Ubiquiti NanoStation LocoM2 Outdoor airMAX CPE 2.4GHz, 150+ Mbps, 5+ km, 1 x 10/100 Ethernet Ports AP/Bridge

Ubiquiti NanoStation LocoM2 Outdoor airMAX CPE 2.4GHz, 150+ Mbps, 5+ km, 1 x 10/100 Ethernet Ports...

  • Brand: Ubiquiti
  • MPN: LOCOM2
  • Part #: NETUBI1072
  • UPC:817882023245
  • Ethernet Ports:1
  • Wireless Technology:N/A
  • USB Ports:None
  • Interface:N/A
  • Wireless Transmission Speed:150Mbps
  • Wi-Fi Bands:Single
PB Tech price:PB Tech price:
$8608$9899
 +GST  inc GST

Store Pickup: Select your store to check availability
Delivery: Order now and it ships tomorrow
When will I receive it?

What PB Tech customers are saying about this product...See More Reviews

"Great booster product reasonably good price and quick delivery gives me better speeds for my WiFi as I'm away from the cities thanks PB..."
 Rex S. ~ 27-09-18
"Good little unit. Using it as a outdoor AP, UI is a little slow."
 Tom ~ 17-05-16   VERIFIED OWNER
"Works 100 as advertised, unboxed the two units, configured them as described online, put them on 2 metre poles on the roofs of two house 150 metres apart, plugged them in and bingo - instant network..."
more
 Bruce D. ~ 14-08-15   VERIFIED OWNER

Features

The Ubiquiti Nanostation LocoM2 is the perfect solution for creating a dedicated Point to Point or Point to Multipoint connection between locations where running an ethernet cable is not a viable option. The Ubiquiti Nanostation LocoM2 can also be used for extending wireless coverage outdoors or to remote buildings to provide direct Wi-Fi access to mobile devices.



Plug and Play Installation

The NanoStation®M requires no tools for assembly; only a single wrench is required for pole-mounting.






Performance Breakthrough:

Up to 100Mbps real outdoor throughput and up to 1km+ range. Featuring 2x2 MIMO technology, the new Ubiquiti NanoStation links significantly faster and farther than ever before.

New Leading-Edge Industrial Design:

The original NanoStation set the bar for the world's first low-cost and efficiently designed outdoor broadband CPE. The new Ubiquiti NanoStation M and NanoStation Loco M take the same concept to the future with new redesigned sleek and elegant form-factors.






Next-Gen Antenna Design:

New Ubiquiti antenna array designs featuring 8dBi dual-polarity gain at 2.4GHz. Optimized cross-polarity isolation and in a compact form-factor.

AirOS V:

Ubiquiti's AirOS builds upon the market leading intuitive user-interface loaded with advanced wireless configurations and routing functionality.










In The Box

Specifications

Dimensions
161 x 31 x 80 mm

Weight
180 g

Power Supply
(PoE) 24V, 0.5A 24V, 0.5A

Max. Power Consumption
5.5W 5.5W

Power Method
Passive PoE (Pairs 4, 5+; 7, 8 Return)

Operating Frequency
2412-2462 MHz

Gain
8.5 dBi

Networking Interface
(1) 10/100 Ethernet Port

Processor Specs
Atheros MIPS 24Kc, 400 MHz

Memory
32 MB SDRAM, 8 MB Flash

Frequency
2.4 GHz

Cross-pol Isolation
20 dB Minimum

Max. VSWR
1.4:1

Beamwidth
60° (H-pol) / 60° (V-pol) / 60° (Elevation)

Polarization
Dual Linear

Enclosure
Outdoor UV Stabilized Plastic

Mounting
Pole-Mount (Kit Included)

Operating Temperature
-30 to 75° C (-22 to 167° F)

Operating Humidity
5 to 95% Noncondensing

Wireless Approvals
FCC Part 15.247, IC RS210, CE

RoHS Compliance
Yes

Shock & Vibration
ETSI300-019-1.4

In the Box
- NanoStation
- Cable Tie
- PoE Adapter (24V, 0.5A) with Mounting Bracket
- Power Cord
- Quick Start Guide

Manufacturer Part No: LOCOM2 Brand: Ubiquiti Product Type: Outdoor airMAX CPE
UPC 817882023245 Product Family: NanoStation Shipping Weight: 0.49 kg
PB Part No: NETUBI1072 Product Model: LocoM2

Warranty: 12 months *
* Warranty period is as stated above unless the manufacturer has chosen to specify a longer period.
All warranties are return to base unless otherwise specified.

Customer Questions & Answers

Want to know something about this product? Ask a question which other users may be able to answer.

Reviews

4.3 out of 5 StarsBased on 4 Reviews

5 Stars
2
4 Stars
1
3 Stars
1
2 Stars
0
1 Star
0

Filter Results

Do you own this product?

Write a review and go into the draw to win great prizes each month! Learn more WRITE A REVIEW
Displaying 1 - 4 of 4 reviews
Bruce D.
VERIFIED OWNER
14 August 2015
Works 100 as advertised, unboxed the two units, configured them as described online, put them on 2 metre poles on the roofs of two house 150 metres apart, plugged them in and bingo - instant network with great speed - easy to set up and great range - up to 5k line of sight - highly recommended - of course PB delivered the day after I ordered as usual great service as always
Did you find it helpful?
1 out of 1 user found this review helpful
Tom
VERIFIED OWNER
17 May 2016
Good little unit. Using it as a outdoor AP, UI is a little slow.
Did you find it helpful?
0 out of 0 users found this review helpful
Guest
12 October 2015
As for the M5, the documentation is non-existent. One must disable the proprietary features (set by default) to allow most user devices to access the AP. Whilst intended as an outdoor unit, I have doubts the enclosure's plastic will resist for several years, but at that price they are quite a bargain.
Did you find it helpful?
0 out of 0 users found this review helpful
Rex S.

Mr

27 September 2018
Great booster product reasonably good price and quick delivery gives me better speeds for my WiFi as I'm away from the cities thanks PB...
Did you find it helpful?
0 out of 1 user found this review helpful
