- Flexible Deployment - Supports Passive PoE to carry electrical power and data simultaneously.
- Multiple Modes - Supports Access Point, Range Extender, Multi-SSID, and Client modes to meet any network needs.
- MU-MIMO Technology - Simultaneously transfers data to multiple devices for 2� faster performance.
- Boosted Coverage - Four fixed antennas equipped with Beamforming technology extend and concentrate the Wi-Fi signals.
- Captive Portal - Offers a designed portal page for heightened security and marketing.



*Maximum wireless signal rates are the physical rates derived from IEEE Standard 802.11 specifications. Actual wireless data throughput and wireless coverage are not guaranteed and will vary as a result of 1) environmental factors, including building materials, physical objects, and obstacles, 2) network conditions, including local interference, volume and density of traffic, product location, network complexity, and network overhead, and 3) client limitations, including rated performance, location, connection, quality, and client condition.

?Use of MU-MIMO requires clients to also support MU-MIMO.

Specifications

HARDWARE FEATURES

Interface

1× 10/100/1000 Mbps Ethernet Port
(Supports Passive PoE)

Button

Power On/Off Button, WPS Button, Reset Button

External Power Supply

12V/1.5A

Wireless Standards

IEEE802.11b/g/n 2.4 GHz, IEEE 802.11ac/n/a 5 GHz

Dimensions ( W x D x H )

225×145.5×37 in (400×255×72 mm)

Antenna Type

4 Fixed High Performance Antennas

WIRELESS FEATURES

Frequency

2.4 GHz and 5 GHz

Signal Rate

867 Mbps at 5 GHz, 300 Mbps at 2.4 GHz

Reception Sensitivity

5 GHz:
11a 6 Mbps: -95 dBm, 11a 54 Mbps: -81 dBm
11ac VHT20(MCS0): -94 dBm, 11ac VHT20(MCS8): -71 dBm
11n HT40(MCS0): -91 dBm, 11n HT40(MCS7): -71 dBm
11ac VHT80(MCS0): -88 dBm, 11ac VHT80(MCS9): -63 dBm
2.4 GHz:
11g 54Mbps: -78 dBm
11n HT20(MCS0): -92 dBm, 11n HT20(MCS7): -74 dBm
11n HT40(MCS0): -88 dBm, 11n HT40(MCS7): -72 dBm

Transmit Power

CE: <20dBm(2.4GHz), <23dBm(5.15GHz~5.25GHz)
FCC: <30dBm(2.4GHz&5GHz)

Wireless Modes

Access Point, Range Extender, Client, Multi-SSID

Wireless Functions

Enable/Disable Wireless Radio, WDS Bridge, WMM, Wireless Statistics, Wireless Multicast Forwarding, DHCP Server, Access Control

Wireless Security

64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions

DHCP

Server, DHCP Client List

Quality of Service

WMM

Advanced Functions

Captive Portal

OTHERS

Certification

CE, FCC, RoHS

Package Contents

Wireless Access Point TL-WA1201
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
PoE Power Injector

System Requirements

Microsoft Windows 98SE, NT, 2000, XP, Vista™ or Windows 7, 8, 8.1,
10, MAC OS, NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
Java-enabled browser

Environment

Operating Temperature: 0°C ~ 40°C(32°F ~ 104°F)
Storage Temperature: -40°C ~ 70°C (-40°F ~ 158°F)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing

Protocol Support

IPv4, IPv6

Date Created: 05:56, 16-04-2024
Product URL: https://www.pbtech.co.nz/product/NAPTPL1201/TP-Link-TL-WA1201-Wi-Fi-Access-Point-MU-MIMO---Dua
