TP-Link PHAROS CPE210 2.4GHz 300Mbps 5km+ 9dBi Outdoor CPE, Support AP/Client/Repeater/AP Router/WISP Mode

+2 More
CLICK IMAGE TO ENLARGE

TP-Link PHAROS CPE210 2.4GHz 300Mbps 5km+ 9dBi Outdoor CPE, Support AP/Client/Repeater/AP Router...

  • Brand: TP-Link
  • MPN: CPE210
  • Part #: NETTPL0202
  • UPC:
  • Wi-Fi Bands:Single
  • USB Ports:None
  • Interface:N/A
  • Ethernet Ports:2
  • Wireless Transmission Speed:N/A
  • Wireless Technology:N/A
Returns & Warranty Bulk Quote Print Page
PB Tech price:PB Tech price:
$6869$7899
 +GST  inc GST
Store Pickup: Select your store to check availability
Delivery: Order now and it ships tomorrow
When will I receive it?
Add To List

What PB Tech customers are saying about this product...See More Reviews

"Using two of these for a point to point rural WiFi extender and it couldn't have been easier. Just over a month in with no issues."
 Gregg M. ~ 21-03-19   VERIFIED OWNER
"These CPE210 Ver 3 units with 64MB or memory have proven to perform well when reloaded with AREDN MESH operating system"
 Ted L. ~ 23-07-18

Features

2.4GHz 300Mbps 9dBi Outdoor CPE

-Built-in 9dBi 2x2 dual-polarized directional MIMO antenna
-Adjustable transmission power from 0 to 27dBm/500mw
-System-level optimizations for more than 5km long range wireless transmission
-TP-LINK Pharos MAXtream TDMA (Time-Division-Multiple-Access) technology improves product performance in throughput, capacity and latency performance, ideal for PTMP applications
-Centralized Management System - Pharos Control
-AP / Client / Bridge / Repeater / AP Router / AP Client Router (WISP) operation modes
-Passive PoE Adapter supports up to 60 meter (200 feet) Power over Ethernet deployment and allows the device to be reset remotely

Specifications

Processor
Qualcomm Atheros 560MHz CPU, MIPS 74Kc
Memory
64MB DDR2 RAM, 8MB Flash
Interface
1 10/100Mbps Shielded Ethernet Port (LAN0,Passive PoE in)
1 10/100Mbps Shielded Ethernet Port (LAN1, Passive PoE Passthrough)
1 Grounding Terminal
1 Reset Button
Power Supply
Passive Power over Ethernet via LAN0 (+4,5pins; -7,8pins)
Voltage range: 16-27VDC
Dimensions (W X D X H)
224 x 79 x 60 mm
Power Consumption
10.5 Watts Max
Note: When deployed using Passive PoE, the power drawn from the power source will be higher by some amount depending on the length of the connecting cable.
Antenna Type
Built-in 9dBi 2x2 Dual-polarized Directional Antenna
Beam Width: 65° (H-Plane) / 35° (E-Plane)
Note: For more details, please refer to datasheet
Protection
15KV ESD Protection
6KV Lightning Protection
Enclosure
Outdoor ASA stabilized plastic material
IPX5 waterproof Certification
Manufacturer Part No: CPE210 Brand: TP-Link Product Type: -
UPC - Product Family: PHAROS Shipping Weight: 0.756 kg
PB Part No: NETTPL0202 Product Model: CPE210

Warranty: 36 months local warranty *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.

Customer Questions & Answers

Want to know something about this product? Ask a question which other users may be able to answer.

Reviews

4.5 out of 5 StarsBased on 2 Reviews
5 Stars
1
4 Stars
1
3 Stars
0
2 Stars
0
1 Star
0

Filter Results

Do you own this product?

Write a review and go into the draw to win great prizes each month! Learn more WRITE A REVIEW
Displaying 1 - 2 of 2 reviews
Gregg M.
VERIFIED OWNER

Great Value and Easy Install

21 March 2019
Using two of these for a point to point rural WiFi extender and it couldn't have been easier. Just over a month in with no issues.
Did you find it helpful?
0 out of 0 users found this review helpful
Ted L.

Relaoding with AREDN FW

23 July 2018
These CPE210 Ver 3 units with 64MB or memory have proven to perform well when reloaded with AREDN MESH operating system
Did you find it helpful?
0 out of 0 users found this review helpful
